Lowest1.22:1
Highest3.55:1
Total range291%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 26×1.75; rear size isn’t listed.
Velopedia Bicycle Archive
2006 KHS Tandemania Alite
Original specifications: Shimano Deore XT drivetrain · 26" wheels.
Planning to sell? Draft your listing
No archive photo is available for this record.
At a glance
Archive #10823- Model year
- 2006
- Category
- Tandem
- Original MSRP
- $1,249.00
- Sizes
- 17" x 15", 20" x 16"
- Colors
- Flat blue
- In this record
- 26 specifications · original MSRP
Model history 11 other years
Browse other years
Compare side by side
Identification clues
2006 archived details
- Published colors
- Flat blue
- Frame
- 6061 aluminum
- Original equipment
- Shimano Deore XT
Clues, not proof of model year. Colors vary and components may have been replaced.
Original build6061 aluminum · Shimano Deore XT · 26" wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 6061 aluminum |
| Fork | Khs |
| Fork Material | Chromoly, unicrown crown |
Drivetrain
| Component Group | Shimano Deore XT |
|---|---|
| Shifters | Shimano Revo SB-C055A |
| Front Derailleur | Shimano FD-C202 |
| Rear Derailleur | Shimano XT RD-M760 |
| Crankset | Truvativ FiveD, 48/38/28+39T teeth |
| Bottom Bracket | TH cartridge |
| BB Shell Width | 68mm English |
| Rear Cogs | 8-speed, 11 - 32 teeth |
| Chain | KMC Z51/ Z82, 1/2 x 3/32" |
| Pedals | VP-990A, Alloy |
Brakes
| Brakes | Power Tools linear pull brakes, Shimano Revo levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless VP-71 |
|---|---|
| Handlebar | Alloy |
| Stem | Captain: Alloy Stoker: Alloy, adjustable |
| Saddle | Captain: KHS Padded Stoker: KHS Padded |
| Seatpost | Captain: Kalloy Micro Adj.; Stoker: Alloy Suspension |
Wheels & Tires
| Hubs | Front: Alloy, Rear: Shimano HF08 tandem |
|---|---|
| Rims | Weinmann ZAC-19 doublewall, 40-hole |
| Spokes | Stainless steel, 14ga. (2.0mm) straight gauge |
| Spoke Nipples | Brass nipples |
| Front Tire | 26 x 1.75" KHS |
| Wheel Size | 26" wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
26 x 1.75" KHS
Replacement search: 26x1.75 bicycle tire Before ordering: Check rim type and tire clearance.
Power Tools linear pull brakes
Shimano Revo levers
More parts (3)Fewer parts
Shimano Revo SB-C055A
Captain: Kalloy Micro Adj.
Stoker: Alloy Suspension
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 26 x 1.75" KHS
- Drivetrain
- 8-speed
- Bottom bracket / shell
- TH cartridge · 68mm English
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: KHS · Chromoly, unicrown crown
Drivetrain
Check drivetrain wear →Archived: Group: Shimano Deore XT · Shifters: Shimano Revo SB-C055A · Front derailleur: Shimano FD-C202 · Rear derailleur: Shimano XT RD-M760 · Crankset: Truvativ FiveD, 48/38/28+39T teeth · Bottom bracket: TH cartridge · Rear cogs: 8-speed, 11 - 32 teeth · Chain: KMC Z51/ Z82, 1/2 x 3/32"
Brakes
Inspect the brakes →Archived: Brakes: Power Tools linear pull brakes, Shimano Revo levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 26" wheels · Rims: Weinmann ZAC-19 doublewall, 40-hole · Hubs: Front: Alloy, Rear: Shimano HF08 tandem · Front tire: 26 x 1.75" KHS
Controls and contact points
Archived: Headset: 1 1/8" threadless VP-71 · Handlebar: Alloy · Stem: Captain: Alloy Stoker: Alloy, adjustable · Seatpost: Captain: Kalloy Micro Adj.; Stoker: Alloy Suspension · Saddle: Captain: KHS Padded Stoker: KHS Padded · Pedals: VP-990A, Alloy
Have you owned this model?Help document firsthand fit, ride and maintenance details that may no longer be available.
This archive record has limited published detail. Share what would help another rider understand how this model fit, rode and held up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
