2025 Canyon Aeroad CFR Di2

Original specifications: 700C wheels · 15.66 lb published weight · geometry for 7 published sizes.

Share owner experience

At a glance

Archive #900001604

Model year: 2025
Category: Road
Original MSRP: $8,399.00
Sizes: XXS, XS, S, M, L, XL, XXL
Colors: Sparkle Stealth
Weight: 15.66 lb
Geometry: 7 manufacturer sizes
In this record: 15 specifications · 8 archived images · original MSRP · geometry

Model history 1 other year

Browse other years

Compare side by side

Identification clues

2025 archived details

Published colors: Sparkle Stealth
Frame: Carbon (CFR)

Clues, not proof of model year. Colors vary and components may have been replaced.

Original buildCarbon (CFR) · 700C

Manufacturer catalog

Published sizes and colors

7 sizes · 1 color

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

XXSXSSMLXLXXL

Published colors

Sparkle Stealth

Frameset

Frame Construction	Canyon Aeroad CFR
Frame Material	Carbon (CFR)
Fork	Canyon FK0137 CF Disc
Fork Material	Carbon

Drivetrain

Rear Derailleur	Shimano Dura-Ace Di2
Crankset	Shimano Dura-Ace Di2 Powermeter; 52/36T
Bottom Bracket	Ceramicspeed BB86 Coated
Cassette	Shimano Dura-Ace CS-R9200; 12-speed; 11-30
Chain	Shimano XTR

Cockpit & Contact Points

Saddle	Selle Italia SLR Boost Superflow S saddle Carbon Rails
Seatpost	Canyon SP0077; 10 mm setback

Wheels & Tires

Wheels	Front: DT Swiss ARC 1100 Wheel; Rear: DT Swiss ARC 1100 Dicut
Front Tire	Continental Aero 111
Rear Tire	Continental Grand Prix 5000 S TR, 28mm
Wheel Size	700C

Geometry

7 sizes · 13 measurements

Frame measurements by size.

All geometry measurements7 sizes · 13 measurements

Measurement	2XS	XS	S	M	L	XL	XXL
Seat tube	441 mm	471 mm	501 mm	531 mm	561 mm	591 mm	621 mm
Effective top tube	516 mm	529 mm	546 mm	555 mm	569 mm	594 mm	609 mm
Head tube	88 mm	107 mm	121 mm	142 mm	162 mm	188 mm	206 mm
Head-tube angle	70°	71.2°	72.8°	73.25°	73.3°	73.5°	73.8°
Seat-tube angle	73.5°	73.5°	73.5°	73.5°	73.5°	73.5°	73.5°
Chainstay / rear center	410 mm	410 mm	410 mm	410 mm	413 mm	415 mm	415 mm
Wheelbase	975 mm	979 mm	982 mm	988 mm	1003 mm	1029 mm	1042 mm
Bottom-bracket drop	70 mm	70 mm	70 mm	70 mm	70 mm	70 mm	70 mm
Reach	372 mm	378 mm	390 mm	393 mm	401 mm	419 mm	429 mm
Stack	498 mm	520 mm	539 mm	560 mm	580 mm	606 mm	624 mm
Standover height	720 mm	748 mm	775 mm	801 mm	828 mm	851 mm	874 mm
Crank length	170 mm	170 mm	170 mm	172.5 mm	172.5 mm	175 mm	175 mm
Wheel size	700C	700C	700C	700C	700C	700C	700C

Dimensions as recorded.

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

Pedal cadence

RPM

Speed units

RPM = pedal turns per minute.

All published sizes52/36T · 11–30T · 12-speed

Lowest1.20:1 Highest4.73:1 Total range394%

Estimated speed At 90 RPM Lowest gear8.6 mph Highest gear33.8 mph

Rear tire: 28 mm + 700C.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Gears Drivetrain

Front teeth Smallest rear teeth Largest rear teeth

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Rear tire marking

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

Rim diameter (BSD, mm) Tire width (mm)

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Cadence (RPM) Speed units

Gear, dimension and cadence changes update results automatically.

Gearing comparison
Measure	Original	Your setup
Lowest ratio	—	—
Highest ratio	—	—
Total range	—	—
Lowest-gear speed	—	—
Highest-gear speed	—	—

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Chain · Original

Shimano XTR

Search Amazon Search eBay

Retailer offers

Shimano Deore CN-M6100 Chain Silver, 12 Speed, 126 Links

Replacement option

Competitive Cyclist ↗$30.00

Cassette · Original

Shimano Dura-Ace CS-R9200

12-speed; 11-30

Search Amazon Search eBay

Retailer offers

Shimano Dura-Ace CS-R9200 12-Speed Cassette Silver, 11-30T, 12-Speed

Model match

Competitive Cyclist ↗$410.00

Backcountry ↗$410.00

Rear tire · Original

Continental Grand Prix 5000 S TR

28mm

Search Amazon Search eBay

Retailer offers

Continental Grand Prix 5000 S TR Tire Black/Black Chili, 700x28

700x28c

Model match

Competitive Cyclist ↗$107.95

Other replacement options (4)

Continental Grand Prix 5000 S TR Tire Transparent, Black Chili, 700x28

700x28c

Model match

Competitive Cyclist ↗$107.95

Continental Grand Prix 5000 AS TR Tire Black, Black Chili, 700x28

700x28c

Model match

Competitive Cyclist ↗$109.95

Continental Grand Prix 5000 AS TR Tire Black/Cream, Black Chili, 700x28

700x28c

Model match

Competitive Cyclist ↗$109.95

Specialized SW Mondo 2Bliss Tire Black, 700x28

700x28c

Replacement option

Backcountry ↗$67.45

More parts (4)Fewer parts

Rear derailleur · Original

Shimano Dura-Ace Di2

Search Amazon Search eBay

Retailer offers

Shimano Dura-Ace RD-R9250 Di2 Rear Derailleur Black, 12-Speed

Specification match

Competitive Cyclist ↗$930.00

Front tire · Original

Continental Aero 111 Before ordering: Confirm the exact tire width before ordering.

Search Amazon Search eBay

Saddle · Original

Selle Italia SLR Boost Superflow S saddle Carbon Rails

Search Amazon Search eBay

Crankset · Original

Shimano Dura-Ace Di2 Powermeter; 52/36T

170 mm Frame sizes 2XS / XS / S

Search Amazon Search eBay

172.5 mm Frame sizes M / L

Search Amazon Search eBay

175 mm Frame sizes XL / XXL

Search Amazon Search eBay

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire: Continental Aero 111
Rear tire: Continental Grand Prix 5000 S TR, 28mm
Drivetrain: 12-speed
Bottom bracket / shell: Ceramicspeed BB86 Coated

Equipment inspection checks 7 checks based on 3 archived component groups Open equipment checksClose equipment checks

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Frame and fork

Inspect the frame and fork →

Archived: Frame: Canyon Aeroad CFR · Fork: Canyon FK0137 CF Disc · Carbon

Inspect the frame in bright light, especially the head tube, bottom-bracket area, chainstays and clamped surfaces. Look for cracks, ripples, crushed sections or signs of impact.
Inspect the fork crown, blades, dropouts and visible steerer area. Check that it is straight, securely installed and free of cracks or impact damage.

Drivetrain

Check drivetrain wear →

Archived: Rear derailleur: Shimano Dura-Ace Di2 · Crankset: Shimano Dura-Ace Di2 Powermeter; 52/36T · Bottom bracket: Ceramicspeed BB86 Coated · Cassette: Shimano Dura-Ace CS-R9200; 12-speed; 11-30 · Chain: Shimano XTR

Confirm every shift battery charges and every control operates. Shift through the full cassette under light load while checking pairing, derailleur alignment and response at both ends of the range.
Measure chain wear with a compatible gauge and inspect chainring, cassette or freewheel teeth. A new chain does not rule out wear in the remaining drivetrain.
Turn the cranks slowly, feel for rough bearings and check for side-to-side play. Inspect crank arms, chainring bolts and pedal threads for looseness or damage.

Wheels and tires

Check wheels and tires →

Archived: Wheel size: 700C · Wheels: Front: DT Swiss ARC 1100 Wheel; Rear: DT Swiss ARC 1100 Dicut · Front tire: Continental Aero 111 · Rear tire: Continental Grand Prix 5000 S TR, 28mm

Spin both wheels and watch for side-to-side and vertical movement. Check spoke tension, rim condition and hub play.
Inspect both tire casings for cuts, cracking, plugs, bulges or exposed threads and confirm the installed sizes are safe for the rims and available frame and fork clearance.
