2006 Haro F2

Original specifications: 20" wheels.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #11324
Model year
2006
Category
BMX
Colors
Chrome, Black, Absolut Red, Cat Yellow
In this record
22 specifications · archived image
Model history 6 other years

Browse other years

Compare side by side

Identification clues

2006 archived details

Published colors
Chrome, Black, Absolut Red, Cat Yellow
Frame
1-tube chromoly
Original equipment
N/A

Clues, not proof of model year. Colors vary and components may have been replaced.

Campaign
Original build1-tube chromoly · 20" wheels

Historical catalog variants

Archived sizes and colors

4 item records

Item-level catalog entries recovered from Velopedia’s original bicycle archive. They document how this model was listed historically; they do not identify the frame size associated with legacy reference geometry or indicate current availability.

Published colors

ChromeBlackAbsolut RedCat Yellow
View 4 archived size/color combinations
SizeColor
—Chrome
—Black
—Absolut Red
—Cat Yellow

Historical catalog evidence. Exact specifications and naming may vary by market, production run or manufacturer revision.

Frameset

Frame ConstructionTIG-welded
Frame Material1-tube chromoly
ForkHaro Straight Shooter
Fork MaterialSteel, unicrown crown

Drivetrain

CranksetChromoly three-piece, 44 teeth
Bottom BracketSealed mechanism
Rear Cogs1-speed, 16 teeth
ChainKMC Z410
PedalsHaro DX Alloy

Brakes

BrakesTektro U-Brake brakes, Tektro Alloy levers

Cockpit & Contact Points

Headset1 1/8" threadless TH Aheadset OS/SST Oryg
HandlebarHaro Street 7" 2.3
Handlebar ExtensionsNot included
StemHaro Alloy Clamp-On
SaddleHaro H-Crest
SeatpostHaro Steel, 25.4mm diameter

Wheels & Tires

Hubs14mm axle
RimsHaro Alloy Single Wall, 48-hole
Spokes14ga. (2.0mm) straight gauge
Spoke NipplesBrass nipples
Front Tire20 x 2.00" Haro MS4 2.0
Wheel Size20" wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

Published build44T · 16T · 1-speed
Ratio2.75:1
Estimated speed At 90 RPM Gear14.7 mph

Uses front tire 20×2; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications
Front tire · Original
20 x 2.00" Haro MS4 2.0 Replacement search: 20x2 bicycle tire Before ordering: Check rim type and tire clearance.
Seatpost · Original
Haro Steel

25.4mm diameter

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
20 x 2.00" Haro MS4 2.0
Drivetrain
1-speed
Seatpost diameter
25.4 mm
Bottom bracket / shell
Sealed mechanism
Campaign
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 10 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: Haro Straight Shooter · Steel, unicrown crown

Archived: Crankset: Chromoly three-piece, 44 teeth · Bottom bracket: Sealed mechanism · Rear cogs: 1-speed, 16 teeth · Chain: KMC Z410

Archived: Brakes: Tektro U-Brake brakes, Tektro Alloy levers

Archived: Wheel size: 20" wheels · Rims: Haro Alloy Single Wall, 48-hole · Hubs: 14mm axle · Front tire: 20 x 2.00" Haro MS4 2.0

Controls and contact points

Archived: Headset: 1 1/8" threadless TH Aheadset OS/SST Oryg · Handlebar: Haro Street 7" 2.3 · Stem: Haro Alloy Clamp-On · Seatpost: Haro Steel, 25.4mm diameter · Saddle: Haro H-Crest · Pedals: Haro DX Alloy
