Velopedia Bicycle Archive
2025 Commencal Absolut
Original manufacturer specifications including geometry for 4 published sizes.
Selling this bike? Create a shareable bike record
What Velopedia knows
- Model year
- 2025
- Category
- Mountain
- Original MSRP
- $1,500.00
- Sizes
- 24, S, M, L
- Colors
- Burgundy
- Geometry
- 4 manufacturer sizes · Geometry context
- Record coverage
- 19 preserved details · 8 archived images · original MSRP · preserved geometry
- Archive ID
- 900001430
Model history 1 other year
Frameset
| Frame Construction | ABSOLUT Al V4, ALLOY 6061, Triple Butted (T4, T6) |
|---|---|
| Frame Material | Aluminum |
| Fork | MANITOU Circus Expert, 100 mm travel, thru axle |
Drivetrain
| Crankset | PROWHEEL, 165 mm, BSA BB, Alloy |
|---|---|
| Bottom Bracket | BSA 73mm |
| Cassette | PROWHEEL, 30T, Steel, Black |
| Chain | KMC Z1, 84 links |
| Pedals | No |
Brakes
| Brakes | SRAM Level, Black, 1400 mm |
|---|
Cockpit & Contact Points
| Headset | ACROS ZS44/56, Sealed bearings with alloy cup |
|---|---|
| Handlebar | RIDE ALPHA R35, 760 mm width, 35 mm Rise |
| Stem | RIDE ALPHA 40 mm, Enduro 40 mm |
| Saddle | Ride Alpha |
| Seatpost | Ride Alpha, 31.6 mm, 250 mm |
Wheels & Tires
| Hubs | Rear: NOVATEC D256 - Front: NOVATEC DH61SB-HL, 32H |
|---|---|
| Rims | Alexrims FR30, 32H, 26" |
| Front Tire | MAXXIS DTH, 26" x 2.30 Clincher |
| Rear Tire | MAXXIS DTH, 26" x 2.30 Clincher |
Size-specific frame data
Geometry
Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.
| Measurement | 24 | S | M | L |
|---|---|---|---|---|
| Seat tube | 270 mm | 310 mm | 310 mm | 310 mm |
| Effective top tube | 516 mm | 577 mm | 597 mm | 622 mm |
| Head tube | 115 mm | 120 mm | 120 mm | 120 mm |
| Head-tube angle | 69° | 69° | 69° | 69° |
| Seat-tube angle | 72.5° | 72° | 72° | 72° |
| Chainstay / rear center | 365 mm | 390 mm | 390 mm | 390 mm |
| Wheelbase | 972 mm | 1037 mm | 1057 mm | 1082 mm |
| Bottom-bracket drop | 8 mm | 25 mm | 25 mm | 25 mm |
| Reach | 360 mm | 395 mm | 415 mm | 440 mm |
| Stack | 527 mm | 566 mm | 566 mm | 566 mm |
| Fork length / axle-to-crown | 460 mm | 470 mm | 470 mm | 470 mm |
Geometry source: Commencal first-party labeled geometry table ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.
Geometry tools
Analyze a published size
24 geometry
Archive context: Its stack of 527 mm sits toward the lower end. Its wheelbase of 972 mm sits toward the shorter end. The chainstay of 365 mm sits toward the shorter rear-center end.
Compared with 166 distinct mountain geometries in the XL-equivalent size cohort from model years 2023–2027 in the Velopedia archive.S geometry
Archive context: The chainstay of 390 mm sits toward the shorter rear-center end. Its wheelbase of 1037 mm sits toward the shorter end. Its stack of 566 mm sits toward the lower end.
Compared with 195 distinct mountain geometries in the Small-equivalent size cohort from model years 2023–2027 in the Velopedia archive.M geometry
Archive context: The chainstay of 390 mm sits toward the shorter rear-center end. Its stack of 566 mm sits toward the lower end. Its wheelbase of 1057 mm sits toward the shorter end.
Compared with 199 distinct mountain geometries in the Medium-equivalent size cohort from model years 2023–2027 in the Velopedia archive.L geometry
Archive context: Its stack of 566 mm sits toward the lower end. The chainstay of 390 mm sits toward the shorter rear-center end. Its wheelbase of 1082 mm sits toward the shorter end.
Compared with 193 distinct mountain geometries in the Large-equivalent size cohort from model years 2023–2027 in the Velopedia archive.Parts & serviceability
Find replacement parts
More qualified parts (1)
Searches use the archived manufacturer specification, not the components currently installed on a particular bicycle. Confirm the exact model, size and fit before ordering. As an Amazon Associate I earn from qualifying purchases. Velopedia may also earn from qualifying eBay purchases. Velopedia may also earn from qualifying retailer purchases. Commercial relationships do not influence Archive specifications or analysis.
Used-bike inspection
If you’re buying this bike used
Before any test ride: both brakes should stop the bike firmly and release cleanly; both wheels should run true and be securely attached; tires should have no casing damage; and the headset, handlebar, stem, cranks and pedals should have no looseness or play.
Follow the full used-bike inspection order →- FrameLook closely for dents and hairline cracks around welds, the head tube and bottom-bracket area. Cosmetic scratches matter less than a change in shape or a crack line.Inspect the frame and fork →
- BrakesTest each brake separately and confirm it stops firmly and releases cleanly. Inspect the pads and braking surfaces for wear or contamination, and check the cables or hoses for damage.Inspect the brakes →
- SuspensionAsk when the fork was last serviced. Check the stanchions for damage, look for oil at the seals and make sure the fork moves smoothly without bushing play.Evaluate the suspension →
- DrivetrainShift through the full range under light load, measure chain wear and inspect the cassette or freewheel teeth. Skipping or hesitation can indicate wear, poor adjustment or mismatched parts.Check drivetrain wear →
- Wheels & tiresSpin both wheels and watch the rims for side-to-side or vertical movement. Check for dents, cracks, loose or uneven spokes and hub play, then inspect both tire casings for cuts, cracking or exposed threads.Check wheels and tires →
Bike-specific inspection checklist 20 checks based on 6 archived component groups Open checklistClose checklist
This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.
Identity and fit
Follow the full used-bike inspection order →Archived: 2025 Commencal Absolut · Mountain · Published sizes: 24, S, M, L
Frame and fork
Inspect the frame and fork →Archived: Frame: ABSOLUT Al V4, ALLOY 6061, Triple Butted (T4, T6) · Fork: MANITOU Circus Expert, 100 mm travel, thru axle
Suspension
Evaluate the suspension →Archived: Fork: MANITOU Circus Expert, 100 mm travel, thru axle
Drivetrain
Check drivetrain wear →Archived: Crankset: PROWHEEL, 165 mm, BSA BB, Alloy · Bottom bracket: BSA 73mm · Cassette: PROWHEEL, 30T, Steel, Black · Chain: KMC Z1, 84 links
Brakes
Inspect the brakes →Archived: Brakes: SRAM Level, Black, 1400 mm
Wheels and tires
Check wheels and tires →Archived: Rims: ALEXRIMS FR30, 32H, 26" · Hubs: Rear: NOVATEC D256 - Front: NOVATEC DH61SB-HL, 32H · Front tire: MAXXIS DTH, 26" x 2.30 Clincher · Rear tire: MAXXIS DTH, 26" x 2.30 Clincher
Controls and contact points
Archived: Headset: ACROS ZS44/56, Sealed bearings with alloy cup · Handlebar: RIDE ALPHA R35, 760 mm width, 35 mm Rise · Stem: RIDE ALPHA 40 mm, Enduro 40 mm · Seatpost: RIDE ALPHA, 31.6 mm, 250 mm · Saddle: RIDE ALPHA · Pedals: No
Before and during the test ride
Follow the full used-bike inspection order →Build relationships are limited to the archived manufacturer specifications. Confirm exact fit and standards before ordering parts or performing service.
Have you owned this bike?Help preserve its real-world history by sharing your owner experience.
Share the details that would help another rider understand how this model fits, rides and holds up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
Gallery
Current market
Snapshot not yet availableMove, scroll, tap or type to start the protected update.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
