Lowest0.65:1
Highest4.00:1
Total range618%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 29×2.1; rear size isn’t listed.
Velopedia Bicycle Archive
2009 Kona Big Kahuna
Original specifications: Shimano Deore drivetrain · 29" wheels.
Planning to sell? Draft your listing
At a glance
Archive #16942- Model year
- 2009
- Category
- Mountain
- Original MSRP
- $1,499.00
- Sizes
- 16", 18", 19", 20", 22"
- Colors
- Brown Metallic/Pearl White
- In this record
- 26 specifications · archived image · original MSRP
Model history 6 other years
Browse other years
Compare side by side
Identification clues
2009 archived details
- Published colors
- Brown Metallic/Pearl White
- Frame
- Kona Race Light 7005 Aluminum Butted
- Original equipment
- Shimano Deore
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildKona Race Light 7005 Aluminum Butted · Shimano Deore · 29" wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Kona Race Light 7005 Aluminum Butted |
| Fork | RockShox Tora Race 29er, 80mm travel |
| Fork Material | Single |
Drivetrain
| Component Group | Shimano Deore |
|---|---|
| Shifters | Shimano Deore RapidFire |
| Front Derailleur | Shimano Deore |
| Rear Derailleur | Shimano XT Shadow |
| Crankset | Shimano SLX, 22/32/44 teeth |
| Bottom Bracket | Shimano SLX Hollowtech II |
| BB Shell Width | 73mm |
| Cassette | Shimano Deore |
| Rear Cogs | 9-speed, 11 - 34 teeth |
| Chain | Shimano Deore |
| Pedals | Shimano M520 |
Brakes
| Brakes | Shimano M575 disc brakes, Shimano M575 Hydraulic levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" TH |
|---|---|
| Handlebar | Kona XC/BC Deluxe riser |
| Handlebar Extensions | Not included |
| Stem | Kona XC/BC Deluxe |
| Saddle | WTB Rocket V Comp |
| Seatpost | Kona XC/BC Deluxe |
Wheels & Tires
| Hubs | Front: Formula disc, Rear: Shimano M525 disc |
|---|---|
| Rims | Sun EQ 2.3SL |
| Front Tire | 29 x 2.10" Maxxis Ignitor |
| Wheel Size | 29" wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
29 x 2.10" Maxxis Ignitor
Retailer offers
Schwalbe RapidRob Performance 29in Tire Black, Clincher/Wire, 29x2.1
Replacement option
Maxxis Ignitor on eBaySponsored links
Shimano Deore
Shimano SLX Hollowtech II
More parts (6)Fewer parts
Shimano M520
WTB Rocket V Comp
Shimano SLX
22/32/44 teeth
Shimano Deore
Shimano XT Shadow
Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.
Shimano Deore RapidFire
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 29 x 2.10" Maxxis Ignitor
- Drivetrain
- 9-speed
- Bottom bracket / shell
- Shimano SLX Hollowtech II · 73mm
Equipment inspection checks 11 checks based on 6 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: RockShox Tora Race 29er, 80mm travel · Single
Suspension
Evaluate the suspension →Archived: Fork: RockShox Tora Race 29er, 80mm travel
Drivetrain
Check drivetrain wear →Archived: Group: Shimano Deore · Shifters: Shimano Deore RapidFire · Front derailleur: Shimano Deore · Rear derailleur: Shimano XT Shadow · Crankset: Shimano SLX, 22/32/44 teeth · Bottom bracket: Shimano SLX Hollowtech II · Cassette: Shimano Deore · Rear cogs: 9-speed, 11 - 34 teeth · Chain: Shimano Deore
Brakes
Inspect the brakes →Archived: Brakes: Shimano M575 disc brakes, Shimano M575 Hydraulic levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 29" wheels · Rims: Sun EQ 2.3SL · Hubs: Front: Formula disc, Rear: Shimano M525 disc · Front tire: 29 x 2.10" Maxxis Ignitor
Controls and contact points
Archived: Headset: 1 1/8" TH · Handlebar: Kona XC/BC Deluxe riser · Stem: Kona XC/BC Deluxe · Seatpost: Kona XC/BC Deluxe · Saddle: WTB Rocket V Comp · Pedals: Shimano M520
