Lowest0.94:1
Highest4.73:1
Total range504%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 700C×26; rear size isn’t listed.
Velopedia Bicycle Archive
2005 Fuji Absolute
Original specifications: Shimano Deore · 8-speed · mechanical rear derailleur · 700c wheels · 23.5 lb published weight.
Planning to sell? Draft your listing
At a glance
Archive #93361- Model year
- 2005
- Category
- Hybrid
- Sizes
- 15", 17", 19", 21", 23"
- Colors
- Steel Gray
- Weight
- 23.5 lb
- In this record
- 24 specifications · archived image
Model history 4 other years
Browse other years
Compare side by side
Identification clues
2005 archived details
- Published colors
- Steel Gray
- Frame
- Fuji Altair 2
- Original equipment
- Hybrid Mix
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildFuji Altair 2 · Hybrid Mix · 700c wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Fuji Altair 2 |
| Fork | Fuji |
| Fork Material | Aluminum/chrome-moly, aero crown |
Drivetrain
| Component Group | Hybrid Mix |
|---|---|
| Shifters | Shimano SL-R440 Flat Bar |
| Front Derailleur | Shimano FD-443, bottom-pull/clamp-on 31.8mm |
| Rear Derailleur | Shimano Deore |
| Crankset | TruVativ Isoflow, 30/42/52 teeth |
| Bottom Bracket | Sealed cartridge |
| BB Shell Width | 68mm English |
| Rear Cogs | 8-speed, 11 - 32 teeth |
| Chain | KMC Z72, 1/2 x 3/32" |
Brakes
| Brakes | Tektro 926 Mini V brakes, Tektro RT 354A front/Tektro RT354A rear levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" integrated |
|---|---|
| Handlebar | Aluminum |
| Stem | Adjustable/aluminum |
| Saddle | Fuji Sport |
| Seatpost | Aluminum micro-adjust |
Wheels & Tires
| Hubs | Formula aluminum, Q/R |
|---|---|
| Rims | Alex R-500 |
| Spokes | Stainless steel |
| Front Tire | 700 x 26c Kenda Kontender |
| Wheel Size | 700c wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
KMC Z72
1/2 x 3/32"
Retailer offers
SRAM PC-830 Chain One Color, 8 Speed
Replacement option
KMC Z72 on eBaySponsored links
700 x 26c Kenda Kontender
Retailer offers
Pirelli P7 Sport Clincher Tire Black, 700x26
700x26c
Replacement option
Kenda Kontender on eBaySponsored links
Tektro 926 Mini V brakes
Tektro RT 354A front/Tektro RT354A rear levers
More parts (3)Fewer parts
Shimano Deore
Alex R-500
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 700 x 26c Kenda Kontender
- Drivetrain
- 8-speed
- Bottom bracket / shell
- Sealed cartridge · 68mm English
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Fuji · Aluminum/chrome-moly, aero crown
Drivetrain
Check drivetrain wear →Archived: Group: Hybrid Mix · Shifters: Shimano SL-R440 Flat Bar · Front derailleur: Shimano FD-443, bottom-pull/clamp-on 31.8mm · Rear derailleur: Shimano Deore · Crankset: TruVativ Isoflow, 30/42/52 teeth · Bottom bracket: Sealed cartridge · Rear cogs: 8-speed, 11 - 32 teeth · Chain: KMC Z72, 1/2 x 3/32"
Brakes
Inspect the brakes →Archived: Brakes: Tektro 926 Mini V brakes, Tektro RT 354A front/Tektro RT354A rear levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700c wheels · Rims: Alex R-500 · Hubs: Formula aluminum, Q/R · Front tire: 700 x 26c Kenda Kontender
Controls and contact points
Archived: Headset: 1 1/8" integrated · Handlebar: Aluminum · Stem: Adjustable/aluminum · Seatpost: Aluminum micro-adjust · Saddle: Fuji Sport
