1999 Cannondale Multisport 800
Original specifications: Shimano 105 drivetrain · 650c wheels · 21.6 lb published weight.
Planning to sell? Draft your listing
At a glance
Archive #85775- Model year
- 1999
- Category
- Road
- Original MSRP
- $1,299.00
- Sizes
- 48cm, 50cm, 52cm, 54cm, 56cm, 58cm, 60cm, 62cm
- Colors
- ChromaLusion Purpleen, Team Blue
- Weight
- 21.6 lb
- Geometry
- Legacy reference
- In this record
- 27 specifications · archived image · original MSRP · geometry
Model history 1 other year
Browse other years
Compare side by side
Identification clues
1999 archived details
- Published colors
- ChromaLusion Purpleen, Team Blue
- Frame
- 6061 T6 aluminum
- Original equipment
- Shimano 105
Clues, not proof of model year. Colors vary and components may have been replaced.
Original build6061 T6 aluminum · Shimano 105 · 650c wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 6061 T6 aluminum |
| Fork | Kinesis Air Foil |
| Fork Material | Aluminum, aero crown |
Drivetrain
| Component Group | Shimano 105 |
|---|---|
| Shifters | Shimano 105 |
| Front Derailleur | Shimano 105, bottom-pull/clamp-on 31.8mm |
| Rear Derailleur | Shimano 105 GS |
| Crankset | Shimano 105, 39/53 teeth |
| Bottom Bracket | Shimano BB-5500, 109.5mm spindle |
| BB Shell Width | 68mm English |
| Rear Cogs | 9-speed, 11 - 21 teeth |
| Chain | Shimano CN-HG72, 1/2 x 3/32" |
| Pedals | Not included |
Brakes
| Brakes | Shimano 105 Dual Pivot brakes, Shimano 105 STI levers |
|---|
Cockpit & Contact Points
| Headset | 1" Shimano 105 |
|---|---|
| Handlebar | Cinelli Eubios |
| Handlebar Extensions | Syntace Streamliner |
| Stem | CODA Front Loader aluminum |
| Saddle | CODA Expert Road, manganese rails |
| Seatpost | Kalloy SP-257, 27.2mm diameter |
Wheels & Tires
| Hubs | Shimano 105 |
|---|---|
| Rims | Mavic CXP 21, 32-hole |
| Spokes | DT stainless steel, 1.8mm straight gauge |
| Spoke Nipples | Brass nipples |
| Front Tire | 650 x 23c Continental Grand Prix kevlar |
| Wheel Size | 650c wheels |
No specifications match. Try a component name or clear your search.
Geometry
Historical measurements. Frame size unknown.
Reference drawing
Select an available measurement to locate it on the frame.
All geometry measurementsLegacy reference · 6 measurements
| Measurement | Legacy reference |
|---|---|
| Top tube | 560 mm |
| Head-tube angle | 72.5° |
| Seat-tube angle | 78° |
| Chainstay / rear center | 380 mm |
| Wheelbase | 1002 mm |
| Fork offset / rake | 35 mm |
Frame size not recorded.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
