2008 Jamis Sputnik

Original specifications: Track Mix drivetrain · 700c wheels · 16.75 lb published weight.

Share owner experience

At a glance

Archive #24582

Model year: 2008
Category: Track
Original MSRP: $700.00
Sizes: 50cm, 53cm, 55cm, 57cm, 59cm, 62cm
Colors: Ano Black
Weight: 16.75 lb
In this record: 21 specifications · archived image · original MSRP

Model history 6 other years

Browse other years

Compare side by side

Identification clues

2008 archived details

Published colors: Ano Black
Frame: Reynolds 631 chromoly
Original equipment: Track Mix

Clues, not proof of model year. Colors vary and components may have been replaced.

Original buildReynolds 631 chromoly · Track Mix · 700c wheels

Historical catalog variants

Archived sizes and colors

6 item records

Item-level catalog entries recovered from Velopedia’s original bicycle archive. They document how this model was listed historically; they do not identify the frame size associated with legacy reference geometry or indicate current availability.

Published sizes

50cm53cm55cm57cm59cm62cm

Published colors

Ano Black

View 6 archived size/color combinations

Size	Color
50cm	Ano Black
53cm	Ano Black
55cm	Ano Black
57cm	Ano Black
59cm	Ano Black
62cm	Ano Black

Historical catalog evidence. Exact specifications and naming may vary by market, production run or manufacturer revision.

Frameset

Frame Construction	TIG-welded
Frame Material	Reynolds 631 chromoly
Fork	Jamis
Fork Material	Carbon/carbon steerer, aero crown

Drivetrain

Component Group	Track Mix
Crankset	FSA Vero, 46 teeth
Bottom Bracket	FSA Powerdrive, 113mm spindle
BB Shell Width	68mm English
Cassette	Formula SS
Rear Cogs	1-speed, 16 teeth
Chain	KMC Z510H, 1/2 x 1/8"
Pedals	Not included

Cockpit & Contact Points

Headset	1 1/8" threadless Aheadset
Handlebar	Ritchey Comp Road
Stem	Ritchey Comp Road
Saddle	Selle San Marco Ponza Lux
Seatpost	Ritchey Road Comp, 27.2mm diameter

Wheels & Tires

Hubs	Front: Formula Alloy Track, Rear: Formula Track, Flip-flop
Rims	Alex DA22
Front Tire	700 x 23c Vittoria Zaffiro
Wheel Size	700c wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

Pedal cadence

RPM

Speed units

RPM = pedal turns per minute.

All published sizes46T · 16T · 1-speed

Ratio2.88:1

Estimated speed At 90 RPM Gear20.2 mph

Uses front tire 700C×23; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Gears Drivetrain

Front teeth Smallest rear teeth Largest rear teeth

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Rear tire marking

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

Rim diameter (BSD, mm) Tire width (mm)

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Cadence (RPM) Speed units

Gear, dimension and cadence changes update results automatically.

Gearing comparison
Measure	Original	Your setup
Lowest ratio	—	—
Highest ratio	—	—
Total range	—	—
Lowest-gear speed	—	—
Highest-gear speed	—	—

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Front tire · Original

700 x 23c Vittoria Zaffiro

Search Amazon Search eBay

Retailer offers

Vittoria Rubino Pro G2.0 Clincher Tire Black, 700x23

700x23c

Replacement option

Competitive Cyclist ↗$41.10

Stem · Original

Ritchey Comp Road

Search eBay

Retailer offers

Ritchey Comp 4-Axis 30D Stem Black, 70mm, -30 deg

Model match

Competitive Cyclist ↗$48.35

Seatpost · Original

Ritchey Road Comp

27.2mm diameter

Search eBay

Retailer offers

Ritchey Comp 2-Bolt Seatpost Black, 27.2x400mm

Model match

Competitive Cyclist ↗$59.95

Backcountry ↗$59.95

More parts (4)Fewer parts

Bottom bracket · Original

FSA Powerdrive

113mm spindle

Search Amazon Search eBay

Crankset · Original

FSA Vero

46 teeth

Search eBay

Handlebar · Original

Ritchey Comp Road

Search eBay

Rims · Original

Alex DA22

Search eBay

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire: 700 x 23c Vittoria Zaffiro
Drivetrain: 1-speed
Seatpost diameter: 27.2 mm
Bottom bracket / shell: FSA Powerdrive, 113mm spindle · 68mm English

Equipment inspection checks 9 checks based on 4 archived component groups Open equipment checksClose equipment checks

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Frame and fork

Inspect the frame and fork →

Archived: Frame: TIG-welded · Fork: Jamis · Carbon/carbon steerer, aero crown

Check paint damage, vent holes and accessible internal surfaces for corrosion. Look for dents, bent tubes and cracking around welded or brazed joints.
Inspect the fork crown, blades, dropouts and visible steerer area. Check that it is straight, securely installed and free of cracks or impact damage.

Drivetrain

Check drivetrain wear →

Archived: Group: Track Mix · Crankset: FSA Vero, 46 teeth · Bottom bracket: FSA Powerdrive, 113mm spindle · Cassette: Formula SS · Rear cogs: 1-speed, 16 teeth · Chain: KMC Z510H, 1/2 x 1/8"

Check chain tension and chainline, rotate the drivetrain through a full revolution and confirm the rear axle or tensioning hardware cannot slip.
Measure chain wear with a compatible gauge and inspect chainring, cassette or freewheel teeth. A new chain does not rule out wear in the remaining drivetrain.
Turn the cranks slowly, feel for rough bearings and check for side-to-side play. Inspect crank arms, chainring bolts and pedal threads for looseness or damage.

Wheels and tires

Check wheels and tires →

Archived: Wheel size: 700c wheels · Rims: Alex DA22 · Hubs: Front: Formula Alloy Track, Rear: Formula Track, Flip-flop · Front tire: 700 x 23c Vittoria Zaffiro

Spin both wheels and watch for side-to-side and vertical movement. Check spoke tension, rim condition and hub play.
Inspect both tire casings for cuts, cracking, plugs, bulges or exposed threads and confirm the installed sizes are safe for the rims and available frame and fork clearance.

Controls and contact points

Archived: Headset: 1 1/8" threadless Aheadset · Handlebar: Ritchey Comp Road · Stem: Ritchey Comp Road · Seatpost: Ritchey Road Comp, 27.2mm diameter · Saddle: Selle San Marco Ponza Lux · Pedals: Not included

Apply the front brake and rock the bike to check for headset play or notchiness. Inspect the stem, handlebar and clamp zones, then confirm every fastener and control is secure.
Check that the seatpost moves for adjustment and that the saddle, post and clamp hold securely without cracks, severe corrosion or damaged hardware.
