Uses front tire 700C×28; rear size isn’t listed.
Velopedia Bicycle Archive
2011 Haro Projekt
Original specifications: Track Mix drivetrain · 700c wheels.
Planning to sell? Draft your listing
At a glance
Archive #22260- Model year
- 2011
- Category
- Track
- Sizes
- 49cm, 53cm, 57cm
- Colors
- SG Black Smurfy Blue
- In this record
- 23 specifications · 6 archived images
Model history 2 other years
Browse other years
Compare side by side
Identification clues
2011 archived details
- Published colors
- SG Black Smurfy Blue
- Frame
- Hi Ten
- Original equipment
- Track Mix
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildHi Ten · Track Mix · 700c wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Hi Ten |
| Fork | 700c full cromo |
| Fork Material | Unicrown |
Drivetrain
| Component Group | Track Mix |
|---|---|
| Crankset | Forged Alloy, 44T teeth |
| Bottom Bracket | Sealed |
| Cassette | Cog |
| Rear Cogs | 1-speed, 16 teeth |
| Chain | KMC Z410 |
| Pedals | Wellgo nylon body w/ alloy cage |
Brakes
| Brakes | Tektro dual pivot caliper brakes, Tektro alloy levers |
|---|
Cockpit & Contact Points
| Headset | Ritchey LB |
|---|---|
| Handlebar | One piece cromo bar |
| Handlebar Extensions | Not included |
| Stem | Pivit Alloy |
| Saddle | Haro Slim BMX |
| Seatpost | Steel, 27.2mm diameter |
Wheels & Tires
| Hubs | Alloy |
|---|---|
| Rims | Weinmann LP18, 32-hole |
| Spokes | Stainless, 14ga. (2.0mm) butted |
| Front Tire | 700 x 28c Kenda K193 |
| Wheel Size | 700c wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
27.2mm diameter
More parts (1)Fewer parts
Based on the original build. Check fit and installed parts before ordering.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 700 x 28c Kenda K193
- Drivetrain
- 1-speed
- Seatpost diameter
- 27.2 mm
- Bottom bracket / shell
- Sealed
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: 700c full cromo · Unicrown
Drivetrain
Check drivetrain wear →Archived: Group: Track Mix · Crankset: Forged Alloy, 44T teeth · Bottom bracket: Sealed · Cassette: Cog · Rear cogs: 1-speed, 16 teeth · Chain: KMC Z410
Brakes
Inspect the brakes →Archived: Brakes: Tektro dual pivot caliper brakes, Tektro alloy levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700c wheels · Rims: Weinmann LP18, 32-hole · Hubs: Alloy · Front tire: 700 x 28c Kenda K193
Controls and contact points
Archived: Headset: Ritchey LB · Handlebar: One piece cromo bar · Stem: Pivit Alloy · Seatpost: Steel, 27.2mm diameter · Saddle: Haro Slim BMX · Pedals: Wellgo nylon body w/ alloy cage
