Lowest0.65:1
Highest4.00:1
Total range618%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 26×2.1; rear size isn’t listed.
Velopedia Bicycle Archive
2006 KHS Alite 4000
Original specifications: SRAM X0 · 9-speed · mechanical rear derailleur · 26" wheels.
Planning to sell? Draft your listing
At a glance
Archive #10798- Model year
- 2006
- Category
- Mountain
- Sizes
- 15", 17", 19", 21"
- Colors
- Team satin silver
- In this record
- 24 specifications · archived image
Model history 6 other years
Browse other years
Compare side by side
Identification clues
2006 archived details
- Published colors
- Team satin silver
- Frame
- DB Alloy AN6 Super Lite
- Original equipment
- SRAM X.0/mix
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildDB Alloy AN6 Super Lite · SRAM X.0/mix · 26" wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | DB Alloy AN6 Super Lite |
| Fork | RockShox SID Team, 80mm |
Drivetrain
| Component Group | SRAM X.0/mix |
|---|---|
| Shifters | Sram X.0 |
| Front Derailleur | Shimano Deore LX FD-M760L6 |
| Rear Derailleur | Sram X.0 |
| Crankset | Truvativ Stylo, 44/32/22 teeth |
| Bottom Bracket | TruVativ GXP |
| BB Shell Width | 68mm English |
| Rear Cogs | 9-speed, 11 - 34 teeth |
| Chain | SRAM PC-971, 1/2 X 3/32" |
Brakes
| Brakes | Avid Juicy 7 hydraulic disc, Ø 6" rotors brakes, Avid Juicy 7 levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" integrated FSA Orbit DL |
|---|---|
| Handlebar | Carbon, Gigantex HR018-660 L Ø31.8 riser |
| Stem | HL TDS-D298-B8CF(FOV), carbon wrapped Ø31.8 |
| Saddle | WTB Shadow V Stealth |
| Seatpost | Q2 |
Wheels & Tires
| Hubs | Sun XC Flea disc |
|---|---|
| Rims | Sun XC Flea, disc specific, 28-hole/32-hole |
| Spokes | DT Swiss stainless steel, 14/15ga. (2.0/1.8mm) butted |
| Spoke Nipples | Alloy niples |
| Front Tire | 26 x 2.10" John Tomac Nevegal 120TPI, kevlar bead |
| Wheel Size | 26" wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
SRAM PC-971
1/2 x 3/32"
Retailer offers
SRAM PC 971 Chain - 9-Speed Power link/Gold, 114 Links
Model match
SRAM PC-971 on eBaySponsored links
26 x 2.10" John Tomac Nevegal 120TPI
kevlar bead
Replacement search: 26x2.1 bicycle tire Before ordering: Check rim type and tire clearance.
WTB Shadow V Stealth
More parts (4)Fewer parts
Shimano Deore LX FD-M760L6
Sram X.0
Sram X.0
1 1/8" integrated FSA Orbit DL
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 26 x 2.10" John Tomac Nevegal 120TPI, kevlar bead
- Drivetrain
- 9-speed
- Bottom bracket / shell
- TruVativ GXP · 68mm English
Equipment inspection checks 11 checks based on 6 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: RockShox SID Team, 80mm
Suspension
Evaluate the suspension →Archived: Fork: RockShox SID Team, 80mm
Drivetrain
Check drivetrain wear →Archived: Group: SRAM X.0/mix · Shifters: Sram X.0 · Front derailleur: Shimano Deore LX FD-M760L6 · Rear derailleur: Sram X.0 · Crankset: Truvativ Stylo, 44/32/22 teeth · Bottom bracket: TruVativ GXP · Rear cogs: 9-speed, 11 - 34 teeth · Chain: SRAM PC-971, 1/2 x 3/32"
Brakes
Inspect the brakes →Archived: Brakes: Avid Juicy 7 hydraulic disc, Ø 6" rotors brakes, Avid Juicy 7 levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 26" wheels · Rims: Sun XC Flea, disc specific, 28-hole/32-hole · Hubs: Sun XC Flea disc · Front tire: 26 x 2.10" John Tomac Nevegal 120TPI, kevlar bead
Controls and contact points
Archived: Headset: 1 1/8" integrated FSA Orbit DL · Handlebar: Carbon, Gigantex HR018-660 L Ø31.8 riser · Stem: HL TDS-D298-B8CF(FOV), carbon wrapped Ø31.8 · Seatpost: Q2 · Saddle: WTB Shadow V Stealth
Have you owned this model?Help document firsthand fit, ride and maintenance details that may no longer be available.
This archive record has limited published detail. Share what would help another rider understand how this model fit, rode and held up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
Checking current listings…
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
