2012 Haro Flightline Trail

Original specifications.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #2026745
Model year
2012
Category
Mountain
Sizes
15", 17", 19"
Colors
SG Euro Blue/SG Black
In this record
18 specifications · 6 archived images
Model history 2 other years

Browse other years

Compare side by side

Identification clues

2012 archived details

Published colors
SG Euro Blue/SG Black
Frame
6061 T-6 Alloy

Clues, not proof of model year. Colors vary and components may have been replaced.

Original build6061 T-6 Alloy

Manufacturer catalog

Published sizes and colors

3 sizes · 1 color

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

15"17"19"

Published colors

SG Euro Blue/SG Black

Frameset

Frame Material6061 T-6 Alloy
ForkSR Suntour XCR 100mm

Drivetrain

ShiftersShimano Acera
Front DerailleurShimano Acera
Rear DerailleurShimano Alivio
CranksetShimano Acera 44/32/22t
Bottom Bracketsealed cartridge
CassetteShimano HG20 11-34t
ChainKMC HG-53
PedalsNylon ATB

Brakes

BrakesTektro Drako 6"

Cockpit & Contact Points

HeadsetRitchey Zero Press Fit
HandlebarPivit riser bar
StemPivit alloy
SaddleWTB Rocket V Comp
SeatpostPivit Alloy 30.9

Wheels & Tires

RimsWeinmann XM280
Front TireKenda Karma 26 X 2.0

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

All published sizes44/32/22T · 11–34T
Lowest0.65:1 Highest4.00:1 Total range618%

Speed unavailable: wheel or tire size is missing or unclear.

Add your rear tire size to calculate speed
How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Front tire · Original
Kenda Karma 26 X 2.0
Chain · Original
KMC HG-53
Cassette · Original
Shimano HG20 11-34t
More parts (2)Fewer parts
Saddle · Original
WTB Rocket V Comp
Crankset · Original
Shimano Acera 44/32/22t

Based on the original build. Check fit and installed parts before ordering.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
Kenda Karma 26 X 2.0
Bottom bracket / shell
sealed cartridge
Equipment inspection checks 11 checks based on 6 archived component groups Open equipment checksClose equipment checks
0 of 11 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: 6061 T-6 Alloy · Fork: SR Suntour XCR 100mm

Archived: Fork: SR Suntour XCR 100mm

Archived: Shifters: Shimano Acera · Front derailleur: Shimano Acera · Rear derailleur: Shimano Alivio · Crankset: Shimano Acera 44/32/22t · Bottom bracket: sealed cartridge · Cassette: Shimano HG20 11-34t · Chain: KMC HG-53

Archived: Brakes: Tektro Drako 6"

Archived: Rims: Weinmann XM280 · Front tire: Kenda Karma 26 X 2.0

Controls and contact points

Archived: Headset: Ritchey Zero Press Fit · Handlebar: Pivit riser bar · Stem: Pivit alloy · Seatpost: Pivit Alloy 30.9 · Saddle: WTB Rocket V Comp · Pedals: Nylon ATB
