2027 Liv Avail Advanced 2

Original specifications: geometry for 5 published sizes.

Share owner experience

At a glance

Archive #900002171

Model year: 2027
Category: Road
Original MSRP: $3,300.00
Sizes: XXS, XS, S, M, L
Colors: Cosmic Dust/Tiger Red, Silver Pine/Black
Geometry: 5 manufacturer sizes
In this record: 21 specifications · 5 archived images · original MSRP · geometry

Model history 3 other years

Browse other years

Compare side by side

Identification clues

2027 archived details

Published colors: Cosmic Dust/Tiger Red, Silver Pine/Black
Frame: Carbon Fiber

Clues, not proof of model year. Colors vary and components may have been replaced.

Original buildCarbon Fiber

Manufacturer catalog

Published sizes and colors

5 sizes · 2 colors

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

XXSXSSML

Published colors

Cosmic Dust/Tiger RedSilver Pine/Black

Frameset

Frame Construction	Advanced-grade composite, 12x142mm thru-axle, disc
Frame Material	Carbon Fiber
Fork	Advanced-grade composite, full-composite OverDrive steerer, 12x100mm thru-axle, disc
Fork Material	Carbon Fiber

Drivetrain

Shifters	Shimano 105
Front Derailleur	Shimano 105
Rear Derailleur	Shimano 105
Crankset	Shimano 105, 34/50 XXS: 160mm, XS: 165mm, S: 165mm, M: 170mm, L: 172.5mm
Bottom Bracket	Shimano, press fit
Cassette	Shimano 105, 12-speed, 11x36
Chain	KMC X12L-1

Brakes

Brakes	Shimano 105 hydraulic, Shimano SM-RT64 rotors [F]160mm, [R]160mm

Cockpit & Contact Points

Handlebar	Liv Contact SL D-Fuse, 31.8mm XXS: 380/410mm, XS: 380/410mm, S: 400/430mm, M: 400/430mm, L: 420/450mm
Stem	Giant Contact AeroLight, -10-degree XXS: 70mm, XS: 70mm, S: 80mm, M: 90mm, L: 90mm
Saddle	Liv Approach
Seatpost	Giant D-Fuse, composite, 14mm offset

Wheels & Tires

Hubs	Giant alloy, 12mm thru-axle
Rims	Giant P-R1 Disc wheelset, alloy, [F] 25mm, [R] 25mm
Spokes	Sapim
Front Tire	Giant Gavia Fondo 1, tubeless, 700x32c (33.5mm), folding
Rear Tire	Giant Gavia Fondo 1, tubeless, 700x32c (33.5mm), folding

Geometry

5 sizes · 16 measurements

Frame measurements by size.

All geometry measurements5 sizes · 16 measurements

Measurement	XXS	XS	S	M	L
Seat tube	385 mm	405 mm	435 mm	465 mm	495 mm
Top tube	500 mm	520 mm	525 mm	535 mm	550 mm
Head tube	110 mm	125 mm	145 mm	165 mm	185 mm
Head-tube angle	69.8°	71°	71°	71°	72°
Seat-tube angle	75°	74.5°	74.5°	74°	74°
Chainstay / rear center	420 mm	420 mm	420 mm	420 mm	420 mm
Wheelbase	989 mm	995 mm	1002 mm	1007 mm	1013 mm
Bottom-bracket drop	75 mm	75 mm	75 mm	75 mm	75 mm
Reach	363 mm	373 mm	373 mm	373 mm	381 mm
Stack	510 mm	528 mm	547 mm	566 mm	589 mm
Standover height	683 mm	712 mm	737 mm	762 mm	789 mm
Fork offset / rake	50 mm	50 mm	50 mm	50 mm	50 mm
Trail	76.2 mm	68.3 mm	68.3 mm	68.3 mm	61.8 mm
Crank length	160 mm	165 mm	165 mm	170 mm	172.5 mm
Stem length	70 mm	70 mm	80 mm	90 mm	90 mm
Handlebar width	380 mm	380 mm	400 mm	400 mm	420 mm

Dimensions as recorded.

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

Pedal cadence

RPM

Speed units

RPM = pedal turns per minute.

All published sizes50/34T · 11–36T · 12-speed

Lowest0.94:1 Highest4.55:1 Total range481%

Estimated speed At 90 RPM Lowest gear6.8 mph Highest gear32.9 mph

Rear tire: 700C×32.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Gears Drivetrain

Front teeth Smallest rear teeth Largest rear teeth

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Rear tire marking

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

Rim diameter (BSD, mm) Tire width (mm)

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Cadence (RPM) Speed units

Gear, dimension and cadence changes update results automatically.

Gearing comparison
Measure	Original	Your setup
Lowest ratio	—	—
Highest ratio	—	—
Total range	—	—
Lowest-gear speed	—	—
Highest-gear speed	—	—

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
