2009 Norco Nitro

Original specifications: Shimano Deore drivetrain · 26" wheels.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #16749
Model year
2009
Category
Mountain
Sizes
12.5", 15", 17", 18.5", 20", 22"
Colors
Green/White
In this record
26 specifications · archived image
Model history 16 other years

Browse other years

Compare side by side

Identification clues

2009 archived details

Published colors
Green/White
Frame
Hydraformed Aluminum
Original equipment
Shimano Deore

Clues, not proof of model year. Colors vary and components may have been replaced.

Original buildHydraformed Aluminum · Shimano Deore · 26" wheels

Historical catalog variants

Archived sizes and colors

6 item records

Item-level catalog entries recovered from Velopedia’s original bicycle archive. They document how this model was listed historically; they do not identify the frame size associated with legacy reference geometry or indicate current availability.

Published sizes

12.5"15"17"18.5"20"22"

Published colors

Green/White
View 6 archived size/color combinations
SizeColor
12.5"Green/White
15"Green/White
17"Green/White
18.5"Green/White
20"Green/White
22"Green/White

Historical catalog evidence. Exact specifications and naming may vary by market, production run or manufacturer revision.

Frameset

Frame ConstructionTIG-welded
Frame MaterialHydraformed Aluminum
ForkRockShox Tora Air SL, 100mm travel
Fork MaterialSingle

Drivetrain

Component GroupShimano Deore
ShiftersShimano Deore
Front DerailleurShimano Deore, 31.8mm clamp
Rear DerailleurShimano XT
CranksetShimano Deore, 22/32/44 teeth
Bottom BracketShimano Deore
CassetteShimano HG50
Rear Cogs9-speed, 11 - 34 teeth
ChainKMC HG-73, 1/2 x 3/32"
PedalsShimano 505

Brakes

BrakesAvid Juicy 3 w/ 6" rotor brakes, Avid Juicy 3 levers

Cockpit & Contact Points

Headset1 1/8" threadless FSA ZS-4
HandlebarRitchey MTN
Handlebar ExtensionsNot included
StemRitchey
SaddleWTB Silverado Comp
SeatpostRitchey, 27.2mm diameter

Wheels & Tires

HubsShimano M475
RimsMavic XM 117, 32-hole
SpokesStainless, straight gauge
Front Tire26 x 2.10" Schwalbe Nobby Nic Evolution
Wheel Size26" wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes44/32/22T · 11–34T · 9-speed
Lowest0.65:1 Highest4.00:1 Total range618%
Estimated speed At 90 RPM Lowest gear4.5 mph Highest gear28.1 mph

Uses front tire 26×2.1; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Chain · Original
KMC HG-73

1/2 x 3/32"

Front tire · Original
26 x 2.10" Schwalbe Nobby Nic Evolution
More parts (11)Fewer parts
Cassette · Original
Shimano HG50
Bottom bracket · Original
Shimano Deore
Saddle · Original
WTB Silverado Comp
Crankset · Original
Shimano Deore

22/32/44 teeth

Front derailleur · Original
Shimano Deore

31.8mm clamp

Rear derailleur · Original
Shimano XT Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.
Shifters · Original
Shimano Deore
Handlebar · Original
Ritchey MTN
Headset · Original
1 1/8" threadless FSA ZS-4
Rims · Original
Mavic XM 117

32-hole

Hubs · Original
Shimano M475

Based on the original build. Check fit and installed parts before ordering.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
26 x 2.10" Schwalbe Nobby Nic Evolution
Drivetrain
9-speed
Seatpost diameter
27.2 mm
Bottom bracket / shell
Shimano Deore
Equipment inspection checks 11 checks based on 6 archived component groups Open equipment checksClose equipment checks
0 of 11 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: RockShox Tora Air SL, 100mm travel · Single

Archived: Fork: RockShox Tora Air SL, 100mm travel

Archived: Group: Shimano Deore · Shifters: Shimano Deore · Front derailleur: Shimano Deore, 31.8mm clamp · Rear derailleur: Shimano XT · Crankset: Shimano Deore, 22/32/44 teeth · Bottom bracket: Shimano Deore · Cassette: Shimano HG50 · Rear cogs: 9-speed, 11 - 34 teeth · Chain: KMC HG-73, 1/2 x 3/32"

Archived: Brakes: Avid Juicy 3 w/ 6" rotor brakes, Avid Juicy 3 levers

Archived: Wheel size: 26" wheels · Rims: Mavic XM 117, 32-hole · Hubs: Shimano M475 · Front tire: 26 x 2.10" Schwalbe Nobby Nic Evolution

Controls and contact points

Archived: Headset: 1 1/8" threadless FSA ZS-4 · Handlebar: Ritchey MTN · Stem: Ritchey · Seatpost: Ritchey, 27.2mm diameter · Saddle: WTB Silverado Comp · Pedals: Shimano 505
