2010 Masi CXR

Original specifications: Shimano 105 · 10-speed rear derailleur · 700c wheels.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #19860
Model year
2010
Category
Gravel & Cyclocross
Original MSRP
$1,785.00
Sizes
49cm, 52cm, 55cm, 57cm, 60cm
Colors
SG Ano White
In this record
24 specifications · archived image · original MSRP
Model history 6 other years

Browse other years

Compare side by side

Identification clues

2010 archived details

Published colors
SG Ano White
Frame
7005 T6 SLX Double Butted Alloy
Original equipment
Cyclocross Mix

Clues, not proof of model year. Colors vary and components may have been replaced.

Sponsored affiliate link
Original build7005 T6 SLX Double Butted Alloy · Cyclocross Mix · 700c wheels

Historical catalog variants

Archived sizes and colors

5 item records

Item-level catalog entries recovered from Velopedia’s original bicycle archive. They document how this model was listed historically; they do not identify the frame size associated with legacy reference geometry or indicate current availability.

Published sizes

49cm52cm55cm57cm60cm

Published colors

SG Ano White
View 5 archived size/color combinations
SizeColor
49cmSG Ano White
52cmSG Ano White
55cmSG Ano White
57cmSG Ano White
60cmSG Ano White

Historical catalog evidence. Exact specifications and naming may vary by market, production run or manufacturer revision.

Frameset

Frame ConstructionTIG-welded
Frame Material7005 T6 SLX Double Butted Alloy
ForkMasi Elite/RS Cross Carbon
Fork MaterialCarbon w/alloy steerer, aero crown

Drivetrain

Component GroupCyclocross Mix
ShiftersShimano 105 STI
Front DerailleurShimano 105
Rear DerailleurShimano 105
CranksetTruVativ Elita C 2.2, 48/34 teeth
Bottom BracketTruVativ Giga X Pipe
CassetteShimano 105
Rear Cogs10-speed, 12 - 27 teeth
ChainShimano 105

Brakes

BrakesKore Race Plus brakes, Shimano 105 STI levers

Cockpit & Contact Points

Headset1 1/8" threadless Ritchey Pro Zero drop in
HandlebarRitchey Pro Logic
Handlebar ExtensionsNot included
StemRitchey Pro 4-axis 44
SaddleMasi SLR w/tubular crmo rails
SeatpostMasi Carbon, 27.2mm diameter

Wheels & Tires

HubsKore Gradient II
RimsKore Gradient II
Front Tire700 x 32c Ritchey Speed Max Cross Pro
Wheel Size700c wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

All published sizes48/34T · 12–27T · 10-speed
Lowest1.26:1 Highest4.00:1 Total range318%

Speed unavailable: wheel or tire size is missing or unclear.

Add your rear tire size to calculate speed
How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Front tire · Original
700 x 32c Ritchey Speed Max Cross Pro
Retailer offers
Seatpost · Original
Masi Carbon

27.2mm diameter

Retailer offers
Chain · Original
Shimano 105
More parts (6)Fewer parts
Front derailleur · Original
Shimano 105 Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.
Rear derailleur · Original
Shimano 105 Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.
Shifters · Original
Shimano 105 STI Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.
Handlebar · Original
Ritchey Pro Logic
Stem · Original
Ritchey Pro 4-axis 44
Headset · Original
1 1/8" threadless Ritchey Pro Zero drop in

Based on the original build. Check fit and installed parts before ordering.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
700 x 32c Ritchey Speed Max Cross Pro
Drivetrain
10-speed
Seatpost diameter
27.2 mm
Bottom bracket / shell
TruVativ Giga X Pipe
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 10 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: Masi Elite/RS Cross Carbon · Carbon w/alloy steerer, aero crown

Archived: Group: Cyclocross Mix · Shifters: Shimano 105 STI · Front derailleur: Shimano 105 · Rear derailleur: Shimano 105 · Crankset: TruVativ Elita C 2.2, 48/34 teeth · Bottom bracket: TruVativ Giga X Pipe · Cassette: Shimano 105 · Rear cogs: 10-speed, 12 - 27 teeth · Chain: Shimano 105

Archived: Brakes: Kore Race Plus brakes, Shimano 105 STI levers

Archived: Wheel size: 700c wheels · Rims: Kore Gradient II · Hubs: Kore Gradient II · Front tire: 700 x 32c Ritchey Speed Max Cross Pro

Controls and contact points

Archived: Headset: 1 1/8" threadless Ritchey Pro Zero drop in · Handlebar: Ritchey Pro Logic · Stem: Ritchey Pro 4-axis 44 · Seatpost: Masi Carbon, 27.2mm diameter · Saddle: Masi SLR w/tubular crmo rails
