Lowest0.94:1
Highest2.29:1
Total range243%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Rear tire: 20×1.95.
Velopedia Bicycle Archive
2024 Giant Talon 20 Lite
Original specifications: 9.7kg (21lbs 07oz) - Size (Reg.) published weight · geometry for 1 published size.
Planning to sell? Draft your listing
At a glance
Archive #900002073- Model year
- 2024
- Category
- Kids
- Original MSRP
- $480.00
- Sizes
- One Size
- Colors
- Eclipse, Snow Drift
- Weight
- 9.7kg (21lbs 07oz) - Size (Reg.)
- Geometry
- 1 manufacturer size
- In this record
- 21 specifications · 7 archived images · original MSRP · geometry
Model history 1 other year
Browse other years
Compare side by side
Identification clues
2024 archived details
- Published colors
- Eclipse, Snow Drift
- Frame
- Aluminum
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildAluminum
Frameset
| Frame Construction | ALUXX-grade aluminum |
|---|---|
| Frame Material | Aluminum |
| Fork | high-tensile steel, rigid |
| Fork Material | Steel |
Drivetrain
| Shifters | Shimano REVOSHIFT, 1x7 |
|---|---|
| Rear Derailleur | Shimano Tourney |
| Crankset | alloy, 32t, 140mm |
| Bottom Bracket | semi-cartridge |
| Cassette | 14x34 |
| Chain | KMC HV500 |
| Pedals | platform |
Brakes
| Brakes | alloy, linear pull |
|---|
Cockpit & Contact Points
| Handlebar | Giant Kids, alloy, 31.8mm, 10-degree rise, 60mm, custom taper design |
|---|---|
| Stem | forged alloy Ahead, 10-degree |
| Saddle | Explora Jr. |
| Seatpost | alloy, single-bolt, 27.2x250mm |
Wheels & Tires
| Hubs | nutted, 28h |
|---|---|
| Rims | Giant Kids 20", alloy |
| Spokes | stainless, 14g |
| Front Tire | Giant Junior Sport, 20x1.95", 22 tpi |
| Rear Tire | Giant Junior Sport, 20x1.95", 22 tpi |
No specifications match. Try a component name or clear your search.
Geometry
Frame measurements by size.
Reference drawing
Size
Measurement
Measurement
—
Select an available measurement to locate it on the frame.
All geometry measurements1 size · 17 measurements
| Measurement | One Size |
|---|---|
| Seat tube | 225 mm |
| Top tube | 450 mm |
| Head tube | 130 mm |
| Head-tube angle | 69° |
| Seat-tube angle | 72° |
| Chainstay / rear center | 375 mm |
| Wheelbase | 879.1 mm |
| Bottom-bracket drop | 30 mm |
| Reach | 306.2 mm |
| Stack | 442.6 mm |
| Standover height | 463.1 mm |
| Fork offset / rake | 38 mm |
| Trail | 58.3 mm |
| Crank length | 130 mm |
| Stem length | 60 mm |
| Handlebar width | 520 mm |
| Wheel size | 20" |
Dimensions as recorded.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
alloy
single-bolt, 27.2x250mm
Retailer offers
Race Face Ride XC Seatpost Black, 27.2x375mm
Replacement option
Giant Junior Sport
20x1.95", 22 tpi
Replacement search: 20x1.95 bicycle tire Before ordering: Check rim type and tire clearance.
alloy
linear pull
More parts (1)Fewer parts
Shimano Tourney
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- Giant Junior Sport, 20x1.95", 22 tpi
- Rear tire
- Giant Junior Sport, 20x1.95", 22 tpi
- Seatpost diameter
- 27.2 mm
- Bottom bracket / shell
- semi-cartridge
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: ALUXX-grade aluminum · Fork: high-tensile steel, rigid · Steel
Drivetrain
Check drivetrain wear →Archived: Shifters: Shimano REVOSHIFT, 1x7 · Rear derailleur: Shimano Tourney · Crankset: alloy, 32t, 140mm · Bottom bracket: semi-cartridge · Cassette: 14x34 · Chain: KMC HV500
Brakes
Inspect the brakes →Archived: Brakes: alloy, linear pull
Wheels and tires
Check wheels and tires →Archived: Rims: Giant Kids 20", alloy · Hubs: nutted, 28h · Front tire: Giant Junior Sport, 20x1.95", 22 tpi · Rear tire: Giant Junior Sport, 20x1.95", 22 tpi
Controls and contact points
Archived: Handlebar: Giant Kids, alloy, 31.8mm, 10-degree rise, 60mm, custom taper design · Stem: forged alloy Ahead, 10-degree · Seatpost: alloy, single-bolt, 27.2x250mm · Saddle: Explora Jr. · Pedals: platform
