2026 Kona Lava Dome
Mountain bicycle from the Velopedia specification archive.
Selling this bike? Create a Bike History Report
What Velopedia knows
- Model year
- 2026
- Category
- Mountain
- Original MSRP
- $799.00
- Sizes
- XS, S, M, L, XL
- Colors
- Gloss Celestial Blue w/ Reef Decals
- Geometry
- 5 manufacturer sizes · Geometry context
- Record coverage
- 23 preserved details · 8 archived images · original MSRP · preserved geometry
- Archive ID
- 900001152
Model history 10 other years
Frameset
| Frame Construction | Kona 6061 Aluminum Butted |
|---|---|
| Frame Material | Aluminum |
| Fork | Suntour XCM32 100mm |
| Rear Shock | n/a |
Drivetrain
| Shifters | Microshift Advent |
|---|---|
| Front Derailleur | n/a |
| Rear Derailleur | Microshift Advent w/ Clutch |
| Crankset | Prowheel Charm; Chainring: Prowheel 30t |
| Bottom Bracket | Fei Min 73mm |
| Cassette | Microshift Advent 11-46t 9spd |
| Chain | KMC X9 |
| Pedals | Kona JS2 |
Brakes
| Brakes | Brake Calipers: Shimano MT200; Front Brake Rotor: Shimano SM-RT26 180mm; Rear Brake Rotor: Shimano SM-RT26 160mm; Brake Levers: Shimano MT200 |
|---|
Cockpit & Contact Points
| Headset | Feimen HP-H868B |
|---|---|
| Handlebar | Kona XC/BC Riser |
| Stem | Kona XC |
| Saddle | Kona XC |
| Seatpost | Kona Thumb 31.6mm |
Wheels & Tires
| Hubs | (F) Joytech 100x9mm / (R) Joytech 135x10mm |
|---|---|
| Rims | HL I27 (XS=26, SM=27.5", MD-XL=29") |
| Spokes | Stainless Black 14g |
| Front Tire | WTB Trail Boss 2.25" (XS=26, SM=27.5", MD-XL=29") |
| Rear Tire | WTB Trail Boss 2.25" (XS=26, SM=27.5", MD-XL=29") |
Size-specific frame data
Geometry
Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.
| Measurement | XS | S | M | L | XL |
|---|---|---|---|---|---|
| Seat tube | 365 mm | 380 mm | 410 mm | 450 mm | 490 mm |
| Top tube | 560 mm | 587 mm | 622 mm | 650 mm | 687 mm |
| Head tube | 100 mm | 110 mm | 120 mm | 130 mm | 140 mm |
| Head-tube angle | 67.5° | 67.5° | 67.5° | 67.5° | 67.5° |
| Seat-tube angle | 75° | 75° | 75° | 75° | 75° |
| Chainstay / rear center | 435 mm | 435 mm | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1110 mm | 1132 mm | 1190 mm | 1219 mm | 1257 mm |
| Bottom-bracket drop | 30 mm | 45 mm | 60 mm | 60 mm | 60 mm |
| Bottom-bracket height | 305 mm | 310 mm | 315 mm | 315 mm | 315 mm |
| Reach | 410 mm | 430 mm | 455 mm | 480 mm | 515 mm |
| Stack | 561 mm | 586 mm | 624 mm | 633 mm | 642 mm |
| Standover height | 679 mm | 699 mm | 728 mm | 726 mm | 721 mm |
| Fork offset / rake | 42 mm | 42 mm | 51 mm | 51 mm | 51 mm |
| Front center | 676 mm | 701 mm | 746 mm | 755 mm | 814 mm |
| Fork length / axle-to-crown | 490 mm | 490 mm | 509 mm | 509 mm | 509 mm |
Geometry source: Manufacturer HTML geometry table ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.
Geometry tools
Analyze a published size
XS geometry
Archive context: Its stack of 561 mm sits toward the lower end. The head angle of 67.5° sits toward the steeper end. Its wheelbase of 1110 mm sits toward the shorter end.
Compared with 52 distinct mountain geometries in the XS-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze XS geometry S geometry
Archive context: Its stack of 586 mm sits toward the lower end. The head angle of 67.5° sits toward the steeper end. Its wheelbase of 1132 mm sits toward the shorter end.
Compared with 168 distinct mountain geometries in the Small-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze S geometry M geometry
Archive context: The chainstay of 450 mm sits toward the longer rear-center end. Its bottom-bracket drop of 60 mm sits toward the deeper-drop end. The head angle of 67.5° sits toward the steeper end.
Compared with 171 distinct mountain geometries in the Medium-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze M geometry L geometry
Archive context: The chainstay of 450 mm sits toward the longer rear-center end. Its bottom-bracket drop of 60 mm sits toward the deeper-drop end. The head angle of 67.5° sits toward the steeper end.
Compared with 166 distinct mountain geometries in the Large-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze L geometry XL geometry
Archive context: The chainstay of 450 mm sits toward the longer rear-center end. Its bottom-bracket drop of 60 mm sits toward the deeper-drop end. The head angle of 67.5° sits toward the steeper end.
Compared with 145 distinct mountain geometries in the XL-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze XL geometry Parts & serviceability
Find replacement parts
ChainKMC X9Exact archived model
CassetteMicroshift Advent 11-46t 9spdComponent family — verify exact version
ShiftersMicroshift AdventNamed component · published drivetrain speed — verify exact version
More qualified parts (1)
Seatpost31.6 mm seatpostPublished diameter — verify length and setback
Searches use the archived manufacturer specification, not the components currently installed on a particular bicycle. Confirm the exact model, size and fit before ordering. As an Amazon Associate I earn from qualifying purchases. Velopedia may also earn from qualifying eBay purchases. Velopedia may also earn from qualifying retailer purchases. Commercial relationships do not influence Archive specifications or analysis.
Used-bike inspection
If you’re buying this bike used
Before any test ride: both brakes should stop the bike firmly and release cleanly; both wheels should run true and be securely attached; tires should have no casing damage; and the headset, handlebar, stem, cranks and pedals should have no looseness or play.
Follow the full used-bike inspection order →- FrameLook closely for dents and hairline cracks around welds, the head tube and bottom-bracket area. Cosmetic scratches matter less than a change in shape or a crack line.Inspect the frame and fork →
- BrakesTest each brake separately and confirm it stops firmly and releases cleanly. Inspect the pads and braking surfaces for wear or contamination, and check the cables or hoses for damage.Inspect the brakes →
- SuspensionAsk when the fork was last serviced. Check the stanchions for damage, look for oil at the seals and make sure the fork moves smoothly without bushing play.Evaluate the suspension →
- DrivetrainShift through every gear under light load and measure chain wear. Confirm that the shifter, derailleur, chain and cassette belong to the same 9-speed system.Check drivetrain wear →
- Wheels & tiresSpin both wheels and watch the rims for side-to-side or vertical movement. Check for dents, cracks, loose or uneven spokes and hub play, then inspect both tire casings for cuts, cracking or exposed threads.Check wheels and tires →
Bike-specific inspection checklist 20 checks based on 6 archived component groups Open checklistClose checklist
This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.
Identity and fit
Follow the full used-bike inspection order →Archived: 2026 Kona Lava Dome · Mountain · Published sizes: XS, S, M, L, XL
Frame and fork
Inspect the frame and fork →Archived: Frame: Kona 6061 Aluminum Butted · Fork: Suntour XCM32 100mm
Suspension
Evaluate the suspension →Archived: Fork: Suntour XCM32 100mm
Drivetrain
Check drivetrain wear →Archived: Shifters: Microshift Advent · Rear derailleur: Microshift Advent w/ Clutch · Crankset: Prowheel Charm; Chainring: Prowheel 30t · Bottom bracket: Fei Min 73mm · Cassette: Microshift Advent 11-46t 9spd · Chain: KMC X9
Brakes
Inspect the brakes →Archived: Brakes: Brake Calipers: Shimano MT200; Front Brake Rotor: Shimano SM-RT26 180mm; Rear Brake Rotor: Shimano SM-RT26 160mm; Brake Levers: Shimano MT200
Wheels and tires
Check wheels and tires →Archived: Rims: HL i27 (XS=26, SM=27.5", MD-XL=29") · Hubs: (F) Joytech 100x9mm / (R) Joytech 135x10mm · Front tire: WTB Trail Boss 2.25" (XS=26, SM=27.5", MD-XL=29") · Rear tire: WTB Trail Boss 2.25" (XS=26, SM=27.5", MD-XL=29")
Controls and contact points
Archived: Headset: Feimen HP-H868B · Handlebar: Kona XC/BC Riser · Stem: Kona XC · Seatpost: Kona Thumb 31.6mm · Saddle: Kona XC · Pedals: Kona JS2
Before and during the test ride
Follow the full used-bike inspection order →Build relationships are limited to the archived manufacturer specifications. Confirm exact fit and standards before ordering parts or performing service.
