2008 Brodie Force

Original specifications: Shimano Deore · 8-speed · mechanical rear derailleur · 26" wheels · 32 lb published weight.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #15580
Model year
2008
Category
Mountain
Original MSRP
$539.00
Sizes
14", 16", 17", 18", 19", 19.5", 20.5"
Colors
Anthracite
Weight
32 lb
In this record
28 specifications · archived image · original MSRP
Model history 2 other years

Browse other years

Compare side by side

Identification clues

2008 archived details

Published colors
Anthracite
Frame
6061 aluminum
Original equipment
Mountain Mix

Clues, not proof of model year. Colors vary and components may have been replaced.

Sponsored affiliate link
Original build6061 aluminum · Mountain Mix · 26" wheels

Historical catalog variants

Archived sizes and colors

7 item records

Item-level catalog entries recovered from Velopedia’s original bicycle archive. They document how this model was listed historically; they do not identify the frame size associated with legacy reference geometry or indicate current availability.

Published sizes

14"16"17"18"19"19.5"20.5"

Published colors

Anthracite
View 7 archived size/color combinations
SizeColor
14"Anthracite
16"Anthracite
17"Anthracite
18"Anthracite
19"Anthracite
19.5"Anthracite
20.5"Anthracite

Historical catalog evidence. Exact specifications and naming may vary by market, production run or manufacturer revision.

Frameset

Frame ConstructionTIG-welded
Frame Material6061 aluminum
ForkSuntour XCM, 100mm travel
Fork MaterialSingle

Drivetrain

Component GroupMountain Mix
ShiftersShimano Alivio
Front DerailleurShimano Altus
Rear DerailleurShimano Deore
CranksetShimano M341, 22/32/42 teeth
Bottom BracketShimano UN-26, 113mm spindle
BB Shell Width68mm
CassetteShimano HG30
Rear Cogs8-speed, 11 - 32 teeth
ChainKMC Z72
PedalsWellgo

Brakes

BrakesTektro IO Mechanical Disc w/ 6" Rotor brakes, Tektro ML-330 levers

Cockpit & Contact Points

Headset1 1/8" threadless TH 855
HandlebarBrodie XC Riser
Handlebar ExtensionsNot included
StemBrodie XC
SaddleBrodie XC
SeatpostBrodie 2-bolt, 27.2mm diameter

Wheels & Tires

HubsFront: Formula DC20, Rear: Shimano M475
RimsAlex DM-18
SpokesStainless steel
Spoke NipplesBrass
Front Tire26 x 2.10" Kenda Komodo
Wheel Size26" wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes42/32/22T · 11–32T · 8-speed
Lowest0.69:1 Highest3.82:1 Total range555%
Estimated speed At 90 RPM Lowest gear4.8 mph Highest gear26.8 mph

Uses front tire 26×2.1; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Chain · Original
KMC Z72
Retailer offers
Seatpost · Original
Brodie 2-bolt

27.2mm diameter

Retailer offers
Cassette · Original
Shimano HG30
More parts (7)Fewer parts
Front tire · Original
26 x 2.10" Kenda Komodo
Bottom bracket · Original
Shimano UN-26

113mm spindle

Crankset · Original
Shimano M341

22/32/42 teeth

Front derailleur · Original
Shimano Altus
Rear derailleur · Original
Shimano Deore
Shifters · Original
Shimano Alivio
Rims · Original
Alex DM-18

Based on the original build. Check fit and installed parts before ordering.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
26 x 2.10" Kenda Komodo
Drivetrain
8-speed
Seatpost diameter
27.2 mm
Bottom bracket / shell
Shimano UN-26, 113mm spindle · 68mm
Equipment inspection checks 11 checks based on 6 archived component groups Open equipment checksClose equipment checks
0 of 11 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: Suntour XCM, 100mm travel · Single

Archived: Fork: Suntour XCM, 100mm travel

Archived: Group: Mountain Mix · Shifters: Shimano Alivio · Front derailleur: Shimano Altus · Rear derailleur: Shimano Deore · Crankset: Shimano M341, 22/32/42 teeth · Bottom bracket: Shimano UN-26, 113mm spindle · Cassette: Shimano HG30 · Rear cogs: 8-speed, 11 - 32 teeth · Chain: KMC Z72

Archived: Brakes: Tektro IO Mechanical Disc w/ 6" Rotor brakes, Tektro ML-330 levers

Archived: Wheel size: 26" wheels · Rims: Alex DM-18 · Hubs: Front: Formula DC20, Rear: Shimano M475 · Front tire: 26 x 2.10" Kenda Komodo

Controls and contact points

Archived: Headset: 1 1/8" threadless TH 855 · Handlebar: Brodie XC Riser · Stem: Brodie XC · Seatpost: Brodie 2-bolt, 27.2mm diameter · Saddle: Brodie XC · Pedals: Wellgo
