2009 Norco 4X

Original specifications: SRAM X5 · 9-speed · mechanical rear derailleur · 26" wheels.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #15992
Model year
2009
Category
Mountain
Sizes
S, M
Colors
Black
In this record
26 specifications · archived image
Original buildHydraformed Aluminum · SRAM Mix · 26" wheels

Historical catalog variants

Archived sizes and colors

2 item records

Item-level catalog entries recovered from Velopedia’s original bicycle archive. They document how this model was listed historically; they do not identify the frame size associated with legacy reference geometry or indicate current availability.

Published sizes

SM

Published colors

Black
View 2 archived size/color combinations
SizeColor
SBlack
MBlack

Historical catalog evidence. Exact specifications and naming may vary by market, production run or manufacturer revision.

Frameset

Frame ConstructionTIG-welded
Frame MaterialHydraformed Aluminum
ForkMarzocchi 4X, 100mm travel
Fork MaterialSingle
Rear ShockFox Float R, 100mm travel

Drivetrain

Component GroupSRAM Mix
ShiftersSRAM X.5
Rear DerailleurSRAM X.5
CranksetFSA Gravity Light MegaExo, 36 teeth
Bottom BracketFSA Mega EXO
CassetteSRAM PG-950
Rear Cogs9-speed, 12 - 25 teeth
ChainKMC Z9000, 1/2 x 3/32"
PedalsFlat alloy

Brakes

BrakesAvid Juicy 3 w/ 6" rotor brakes, Avid Juicy 3 levers

Cockpit & Contact Points

Headset1 1/8" threadless FSA TH-872
HandlebarSunline V-1 31.8mm
Handlebar ExtensionsNot included
StemSunline V-1
SaddlePivotal Tron Thin
SeatpostPivotal alloy, 27.2mm diameter

Wheels & Tires

HubsFront: KT, 20mm thru axle, Rear: KT, 135x10 axle
RimsSun Equalizer 27, 32-hole
SpokesStainless steel, 14ga. (2.0mm) straight gauge
Front Tire26 x 2.25" Intense Micro Knobby
Wheel Size26" wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes36T · 12–25T · 9-speed
Lowest1.44:1 Highest3.00:1 Total range208%
Estimated speed At 90 RPM Lowest gear10.2 mph Highest gear21.3 mph

Uses front tire 26×2.25; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Chain · Original
KMC Z9000

1/2 x 3/32"

Cassette · Original
SRAM PG-950
Front tire · Original
26 x 2.25" Intense Micro Knobby Replacement search: 26x2.25 bicycle tire Before ordering: Check rim type and tire clearance.
More parts (6)Fewer parts
Bottom bracket · Original
FSA Mega EXO
Crankset · Original
FSA Gravity Light MegaExo

36 teeth

Rear derailleur · Original
SRAM X.5
Shifters · Original
SRAM X.5
Seatpost · Original
Pivotal alloy

27.2mm diameter

Headset · Original
1 1/8" threadless FSA TH-872

Based on the original build. Check fit and installed parts before ordering.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
26 x 2.25" Intense Micro Knobby
Drivetrain
9-speed
Seatpost diameter
27.2 mm
Bottom bracket / shell
FSA Mega EXO
Equipment inspection checks 13 checks based on 6 archived component groups Open equipment checksClose equipment checks
0 of 13 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: Marzocchi 4X, 100mm travel · Single

Archived: Fork: Marzocchi 4X, 100mm travel · Rear shock: Fox Float R, 100mm travel

Archived: Group: SRAM Mix · Shifters: SRAM X.5 · Rear derailleur: SRAM X.5 · Crankset: FSA Gravity Light MegaExo, 36 teeth · Bottom bracket: FSA Mega EXO · Cassette: SRAM PG-950 · Rear cogs: 9-speed, 12 - 25 teeth · Chain: KMC Z9000, 1/2 x 3/32"

Archived: Brakes: Avid Juicy 3 w/ 6" rotor brakes, Avid Juicy 3 levers

Archived: Wheel size: 26" wheels · Rims: Sun Equalizer 27, 32-hole · Hubs: Front: KT, 20mm thru axle, Rear: KT, 135x10 axle · Front tire: 26 x 2.25" Intense Micro Knobby

Controls and contact points

Archived: Headset: 1 1/8" threadless FSA TH-872 · Handlebar: Sunline V-1 31.8mm · Stem: Sunline V-1 · Seatpost: Pivotal alloy, 27.2mm diameter · Saddle: Pivotal Tron Thin · Pedals: Flat alloy
