Velopedia Bicycle Archive
2005 Jamis Komodo FX 2.0
Mountain bike, front suspension bicycle from the Velopedia specification archive.
- Original MSRP
- $1,199.95
- Sizes
- 14", 16.5", 18.5"
- Colors
- Gray
- Weight
- 33.5
- Archive ID
- 93115
Current market
Checking current listings…Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 7005 aluminum |
| Fork | Manitou Stance Flow, 120 - 150mm adjustable travel |
| Fork Material | Aluminum/magnesium, single crown |
| Rear Shock | N/A |
Drivetrain
| Component Group | Mountain Mix |
|---|---|
| Shifters | Shimano Deore RapidFire |
| Front Derailleur | SRAM X.7, top-pull/clamp-on 31.8mm |
| Rear Derailleur | Shimano Deore |
| Crankset | TruVativ Hussefelt, 26/36 teeth |
| Bottom Bracket | TruVativ ISIS DH, 113mm spindle |
| BB Shell Width | 68mm English |
| Rear Cogs | 9-speed, 11 - 32 teeth |
| Chain | Shimano CN-HG73, 1/2 x 3/32" |
| Pedals | Aluminum platform |
Brakes
| Brakes | Hayes HFX-9 Hydraulic Disc brakes, Hayes levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless Aheadset SAS |
|---|---|
| Handlebar | TruVativ Hussefelt 31.8 |
| Handlebar Extensions | Not included |
| Stem | TruVativ Hussefelt |
| Saddle | WTB Power V |
| Seatpost | TruVativ XR Dual Clamp, 27.2mm diameter |
Wheels & Tires
| Hubs | Front: Formula, Rear: Shimano FH-M475 disc |
|---|---|
| Rims | WTB Dual Duty Free Ride, 32-hole |
| Spokes | WTB stainless steel, 14ga. (2.0mm) straight gauge |
| Spoke Nipples | Brass nipples |
| Front Tire | 26 x 2.30" Hutchinson Spider |
| Wheel Size | 26" wheels |
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
