Velopedia Bicycle Archive

2005 Free Agent Speedway Jr.

Original specifications: 24" wheels.

Share owner experience

Planning to sell? Draft your listing

No archive photo is available for this record.

At a glance

Archive #93676
Model year
2005
Category
BMX
Original MSRP
$299.00
Sizes
Junior
Colors
Gloss White
In this record
22 specifications · original MSRP
Model history 7 other years

Browse other years

Compare side by side

Identification clues

2005 archived details

Published colors
Gloss White
Frame
7005 aluminum
Original equipment
N/A

Clues, not proof of model year. Colors vary and components may have been replaced.

Campaign
Original build7005 aluminum · 24" wheels

Manufacturer catalog

Published sizes and colors

1 size · 1 color

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

Junior

Published colors

Gloss White

Frameset

Frame ConstructionTIG-welded
Frame Material7005 aluminum
ForkFree Agent
Fork MaterialChromoly, unicrown crown

Drivetrain

CranksetAluminum, 42 teeth
Bottom BracketCartridge bearing
Rear Cogs1-speed, 16 teeth
ChainKMC Z510H, 1/2 x 1/8"
PedalsFree Agent aluminum platform

Brakes

BrakesTektro MV85L linear pull rear brakes, Tektro 316A rear levers

Cockpit & Contact Points

Headset1 1/8" threadless
HandlebarFree Agent aluminum
Handlebar ExtensionsNot included
StemAluminum
SaddleUni
SeatpostUni, 22.2mm (7/8 inch) diameter

Wheels & Tires

HubsAluminum, flip-flop
RimsSemi-aero aluminum, 28-hole
SpokesStainless steel, 15ga. (1.8mm) straight gauge
Spoke NipplesBrass nipples
Front Tire24 x 1 3/8" Tioga Comp X
Wheel Size24" wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

Published build42T · 16T · 1-speed
Ratio2.63:1

Speed unavailable: wheel or tire size is missing or unclear.

Add your rear tire size to calculate speed
How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications
Brake pads · Original
Tektro MV85L linear pull rear brakes

Tektro 316A rear levers

Search Amazon Search eBay
Seatpost · Original
Uni

22.2mm (7/8 inch) diameter

Search Amazon Search eBay

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
24 x 1 3/8" Tioga Comp X
Drivetrain
1-speed
Seatpost diameter
22.2 mm
Bottom bracket / shell
Cartridge bearing
Campaign
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 10 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Frame and fork

Inspect the frame and fork →

Archived: Frame: TIG-welded · Fork: Free Agent · Chromoly, unicrown crown

Drivetrain

Check drivetrain wear →

Archived: Crankset: Aluminum, 42 teeth · Bottom bracket: Cartridge bearing · Rear cogs: 1-speed, 16 teeth · Chain: KMC Z510H, 1/2 x 1/8"

Brakes

Inspect the brakes →

Archived: Brakes: Tektro MV85L linear pull rear brakes, Tektro 316A rear levers

Wheels and tires

Check wheels and tires →

Archived: Wheel size: 24" wheels · Rims: Semi-aero aluminum, 28-hole · Hubs: Aluminum, flip-flop · Front tire: 24 x 1 3/8" Tioga Comp X

Controls and contact points

Archived: Headset: 1 1/8" threadless · Handlebar: Free Agent aluminum · Stem: Aluminum · Seatpost: Uni, 22.2mm (7/8 inch) diameter · Saddle: Uni · Pedals: Free Agent aluminum platform
