Lowest1.70:1
Highest4.82:1
Total range284%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 700C×23; rear size isn’t listed.
Velopedia Bicycle Archive
2003 K2 Mod 5.0
Original specifications: Shimano Dura-Ace drivetrain · 700c wheels.
Planning to sell? Draft your listing
At a glance
Archive #38791- Model year
- 2003
- Category
- Road
- Original MSRP
- $3,600.00
- Sizes
- XS, S, M, L
- Colors
- Gray/Electric Blue
- In this record
- 27 specifications · archived image · original MSRP
Model history 4 other years
Browse other years
Compare side by side
Identification clues
2003 archived details
- Published colors
- Gray/Electric Blue
- Frame
- Columbus Airplane, carbon stays
- Original equipment
- Shimano Dura-Ace
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildColumbus Airplane, carbon stays · Shimano Dura-Ace · 700c wheels
Frameset
| Frame Construction | TIG-welded/carbon fiber composite |
|---|---|
| Frame Material | Columbus Airplane, carbon stays |
| Fork | Columbus Carve |
| Fork Material | Carbon fiber composite w/carbon fiber steerer, aero crown |
Drivetrain
| Component Group | Shimano Dura-Ace |
|---|---|
| Shifters | Shimano Dura-Ace STI Dual Control |
| Front Derailleur | Shimano Dura-Ace |
| Rear Derailleur | Shimano Dura-Ace |
| Crankset | Shimano Dura-Ace, 39/53 teeth |
| Bottom Bracket | Shimano BB-7700, 109.5mm spindle |
| BB Shell Width | 68mm English |
| Rear Cogs | 9-speed, 11 - 23 teeth |
| Chain | Shimano CN-7700, 1/2 x 3/32" |
| Pedals | Not included |
Brakes
| Brakes | Shimano Dura-Ace Dual Pivot brakes, Shimano Dura-Ace STI Dual Control levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless Cane Creek IS-2 integrated |
|---|---|
| Handlebar | 3T Zepp XL |
| Handlebar Extensions | Not included |
| Stem | 3T Zepp XL |
| Saddle | Selle Italia SLR XP |
| Seatpost | Easton EC70 |
Wheels & Tires
| Hubs | Mavic Ksyrium SSC |
|---|---|
| Rims | Mavic Ksyrium SSC SL, 18-hole/20-hole |
| Spokes | Mavic Zicral, aero |
| Spoke Nipples | Aluminum nipples |
| Front Tire | 700 x 23c Vittoria Open Corsa CX |
| Wheel Size | 700c wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
700 x 23c Vittoria Open Corsa CX
Retailer offers
Vittoria Rubino Pro G2.0 Clincher Tire Black, 700x23
700x23c
Replacement option
Vittoria Open Corsa CX on eBaySponsored links
Shimano BB-7700
109.5mm spindle
More parts (8)Fewer parts
Selle Italia SLR XP
Shimano Dura-Ace
39/53 teeth
Shimano Dura-Ace
Shimano Dura-Ace
Shimano Dura-Ace STI Dual Control
Easton EC70
1 1/8" threadless Cane Creek IS-2 integrated
Mavic Ksyrium SSC
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 700 x 23c Vittoria Open Corsa CX
- Drivetrain
- 9-speed
- Bottom bracket / shell
- Shimano BB-7700, 109.5mm spindle · 68mm English
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded/carbon fiber composite · Fork: Columbus Carve · Carbon fiber composite w/carbon fiber steerer, aero crown
Drivetrain
Check drivetrain wear →Archived: Group: Shimano Dura-Ace · Shifters: Shimano Dura-Ace STI Dual Control · Front derailleur: Shimano Dura-Ace · Rear derailleur: Shimano Dura-Ace · Crankset: Shimano Dura-Ace, 39/53 teeth · Bottom bracket: Shimano BB-7700, 109.5mm spindle · Rear cogs: 9-speed, 11 - 23 teeth · Chain: Shimano CN-7700, 1/2 x 3/32"
Brakes
Inspect the brakes →Archived: Brakes: Shimano Dura-Ace Dual Pivot brakes, Shimano Dura-Ace STI Dual Control levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700c wheels · Rims: Mavic Ksyrium SSC SL, 18-hole/20-hole · Hubs: Mavic Ksyrium SSC · Front tire: 700 x 23c Vittoria Open Corsa CX
Controls and contact points
Archived: Headset: 1 1/8" threadless Cane Creek IS-2 integrated · Handlebar: 3T Zepp XL · Stem: 3T Zepp XL · Seatpost: Easton EC70 · Saddle: Selle Italia SLR XP · Pedals: Not included
Have you owned this model?Help document firsthand fit, ride and maintenance details that may no longer be available.
This archive record has limited published detail. Share what would help another rider understand how this model fit, rode and held up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
No recent price sample is available for this bike. Check eBay for matching listings.
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
