Velopedia Bicycle Archive

2009 Kona Africa Bike Three

Original specifications: Cruiser Mix drivetrain · 26" wheels.

Share owner experience

At a glance

Archive #16980

Model year: 2009
Category: Cruiser
Original MSRP: $449.00
Sizes: One size fits all
Colors: Matte Black
In this record: 25 specifications · archived image · original MSRP

Original buildKona Cromoly · Cruiser Mix · 26" wheels

Historical catalog variants

Archived sizes and colors

1 item record

Item-level catalog entries recovered from Velopedia’s original bicycle archive. They document how this model was listed historically; they do not identify the frame size associated with legacy reference geometry or indicate current availability.

Published sizes

one size fits all

Published colors

Matte Black

View 1 archived size/color combination

Size	Color
one size fits all	Matte Black

Historical catalog evidence. Exact specifications and naming may vary by market, production run or manufacturer revision.

Frameset

Frame Construction	TIG-welded
Frame Material	Kona Cromoly
Fork	Kona P2
Fork Material	Unicrown

Drivetrain

Component Group	Cruiser Mix
Shifters	Shimano
Crankset	Pro Wheel, 36 teeth
Bottom Bracket	Ch
BB Shell Width	68mm
Cassette	Shimano
Rear Cogs	3-speed internal, 16 teeth
Chain	KMC Z410
Pedals	Xerama SP-102

Brakes

Brakes	Tektro 849AL brakes, Tektro TS 384A levers

Cockpit & Contact Points

Headset	Ch
Handlebar	Kona Riser
Handlebar Extensions	Not included
Stem	Kona Cruiser
Saddle	Viscount
Seatpost	Kona Thumb

Wheels & Tires

Hubs	Front: Formula, Rear: Shimano 3 speed coaster brake
Rims	Rigida Cyber 10
Spokes	Stainless, 14ga. (2.0mm)
Front Tire	26 x 1.75" Continental Town Ride
Wheel Size	26" wheels

Gearing

Original gearing is incomplete. Enter your setup to calculate ratios and cadence speeds.

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Gears Drivetrain

Front teeth Smallest rear teeth Largest rear teeth

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Rear tire marking

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

Rim diameter (BSD, mm) Tire width (mm)

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Cadence (RPM) Speed units

Gear, dimension and cadence changes update results automatically.

Gearing comparison
Measure	Original	Your setup
Lowest ratio	—	—
Highest ratio	—	—
Total range	—	—
Lowest-gear speed	—	—
Highest-gear speed	—	—

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Front tire · Original

26 x 1.75" Continental Town Ride

Search Amazon Search eBay

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire: 26 x 1.75" Continental Town Ride
Drivetrain: 3-speed
Bottom bracket / shell: CH · 68mm
