Lowest0.86:1
Highest3.45:1
Total range403%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 700C×38; rear size isn’t listed.
Velopedia Bicycle Archive
1995 Jamis Citizen
Original specifications: Shimano Altus C90/AceraX drivetrain · 700c wheels · 27.5 lb published weight.
Planning to sell? Draft your listing
No archive photo is available for this record.
At a glance
Archive #29039- Model year
- 1995
- Category
- Hybrid
- Original MSRP
- $299.95
- Sizes
- 16", 17.5", 19.5", 21.5", womens 17.5"
- Colors
- Green, Royal Blue
- Weight
- 27.5 lb
- Geometry
- Legacy reference
- In this record
- 25 specifications · original MSRP · geometry
Model history 12 other years
Browse other years
Compare side by side
Identification clues
1995 archived details
- Published colors
- Green, Royal Blue
- Frame
- 4130 chromoly main triangle / hi-tensile steel rear stays
- Original equipment
- Shimano Altus C90/AceraX
Clues, not proof of model year. Colors vary and components may have been replaced.
Original build4130 chromoly main triangle / hi-tensile steel rear stays · Shimano Altus C90/AceraX · 700c wheels
Frameset
| Frame Construction | TIG-welded steel |
|---|---|
| Frame Material | 4130 chromoly main triangle / hi-tensile steel rear stays |
| Fork | Akisu |
| Fork Material | Hi-tensile steel, unicrown crown |
Drivetrain
| Component Group | Shimano Altus C90/AceraX |
|---|---|
| Shifters | Grip Shift MRX-100 |
| Front Derailleur | Shimano Altus C90, bottom-pull/bottom bracket mount |
| Rear Derailleur | Shimano AceraX |
| Crankset | Shimano Altus C90, 24/32/38 teeth |
| Rear Cogs | 7-speed, 11 - 28 teeth |
| Chain | KMC UG 50, 1/2 x 3/32" |
| Pedals | Wellgo LU-923 |
Brakes
| Brakes | Tektro 860-1 brakes, Tektro 365A levers |
|---|
Cockpit & Contact Points
| Headset | 1" YST |
|---|---|
| Handlebar | Jamis Bulge Bar |
| Handlebar Extensions | Not included |
| Stem | Jamis |
| Saddle | Jamis |
| Seatpost | Pillar, 26.6 mm diameter |
Wheels & Tires
| Hubs | Sovos cassette Q/R |
|---|---|
| Rims | Alloy, 36-hole |
| Spokes | Stainless steel, straight gauge |
| Spoke Nipples | Brass nipples |
| Front Tire | 700 x 38c Cheng Shin |
| Wheel Size | 700c wheels |
No specifications match. Try a component name or clear your search.
Geometry
Historical measurements. Frame size unknown.
Reference drawing
Size
Measurement
Measurement
—
Select an available measurement to locate it on the frame.
All geometry measurementsLegacy reference · 6 measurements
| Measurement | Legacy reference |
|---|---|
| Top tube | 525.8 mm |
| Head-tube angle | 72° |
| Seat-tube angle | 73.5° |
| Chainstay / rear center | 436.9 mm |
| Wheelbase | 1023.6 mm |
| Fork offset / rake | 50.8 mm |
Frame size not recorded.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
700 x 38c Cheng Shin
Replacement search: 700cx38 bicycle tire Before ordering: Check rim type and tire clearance.
Wellgo LU-923
Shimano Altus C90
24/32/38 teeth
More parts (1)Fewer parts
Pillar
26.6 mm diameter
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 700 x 38c Cheng Shin
- Drivetrain
- 7-speed
- Seatpost diameter
- 26.6 mm
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded steel · Fork: Akisu · Hi-tensile steel, unicrown crown
Drivetrain
Check drivetrain wear →Archived: Group: Shimano Altus C90/AceraX · Shifters: Grip Shift MRX-100 · Front derailleur: Shimano Altus C90, bottom-pull/bottom bracket mount · Rear derailleur: Shimano AceraX · Crankset: Shimano Altus C90, 24/32/38 teeth · Rear cogs: 7-speed, 11 - 28 teeth · Chain: KMC UG 50, 1/2 x 3/32"
Brakes
Inspect the brakes →Archived: Brakes: Tektro 860-1 brakes, Tektro 365A levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700c wheels · Rims: Alloy, 36-hole · Hubs: Sovos cassette Q/R · Front tire: 700 x 38c Cheng Shin
Controls and contact points
Archived: Headset: 1" YST · Handlebar: Jamis Bulge Bar · Stem: Jamis · Seatpost: Pillar, 26.6 mm diameter · Saddle: Jamis · Pedals: Wellgo LU-923
