Rear tire: 20×2.1.
Velopedia Bicycle Archive
At a glance
Archive #11299- Model year
- 2006
- Category
- BMX
- Colors
- Gloss Black, Absolut Red, SG Primer
- In this record
- 23 specifications · archived image
Model history 6 other years
Browse other years
Compare side by side
Identification clues
2006 archived details
- Published colors
- Gloss Black, Absolut Red, SG Primer
- Frame
- 3-tube chromoly
- Original equipment
- N/A
Clues, not proof of model year. Colors vary and components may have been replaced.
Original build3-tube chromoly · 20" wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 3-tube chromoly |
| Fork | Haro |
| Fork Material | Chromoly steerer, unicrown crown |
Drivetrain
| Crankset | Chromoly three-piece, 44 teeth |
|---|---|
| Bottom Bracket | Sealed |
| Rear Cogs | 1-speed, 16 teeth |
| Chain | KMC Z410 |
| Pedals | Haro DX Alloy |
Brakes
| Brakes | Tektro U-Brake rear brakes, Tektro Alloy rear levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless TH Aheadset OS/SST Oryg |
|---|---|
| Handlebar | Haro Street 7" Rise |
| Handlebar Extensions | Not included |
| Stem | Haro Alloy Clamp-On |
| Saddle | Haro Padded |
| Seatpost | Haro Steel, 25.4mm diameter |
Wheels & Tires
| Hubs | Aluminum |
|---|---|
| Rims | Haro Alloy Single Wall, 48-hole |
| Spokes | 14ga. (2.0mm) straight gauge |
| Spoke Nipples | Brass nipples |
| Front Tire | 20 x 2.25" Haro Catapult |
| Rear Tire | 20 x 2.10" Haro Catapult |
| Wheel Size | 20" wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
25.4mm diameter
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- Front: 20 x 2.25" Haro Catapult, Rear: 20 x 2.10" Haro Catapult
- Drivetrain
- 1-speed
- Seatpost diameter
- 25.4 mm
- Bottom bracket / shell
- Sealed
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Haro · Chromoly steerer, unicrown crown
Drivetrain
Check drivetrain wear →Archived: Crankset: Chromoly three-piece, 44 teeth · Bottom bracket: Sealed · Rear cogs: 1-speed, 16 teeth · Chain: KMC Z410
Brakes
Inspect the brakes →Archived: Brakes: Tektro U-Brake rear brakes, Tektro Alloy rear levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 20" wheels · Rims: Haro Alloy Single Wall, 48-hole · Hubs: Aluminum · Front tire: Front: 20 x 2.25" Haro Catapult, Rear: 20 x 2.10" Haro Catapult
Controls and contact points
Archived: Headset: 1 1/8" threadless TH Aheadset OS/SST Oryg · Handlebar: Haro Street 7" Rise · Stem: Haro Alloy Clamp-On · Seatpost: Haro Steel, 25.4mm diameter · Saddle: Haro Padded · Pedals: Haro DX Alloy
Have you owned this model?Help document firsthand fit, ride and maintenance details that may no longer be available.
This archive record has limited published detail. Share what would help another rider understand how this model fit, rode and held up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
No recent price sample is available for this bike. Check eBay for matching listings.
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
