Ratio2.69:1
Estimated speed At 90 RPM
Gear
Uses front tire 20×1.95; rear size isn’t listed.
Velopedia Bicycle Archive
At a glance
Archive #11157- Model year
- 2006
- Category
- BMX
- In this record
- 21 specifications · archived image
Model history 2 other years
Browse other years
Compare side by side
Identification clues
2006 archived details
- Frame
- Hi-tensile steel
- Original equipment
- N/A
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildHi-tensile steel · 20" wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Hi-tensile steel |
| Fork | Eastern |
| Fork Material | High-tensile steel, unicrown crown |
Drivetrain
| Crankset | 3-piece chromoly, 43 teeth |
|---|---|
| Bottom Bracket | Loose ball |
| Rear Cogs | 1-speed, 16 teeth |
| Chain | KMC Z410 |
| Pedals | Wellgo DX Style |
Brakes
| Brakes | Tektro Alloy U-brake brakes, Tektro levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless steel |
|---|---|
| Handlebar | 2-piece |
| Stem | Aluminum threadless |
| Saddle | Eastern |
| Seatpost | Straight post |
Wheels & Tires
| Hubs | Front: steel, 14mm, Rear: steel, 14mm axle |
|---|---|
| Rims | Aluminum, 48-hole |
| Spokes | 14ga. (2.0mm) straight gauge |
| Spoke Nipples | Brass nipples |
| Front Tire | 20 x 1.95" Kenda Kovert |
| Wheel Size | 20" wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Wellgo DX Style
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 20 x 1.95" Kenda Kovert
- Drivetrain
- 1-speed
- Bottom bracket / shell
- Loose ball
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Eastern · High-tensile steel, unicrown crown
Drivetrain
Check drivetrain wear →Archived: Crankset: 3-piece chromoly, 43 teeth · Bottom bracket: Loose ball · Rear cogs: 1-speed, 16 teeth · Chain: KMC Z410
Brakes
Inspect the brakes →Archived: Brakes: Tektro Alloy U-brake brakes, Tektro levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 20" wheels · Rims: Aluminum, 48-hole · Hubs: Front: steel, 14mm, Rear: steel, 14mm axle · Front tire: 20 x 1.95" Kenda Kovert
Controls and contact points
Archived: Headset: 1 1/8" threadless steel · Handlebar: 2-piece · Stem: Aluminum threadless · Seatpost: Straight post · Saddle: Eastern · Pedals: Wellgo DX Style
Have you owned this model?Help document firsthand fit, ride and maintenance details that may no longer be available.
This archive record has limited published detail. Share what would help another rider understand how this model fit, rode and held up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
Checking current listings…
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
