2025 Giant Trinity Advanced SL Triathlon Frameset
Frame specifications: geometry for 4 published sizes.
Planning to sell? Draft your listing
At a glance
Archive #900001198- Model year
- 2025
- Category
- Road
- Original MSRP
- $6,000.00
- Sizes
- XS, S, M, L
- Colors
- Carbon/Chrome
- Geometry
- 4 manufacturer sizes
- In this record
- 7 specifications · 8 archived images · original MSRP · geometry
Frame specificationsCarbon Fiber
Frameset
| Frame Construction | Advanced SL-Grade Composite, 12x142mm thru-axle, disc |
|---|---|
| Frame Material | Carbon Fiber |
| Fork | Advanced SL-Grade Composite, full-composite steerer, 12x100mm thru-axle, disc |
| Fork Material | Carbon Fiber |
Cockpit & Contact Points
| Handlebar | AeroDrive base bar with Sync armrest set, 10 and 15-degree extension wedge |
|---|---|
| Stem | Giant base bar with integrated stem combination with Sync rest set, 10 and 15-degree extension wedge |
| Seatpost | Trinity Composite |
No specifications match. Try a component name or clear your search.
Geometry
Frame measurements by size.
Frame diagram
Select an available measurement to locate it on the frame.
All geometry measurements4 sizes · 16 measurements
| Measurement | XS | S | M | L |
|---|---|---|---|---|
| Seat tube | 477 mm | 508 mm | 538 mm | 565 mm |
| Top tube | 510 mm | 530 mm | 554 mm | 579 mm |
| Head tube | 85 mm | 105 mm | 125 mm | 145 mm |
| Head-tube angle | 72° | 73° | 73° | 73° |
| Seat-tube angle | 77° | 77° | 77° | 77° |
| Chainstay / rear center | 405 mm | 405 mm | 405 mm | 405 mm |
| Wheelbase | 974 mm | 988 mm | 1013 mm | 1039 mm |
| Bottom-bracket drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Reach | 397 mm | 412 mm | 432 mm | 452 mm |
| Stack | 490 mm | 513 mm | 532 mm | 551 mm |
| Standover height | 758 mm | 786 mm | 814 mm | 838 mm |
| Fork offset / rake | 40 mm | 40 mm | 40 mm | 40 mm |
| Trail | 69 mm | 63 mm | 63 mm | 63 mm |
| Crank length | 160 mm | 165 mm | 170 mm | 172.5 mm |
| Handlebar width | 400 mm | 400 mm | 400 mm | 400 mm |
| Wheel size | 700C | 700C | 700C | 700C |
Dimensions as recorded.
