2002 Diamondback Apex
Mountain bike, front suspension bicycle from the Velopedia specification archive.
- Original MSRP
- $879.99
- Sizes
- Large, medium, small, xsmall
- Colors
- Red/Blue
- Archive ID
- 91392
Current market
Checking current listings…Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 7005 aluminum w/replaceable derailleur hanger |
| Fork | Rock Shox Duke C, 3.0" travel |
| Fork Material | Aluminum, single triple-clamp crown |
| Rear Shock | N/A |
Drivetrain
| Component Group | Mountain Mix |
|---|---|
| Shifters | Shimano Deore RapidFire SL |
| Front Derailleur | Shimano Deore, top-pull/clamp-on 31.8mm |
| Rear Derailleur | Shimano Deore LX SGS |
| Crankset | Shimano Deore FC-M510S, 22/32/44 teeth |
| Bottom Bracket | Sealed cartridge, 111mm spindle |
| BB Shell Width | 68mm English |
| Rear Cogs | 9-speed, 11 - 32 teeth |
| Chain | KMC Z9000, 1/2 x 3/32" |
| Pedals | Wellgo WPD-823 clipless |
Brakes
| Brakes | ProMax forged linear-pull brakes, aluminum linear-pull levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" integrated Tien Hsin No.10 ZST |
|---|---|
| Handlebar | Titec Hell Bent XC |
| Handlebar Extensions | Not included |
| Stem | Titec Big AL |
| Saddle | WTB Speed V Comp |
| Seatpost | Aluminum micro-adjust, 27.2mm diameter |
Wheels & Tires
| Hubs | WTB Speed C2 |
|---|---|
| Rims | WTB SpeedMaster, 32-hole |
| Spokes | WTB stainless steel, 14ga. (2.0mm) straight gauge |
| Spoke Nipples | Alloy nipples |
| Front Tire | Front: 26 x 2.10" WTB PrimalRaptor, Rear: 26 x 1.95" WTB PrimalRaptor |
| Wheel Size | 26" wheels |
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
