Velopedia Bicycle Archive

1995 Mongoose Switchback

Original specifications: Shimano AceraX drivetrain · 26" wheels · 30 lb published weight.

Share owner experience

Planning to sell? Draft your listing

No archive photo is available for this record.

At a glance

Archive #32498
Model year
1995
Category
Mountain
Original MSRP
$300.00
Sizes
13.5", 15.5", 17.5", 19.5", 21.5", 23.5", womens 17", womens 19"
Colors
Bright purple, Forest Green, Sapphire Blue
Weight
30 lb
Geometry
Legacy reference
In this record
25 specifications · original MSRP · geometry
Model history 11 other years

Browse other years

Compare side by side

Identification clues

1995 archived details

Published colors
Bright purple, Forest Green, Sapphire Blue
Frame
Tange chromoly main triangle
Original equipment
Shimano AceraX

Clues, not proof of model year. Colors vary and components may have been replaced.

Original buildTange chromoly main triangle · Shimano AceraX · 26" wheels

Manufacturer catalog

Published sizes and colors

8 sizes · 3 colors

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

13.5"15.5"17.5"19.5"21.5"23.5"womens 17"womens 19"

Published colors

Bright purpleForest GreenSapphire Blue

Frameset

Frame ConstructionTIG-welded steel
Frame MaterialTange chromoly main triangle
ForkMongoose
Fork MaterialChromoly, unicrown crown

Drivetrain

Component GroupShimano AceraX
ShiftersShimano AceraX RapidFire TX
Front DerailleurShimano AceraX, bottom-pull/clamp-on 28.6 mm
Rear DerailleurShimano AceraX
CranksetTracer MT-6i, 24/34/42 teeth
Rear Cogs7-speed, 11 - 28 teeth
ChainShimano CN-UG50, 1/2 x 3/32"
PedalsComposite

Brakes

BrakesShimano Altus C90 brakes, Shimano AceraX levers

Cockpit & Contact Points

Headset1" YST 8002E
HandlebarMongoose MTB
Handlebar ExtensionsNot included
StemMongoose MTB
SaddleMongoose Gel
SeatpostMongoose, 26.2 mm diameter

Wheels & Tires

HubsShimano AceraX
RimsAraya VP-20, 36-hole
Spokes2.0 mm
Spoke NipplesBrass nipples
Front Tire26 x 1.95" Mongoose
Wheel Size26" wheels

Geometry

Legacy reference · 6 measurements

Historical measurements. Frame size unknown.

All geometry measurementsLegacy reference · 6 measurements
MeasurementLegacy reference
Top tube560 mm
Head-tube angle70°
Seat-tube angle72°
Chainstay / rear center445 mm
Wheelbase1067 mm
Fork offset / rake45 mm

Frame size not recorded.

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

Published build42/34/24T · 11–28T · 7-speed
Lowest0.86:1 Highest3.82:1 Total range445%
Estimated speed At 90 RPM Lowest gear6.0 mph Highest gear26.5 mph

Uses front tire 26×1.95; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Chain · Original
Shimano CN-UG50

1/2 x 3/32"

Front tire · Original
26 x 1.95" Mongoose Replacement search: 26x1.95 bicycle tire Before ordering: Check rim type and tire clearance.
Seatpost · Original
Mongoose

26.2 mm diameter

More parts (1)Fewer parts
Hubs · Original
Shimano AceraX

Based on the original build. Check fit and installed parts before ordering.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
26 x 1.95" Mongoose
Drivetrain
7-speed
Seatpost diameter
26.2 mm
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 10 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded steel · Fork: Mongoose · Chromoly, unicrown crown

Archived: Group: Shimano AceraX · Shifters: Shimano AceraX RapidFire TX · Front derailleur: Shimano AceraX, bottom-pull/clamp-on 28.6 mm · Rear derailleur: Shimano AceraX · Crankset: Tracer MT-6i, 24/34/42 teeth · Rear cogs: 7-speed, 11 - 28 teeth · Chain: Shimano CN-UG50, 1/2 x 3/32"

Archived: Brakes: Shimano Altus C90 brakes, Shimano AceraX levers

Archived: Wheel size: 26" wheels · Rims: Araya VP-20, 36-hole · Hubs: Shimano AceraX · Front tire: 26 x 1.95" Mongoose

Controls and contact points

Archived: Headset: 1" YST 8002E · Handlebar: Mongoose MTB · Stem: Mongoose MTB · Seatpost: Mongoose, 26.2 mm diameter · Saddle: Mongoose Gel · Pedals: Composite
