2026 Kona Humu
City/Commuter bicycle from the Velopedia specification archive.
Selling this bike? Create a Bike History Report
What Velopedia knows
- Model year
- 2026
- Category
- City & Commuter
- Original MSRP
- $1,699.00
- Sizes
- S, M, L, XL
- Colors
- Gloss Clematis w/ Near White, Bone, Nectarine & Fjord Decals
- Geometry
- 4 manufacturer sizes · Geometry context
- Record coverage
- 23 preserved details · 8 archived images · original MSRP · preserved geometry
- Archive ID
- 900000967
Model history 4 other years
Frameset
| Frame Construction | Kona Butted Cromoly |
|---|---|
| Fork | Kona Cromoly |
| Rear Shock | n/a |
Drivetrain
| Shifters | n/a |
|---|---|
| Front Derailleur | n/a |
| Rear Derailleur | n/a |
| Crankset | FSA Comet Heavy Duty 32t |
| Bottom Bracket | FSA MegaExo BSA 73 |
| Cassette | Single Speed 18t |
| Chain | KMC Z1 |
| Pedals | Kona JS2 |
Brakes
| Brakes | Brake Calipers: Tektro HD-M280 2-piston; Front Brake Rotor: Tektro 180mm 6B 1.8mm; Rear Brake Rotor: Tektro 160mm 6B 1.8mm; Brake Levers: Tektro M280 |
|---|
Cockpit & Contact Points
| Headset | FSA no.10 ZS44/ZS44 |
|---|---|
| Handlebar | Kona 31.8mm / Back 17º / Up 7º / Rise 80mm / Width 820mm |
| Stem | Kona 31.8mm / Rise 0º / Length 45mm |
| Saddle | WTB Comfort |
| Seatpost | Kona Thumb w/Offset 27.2mm / Length S-M 350mm / L-XL 375mm |
Wheels & Tires
| Hubs | (F) Formula 15x110mm / (R) Formula 12x148mm HG |
|---|---|
| Rims | WTB ST i30 |
| Spokes | Stainless 2.0mm Black |
| Front Tire | WTB Groov-E 29x2.25" |
| Rear Tire | WTB Groov-E 29x2.25" |
| Wheel Size | 29" |
Size-specific frame data
Geometry
Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.
| Measurement | S | M | L | XL |
|---|---|---|---|---|
| Seat tube | 420 mm | 470 mm | 520 mm | 570 mm |
| Top tube | 573 mm | 612 mm | 650 mm | 689 mm |
| Head tube | 110 mm | 140 mm | 170 mm | 200 mm |
| Head-tube angle | 69° | 69° | 69° | 69° |
| Seat-tube angle | 73° | 73° | 73° | 73° |
| Chainstay / rear center | 450-466 | 450-466 | 450-466 | 450-466 |
| Wheelbase | 1083-1096 | 1124-1140 | 1165-1179 | 1205-1221 |
| Bottom-bracket drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Bottom-bracket height | 305 mm | 305 mm | 305 mm | 305 mm |
| Reach | 400 mm | 430 mm | 460 mm | 490 mm |
| Stack | 566 mm | 594 mm | 622 mm | 650 mm |
| Standover height | 733 mm | 773 mm | 816 mm | 844 mm |
| Fork offset / rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Front center | 643 mm | 683 mm | 724 mm | 764 mm |
| Fork length / axle-to-crown | 435 mm | 435 mm | 435 mm | 435 mm |
Geometry source: Manufacturer HTML geometry table ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.
Geometry tools
Analyze a published size
The archived table contains multiple manufacturer geometry states. Velopedia preserves source order and analyzes each state separately rather than averaging the published values.
S geometry
Configuration
Archive context: The seat angle of 73° sits somewhat more relaxed than typical. The chainstay of 450 mm sits somewhat shorter than typical. Its stack of 566 mm sits somewhat lower than typical.
Compared with 27 distinct city & commuter geometries in the Small-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze S · Configuration 1 geometry Archive context: The seat angle of 73° sits somewhat more relaxed than typical. Its stack of 566 mm sits somewhat lower than typical. Its reach of 400 mm sits somewhat longer than typical.
Compared with 27 distinct city & commuter geometries in the Small-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze S · Configuration 2 geometry M geometry
Configuration
Archive context: The seat angle of 73° sits toward the more relaxed end. Its reach of 430 mm sits toward the longer end. The chainstay of 450 mm sits somewhat shorter than typical.
Compared with 29 distinct city & commuter geometries in the Medium-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze M · Configuration 1 geometry Archive context: The seat angle of 73° sits toward the more relaxed end. Its reach of 430 mm sits toward the longer end. Its stack of 594 mm sits somewhat lower than typical.
Compared with 29 distinct city & commuter geometries in the Medium-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze M · Configuration 2 geometry L geometry
Configuration
Archive context: Its reach of 460 mm sits toward the longer end. The chainstay of 450 mm sits somewhat shorter than typical. The seat angle of 73° sits somewhat more relaxed than typical.
Compared with 28 distinct city & commuter geometries in the Large-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze L · Configuration 1 geometry Archive context: Its reach of 460 mm sits toward the longer end. The seat angle of 73° sits somewhat more relaxed than typical. Its stack of 622 mm sits somewhat lower than typical.
Compared with 28 distinct city & commuter geometries in the Large-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze L · Configuration 2 geometry XL geometry
Configuration
Archive context: Its reach of 490 mm sits toward the longer end. Its stack of 650 mm sits somewhat lower than typical. The chainstay of 450 mm sits somewhat shorter than typical.
Compared with 16 distinct city & commuter geometries in the XL-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze XL · Configuration 1 geometry Archive context: Its reach of 490 mm sits toward the longer end. Its stack of 650 mm sits somewhat lower than typical. Its wheelbase of 1221 mm sits somewhat longer than typical.
Compared with 16 distinct city & commuter geometries in the XL-equivalent size cohort from model years 2024–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze XL · Configuration 2 geometry Parts & serviceability
Find replacement parts
ChainKMC Z1Exact archived model
Front tireWTB Groov-E 29x2.25"Named tire and published size
Brake padsBrake Calipers: Tektro HD-M280 2-pistonBrake model identified — verify pad shape
More qualified parts (3)
Bottom bracketFSA MegaExo BSA 73Named archived component — verify dimensions
CranksetFSA Comet Heavy Duty 32tNamed archived component — verify exact version
RimsWTB ST i30Named archived component — verify dimensions
Searches use the archived manufacturer specification, not the components currently installed on a particular bicycle. Confirm the exact model, size and fit before ordering. As an Amazon Associate I earn from qualifying purchases. Velopedia may also earn from qualifying eBay purchases. Velopedia may also earn from qualifying retailer purchases. Commercial relationships do not influence Archive specifications or analysis.
Used-bike inspection
If you’re buying this bike used
Before any test ride: both brakes should stop the bike firmly and release cleanly; both wheels should run true and be securely attached; tires should have no casing damage; and the headset, handlebar, stem, cranks and pedals should have no looseness or play.
Follow the full used-bike inspection order →- FrameInspect the complete frame and fork in bright light for cracks, dents, distortion, corrosion, impact marks, suspicious paint differences or signs of repair. Check the head tube, bottom-bracket area, dropouts, joints and clamped surfaces especially closely.Inspect the frame and fork →
- BrakesTest each brake separately and confirm it stops firmly and releases cleanly. Inspect the pads and braking surfaces for wear or contamination, and check the cables or hoses for damage.Inspect the brakes →
- DrivetrainShift through the full range under light load, measure chain wear and inspect the cassette or freewheel teeth. Skipping or hesitation can indicate wear, poor adjustment or mismatched parts.Check drivetrain wear →
- Wheels & tiresSpin both wheels and watch the rims for side-to-side or vertical movement. Check for dents, cracks, loose or uneven spokes and hub play, then inspect both tire casings for cuts, cracking or exposed threads.Check wheels and tires →
- Bottom bracketTurn the cranks slowly, feel for rough bearings and check for side-to-side play. Creaking under load deserves investigation but does not identify the source by itself.Inspect the bottom bracket and shell →
Bike-specific inspection checklist 19 checks based on 5 archived component groups Open checklistClose checklist
This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.
Identity and fit
Follow the full used-bike inspection order →Archived: 2026 Kona Humu · City/Commuter · Published sizes: S, M, L, XL
Frame and fork
Inspect the frame and fork →Archived: Frame: Kona Butted Cromoly · Fork: Kona Cromoly
Drivetrain
Check drivetrain wear →Archived: Crankset: FSA Comet Heavy Duty 32t · Bottom bracket: FSA MegaExo BSA 73 · Cassette: Single Speed 18t · Chain: KMC Z1
Brakes
Inspect the brakes →Archived: Brakes: Brake Calipers: Tektro HD-M280 2-piston; Front Brake Rotor: Tektro 180mm 6B 1.8mm; Rear Brake Rotor: Tektro 160mm 6B 1.8mm; Brake Levers: Tektro M280
Wheels and tires
Check wheels and tires →Archived: Wheel size: 29" · Rims: WTB ST i30 · Hubs: (F) Formula 15x110mm / (R) Formula 12x148mm HG · Front tire: WTB GROOV-E 29x2.25" · Rear tire: WTB GROOV-E 29x2.25"
Controls and contact points
Archived: Headset: FSA No.10 ZS44/ZS44 · Handlebar: Kona 31.8mm / Back 17º / Up 7º / Rise 80mm / Width 820mm · Stem: Kona 31.8mm / Rise 0º / Length 45mm · Seatpost: Kona Thumb w/Offset 27.2mm / Length S-M 350mm / L-XL 375mm · Saddle: WTB Comfort · Pedals: Kona JS2
Before and during the test ride
Follow the full used-bike inspection order →Build relationships are limited to the archived manufacturer specifications. Confirm exact fit and standards before ordering parts or performing service.
