Lowest1.06:1
Highest4.55:1
Total range428%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 700C×25; rear size isn’t listed.
Velopedia Bicycle Archive
2015 Felt Z100
Original specifications: Shimano Claris drivetrain · 700c wheels · 9.99kg, 22.0lb published weight.
Planning to sell? Draft your listing
No archive photo is available for this record.
At a glance
Archive #1465714- Model year
- 2015
- Category
- Road
- Original MSRP
- $799.00
- Sizes
- 51, 54, 56, 58, 61cm
- Colors
- Satin Black (White, Silver)
- Weight
- 9.99kg, 22.0lb
- In this record
- 24 specifications · original MSRP
Model history 6 other years
Browse other years
Compare side by side
Identification clues
2015 archived details
- Published colors
- Satin Black (White, Silver)
- Frame
- Aluminum
- Original equipment
- Shimano Claris
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildAluminum · Shimano Claris · 700c
Frameset
| Frame Construction | Felt Endurance Road FLite Custom Butted aluminum, Hydroform TIG-welded construction, threaded BB, replaceable rear derailleur hanger |
|---|---|
| Frame Material | Aluminum |
| Fork | Felt Endurance Road UHC Performance carbon fiber blades, ControlTaper 1.125" - 1.5" aluminum steer tube |
| Fork Material | Carbon Fiber/Aluminum |
Drivetrain
| Component Group | Shimano Claris |
|---|---|
| Shifters | Shimano Claris STI |
| Front Derailleur | Shimano Claris clamp-on, Ø31.8mm |
| Rear Derailleur | Shimano Claris short cage |
| Crankset | FSA Tempo 50/34T 51cm = 170mm 54 - 56cm = 172.5mm 58 - 61cm = 175mm |
| Bottom Bracket | FSA Square Tapered, 68 x 110.5mm |
| Rear Cogs | Shimano,11-32T |
| Chain | KMC 8-speed |
| Pedals | Superlight Road platform, toe clips & straps |
Brakes
| Brakes | Dual pivot caliper |
|---|
Cockpit & Contact Points
| Headset | FSA NO.38/42B, 1.125" - 1.5" sealed bearing w/ Felt VariableHeight Cone Spacers (20mm PC, 4.5mm aluminum), 1x 10mm + 2 x 5mm PC headset spacers, Felt top cap & aluminum bolt |
|---|---|
| Handlebar | Felt SuperLite Road VariableShape, 71mm reach, 118mm drop, Ø31.8mm 51cm = 400mm 54cm = 420mm 56 - 61cm = 440mm |
| Stem | Felt VariableAngle, +/- 8°/16° rise, Ø31.8mm 51cm = 80mm 54cm = 90mm 56cm = 100mm 58 - 61cm = 110mm |
| Saddle | Felt Endurance Road |
| Seatpost | Felt SuperLite Road, Ø27.2mm, 330mm length |
Wheels & Tires
| Hubs | Felt R3, sealed bearing, 28H, Felt R3, sealed cartridge bearing, 32H, 8-speed (11-speed compatible) |
|---|---|
| Rims | Felt Road RSL3 (tubeless ready), 22mm width, 24mm depth |
| Spokes | 2.0mm stainless steel |
| Front Tire | Felt All Weather, 700 x 25c |
| Wheel Size | 700c |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Felt All Weather
700 x 25c
Before ordering: Check rim compatibility and tire clearance.Retailer offers
Vittoria Rubino Pro G2.0 Tubeless Tire Black, 700x25
700x25c
Replacement option
Felt SuperLite Road
Ø27.2mm, 330mm length
Retailer offers
Race Face Ride XC Seatpost Black, 27.2x375mm
Replacement option
Shimano
11-32T
More parts (6)Fewer parts
FSA Square Tapered
68 x 110.5mm
FSA Tempo 50/34T 51cm = 170mm 54 - 56cm = 172.5mm 58 - 61cm = 175mm
Shimano Claris clamp-on
Ø31.8mm
Shimano Claris short cage
Shimano Claris STI
FSA NO.38/42B
1.125" - 1.5" sealed bearing w/ Felt VariableHeight Cone Spacers (20mm PC, 4.5mm aluminum), 1x 10mm + 2 x 5mm PC headset spacers, Felt top cap & aluminum bolt
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- Felt All Weather, 700 x 25c
- Drivetrain
- 8-speed
- Seatpost diameter
- 27.2 mm
- Bottom bracket / shell
- FSA Square Tapered, 68 x 110.5mm
Equipment inspection checks 11 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: Felt Endurance Road FLite Custom Butted aluminum, Hydroform TIG-welded construction, threaded BB, replaceable rear derailleur hanger · Fork: Felt Endurance Road UHC Performance carbon fiber blades, ControlTaper 1.125" - 1.5" aluminum steer tube · Carbon Fiber/Aluminum
Drivetrain
Check drivetrain wear →Archived: Group: Shimano Claris · Shifters: Shimano Claris STI · Front derailleur: Shimano Claris clamp-on, Ø31.8mm · Rear derailleur: Shimano Claris short cage · Crankset: FSA Tempo 50/34T 51cm = 170mm 54 - 56cm = 172.5mm 58 - 61cm = 175mm · Bottom bracket: FSA Square Tapered, 68 x 110.5mm · Rear cogs: Shimano,11-32T · Chain: KMC 8-speed
Brakes
Inspect the brakes →Archived: Brakes: Dual pivot caliper
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700c · Rims: Felt Road RSL3 (tubeless ready), 22mm width, 24mm depth · Hubs: Felt R3, sealed bearing, 28H, Felt R3, sealed cartridge bearing, 32H, 8-speed (11-speed compatible) · Front tire: Felt All Weather, 700 x 25c
Controls and contact points
Archived: Handlebar: Felt SuperLite Road VariableShape, 71mm reach, 118mm drop, Ø31.8mm 51cm = 400mm 54cm = 420mm 56 - 61cm = 440mm · Stem: Felt VariableAngle, +/- 8°/16° rise, Ø31.8mm 51cm = 80mm 54cm = 90mm 56cm = 100mm 58 - 61cm = 110mm · Seatpost: Felt SuperLite Road, Ø27.2mm, 330mm length · Saddle: Felt Endurance Road · Pedals: Superlight Road platform, toe clips & straps
Have you owned this model?Help document firsthand fit, ride and maintenance details that may no longer be available.
This archive record has limited published detail. Share what would help another rider understand how this model fit, rode and held up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
No recent price sample is available for this bike. Check eBay for matching listings.
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Same model · another year
Z100
Same model · another year
Z100
Same brand and year
AR FRD
