Velopedia Bicycle Archive

2004 Mongoose Switchback

Original specifications: Comfort Mix drivetrain · 26" wheels · legacy reference geometry.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #31644
Model year
2004
Category
City & Commuter
Original MSRP
$249.99
Sizes
L, M, S, womens medium
Geometry
Legacy reference
In this record
22 specifications · archived image · original MSRP · geometry
Model history 11 other years

Browse other years

Compare side by side

Identification clues

2004 archived details

Frame
6061 T6 aluminum
Original equipment
Comfort Mix

Clues, not proof of model year. Colors vary and components may have been replaced.

Original build6061 T6 aluminum · Comfort Mix · 26" wheels

Manufacturer catalog

Published sizes and colors

4 sizes

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

LMSwomens medium

Frameset

Frame ConstructionTIG-welded
Frame Material6061 T6 aluminum
Fork MaterialHi-tensile steel, unicrown crown

Drivetrain

Component GroupComfort Mix
ShiftersSRAM ESP 3.0
Front DerailleurShimano Tourney TY-32
Rear DerailleurSRAM ESP 3.0
CranksetSuntour XCC-100, 28/38/48 teeth
Rear Cogs7-speed, 14 - 34 teeth
ChainKMC Z51, 1/2 x 3/32"
PedalsNylon

Brakes

BrakesProMax linear-pull brakes, aluminum linear-pull levers

Cockpit & Contact Points

Headset1 1/8" steel
HandlebarSteel, 30mm rise
Handlebar ExtensionsNot included
StemAluminum, adjustable
SaddleMongoose Dual Density
SeatpostAluminum, suspension

Wheels & Tires

HubsAluminum, Q/R
RimsAlex Z1000, 36-hole
Front Tire26 x 1.95" Mongoose Comfort
Wheel Size26" wheels

Geometry

Legacy reference · 5 measurements

Historical measurements. Frame size unknown.

All geometry measurementsLegacy reference · 5 measurements
MeasurementLegacy reference
Top tube574 mm
Head-tube angle70°
Seat-tube angle73.5°
Chainstay / rear center429.3 mm
Fork offset / rake38.1 mm

Frame size not recorded.

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

Published build48/38/28T · 14–34T · 7-speed
Lowest0.82:1 Highest3.43:1 Total range416%
Estimated speed At 90 RPM Lowest gear5.7 mph Highest gear23.8 mph

Uses front tire 26×1.95; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Chain · Original
KMC Z51

1/2 x 3/32"

Front tire · Original
26 x 1.95" Mongoose Comfort Replacement search: 26x1.95 bicycle tire Before ordering: Check rim type and tire clearance.
Brake pads · Original
ProMax linear-pull brakes

aluminum linear-pull levers

More parts (2)Fewer parts
Front derailleur · Original
Shimano Tourney TY-32
Rims · Original
Alex Z1000

36-hole

Based on the original build. Check fit and installed parts before ordering.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
26 x 1.95" Mongoose Comfort
Drivetrain
7-speed
Equipment inspection checks 9 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 9 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: · Hi-tensile steel, unicrown crown

Archived: Group: Comfort Mix · Shifters: SRAM ESP 3.0 · Front derailleur: Shimano Tourney TY-32 · Rear derailleur: SRAM ESP 3.0 · Crankset: Suntour XCC-100, 28/38/48 teeth · Rear cogs: 7-speed, 14 - 34 teeth · Chain: KMC Z51, 1/2 x 3/32"

Archived: Brakes: ProMax linear-pull brakes, aluminum linear-pull levers

Archived: Wheel size: 26" wheels · Rims: Alex Z1000, 36-hole · Hubs: Aluminum, Q/R · Front tire: 26 x 1.95" Mongoose Comfort

Controls and contact points

Archived: Headset: 1 1/8" steel · Handlebar: Steel, 30mm rise · Stem: Aluminum, adjustable · Seatpost: Aluminum, suspension · Saddle: Mongoose Dual Density · Pedals: Nylon
