Velopedia Bicycle Archive
2027 Bianchi Specialissima PRO Force eTap AXS - Quarq Power Meter
Original specifications: geometry for 6 published sizes.
Planning to sell? Draft your listing
At a glance
Archive #900001046- Model year
- 2027
- Category
- Road
- Original MSRP
- $9,008.00
- Sizes
- 47, 50, 53, 55, 57, 59
- Colors
- JU – Ying & Yang: Carbonio UD / Bianco Italia + Logo cromato iridescente + Full Glossy
- Geometry
- 6 manufacturer sizes
- In this record
- 20 specifications · 6 archived images · original MSRP · geometry
Original buildCarbon Fiber
Frameset
| Frame Construction | Bianchi Specialissima PRO carbon, only electronic groupsets, fully internal cable routing, Flat mount disc brake type, UDH compatible, BBPressFit 86.5×41, Max crankset compatibility 58T sizes 47-50-53-55-57-59 |
|---|---|
| Frame Material | Carbon Fiber |
| Fork | Bianchi Specialissima carbon, ICR 1.5″ integrated head, Disc brake flat mount 140mm, thru axle 12×100 w/countervail |
| Fork Material | Carbon Fiber |
Drivetrain
| Shifters | Sram Force AXS E1 |
|---|---|
| Front Derailleur | Sram Force AXS E1 |
| Rear Derailleur | Sram Force AXS E1, 12sp |
| Crankset | Sram Force E1, Quarq Power Meter, 48x35T Crank length: 165 mm (47-50 cm); 170 mm (53-55 cm); 172.5 mm (57-59 cm) |
| Bottom Bracket | Sram Press fit Road 86.5×41 |
| Cassette | Sram Force XG 1270 E1, 10-36T, 10-11-12-13-15-17-19-21-24-28-32-36T |
| Chain | Sram Force E1 |
Brakes
| Brakes | Sram Force E1, Hydraulic disc brake; Rotors: Sram Paceline, Center Lock, 160 mm; Levers: Included in the shifter |
|---|
Cockpit & Contact Points
| Headset | Acros IS52 Integrated Cable Routing |
|---|---|
| Handlebar | Included in the stem |
| Stem | Bianchi Reparto Corse Carbon integrated handlebar, for Acros ICR system drop 125mm, reach 80mm Size: 90/380 (47-50 cm); 100/380 (53 cm); 110/400 (55-57 cm); 120/420 (59 cm) |
| Saddle | Prologo Nago R4 PAS, nack carbon rail, Nylon Injection, 156 g, Length: 245 mm, Width: 137 mm |
| Seatpost | Bianchi Specialissima seatpost Full Carbon Aero length: 280 mm, 0 offset (47 cm); 300 mm, 0 offset (50-53 cm); 350 mm, 20 mm offset (55-57-59 cm) |
Wheels & Tires
| Wheels | Bianchi RC 49R, 25-622, profile height 49 mm, straight-pull, ratchet system, tubeless ready, XDR body |
|---|---|
| Front Tire | Continental 30-622 Grand Prix 5000S TR black |
| Rear Tire | Continental 30-622 Grand Prix 5000S TR black |
No specifications match. Try a component name or clear your search.
Geometry
Frame measurements by size.
Frame diagram
Select an available measurement to locate it on the frame.
All geometry measurements6 sizes · 13 measurements
| Measurement | 47 | 50 | 53 | 55 | 57 | 59 |
|---|---|---|---|---|---|---|
| Seat tube | 420 mm | 450 mm | 480 mm | 500 mm | 520 mm | 540 mm |
| Effective top tube | 514 mm | 524 mm | 535 mm | 550 mm | 560 mm | 575 mm |
| Head tube | 100 mm | 105 mm | 120 mm | 135 mm | 150 mm | 170 mm |
| Head-tube angle | 70.5° | 71.5° | 72° | 72.5° | 73° | 73° |
| Seat-tube angle | 74.5° | 74.5° | 74° | 73.5° | 73.5° | 73° |
| Chainstay / rear center | 410 mm | 410 mm | 410 mm | 410 mm | 412 mm | 412 mm |
| Wheelbase | 982 mm | 983 mm | 984 mm | 988 mm | 996 mm | 1005 mm |
| Bottom-bracket drop | 58 mm | 58 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Reach | 379 mm | 387 mm | 386 mm | 391 mm | 397 mm | 400 mm |
| Stack | 486 mm | 494 mm | 520 mm | 536 mm | 552 mm | 571 mm |
| Fork offset / rake | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Front center | 579 mm | 581 mm | 582 mm | 588 mm | 593 mm | 603 mm |
| Fork length / axle-to-crown | 368 mm | 368 mm | 368 mm | 368 mm | 368 mm | 368 mm |
Dimensions as recorded.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Choose a chain long enough to size for your bike.
114 links

SRAM Force E1 Flattop Chain Silver, 114 Link
Specification match
Other replacement options (1)

SRAM Force E1 Flattop Chain Purple, 114 Link
Specification match
126 links

SRAM Force E1 Flattop Chain Silver, 126 Link
Specification match
Other replacement options (1)

SRAM Force E1 Flattop Chain Purple, 126 Link
Specification match

Continental Grand Prix 5000 S TR Tire Black/Black Chili, 700x30
700x30c
Model match
Other replacement options (2)

Continental Grand Prix 5000 S TR Tire Transparent, Black Chili, 700x30
700x30c
Model match

Continental Grand Prix 5000 TT Tubeless Tire Black Chili, 700c x 30mm
700x30c
Model match
12sp

SRAM Force E1 AXS 12-Speed Rear Derailleur Black, 12-Speed, 36t Max
Specification match
More parts (5)Fewer parts
10-36T, 10-11-12-13-15-17-19-21-24-28-32-36T
nack carbon rail, Nylon Injection, 156 g, Length: 245 mm, Width: 137 mm
Quarq Power Meter, 48x35T Crank length: 165 mm (47-50 cm); 170 mm (53-55 cm); 172.5 mm (57-59 cm)
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Service essentialsQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- Continental 30-622 Grand Prix 5000S TR blackCheck: Verify the fitted tire’s size marking and rim type.
- Rear tire
- Continental 30-622 Grand Prix 5000S TR blackCheck: Verify the rear size; it may differ from the front.
- Drivetrain
- 12-speedCheck: Match the installed drivetrain family, not just its speed count.
- Bottom bracket / shell
- Sram Press fit Road 86.5×41Check: Verify shell type and width, crank interface, and spindle length or spacers.
Not confirmed in this record: Seatpost diameter. Check the fitted parts for these details.
Bike-specific inspection checklist 20 checks based on 5 archived component groups Open checklistClose checklist
This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.
Identity and fit
Follow the full used-bike inspection order →Archived: 2027 Bianchi Specialissima PRO Force eTap AXS - Quarq Power Meter · Road · Published sizes: 47, 50, 53, 55, 57, 59
Frame and fork
Inspect the frame and fork →Archived: Frame: Bianchi Specialissima PRO carbon, only electronic groupsets, fully internal cable routing, Flat mount disc brake type, UDH compatible, BBPressFit 86.5×41, Max crankset compatibility 58T sizes 47-50-53-55-57-59 · Fork: Bianchi Specialissima carbon, ICR 1.5″ integrated head, Disc brake flat mount 140mm, thru axle 12×100 w/countervail · Carbon Fiber
Drivetrain
Check drivetrain wear →Archived: Shifters: Sram Force AXS E1 · Front derailleur: Sram Force AXS E1 · Rear derailleur: Sram Force AXS E1, 12sp · Crankset: Sram Force E1, Quarq Power Meter, 48x35T Crank length: 165 mm (47-50 cm); 170 mm (53-55 cm); 172.5 mm (57-59 cm) · Bottom bracket: Sram Press fit Road 86.5×41 · Cassette: Sram Force XG 1270 E1, 10-36T, 10-11-12-13-15-17-19-21-24-28-32-36T · Chain: Sram Force E1
Brakes
Inspect the brakes →Archived: Brakes: Sram Force E1, Hydraulic disc brake; Rotors: Sram Paceline, Center Lock, 160 mm; Levers: Included in the shifter
Wheels and tires
Check wheels and tires →Archived: Wheels: Bianchi RC 49R, 25-622, profile height 49 mm, straight-pull, ratchet system, tubeless ready, XDR body · Front tire: Continental 30-622 Grand Prix 5000S TR black · Rear tire: Continental 30-622 Grand Prix 5000S TR black
Controls and contact points
Archived: Headset: Acros IS52 Integrated Cable Routing · Handlebar: Included in the stem · Seatpost: Bianchi Specialissima seatpost Full Carbon Aero length: 280 mm, 0 offset (47 cm); 300 mm, 0 offset (50-53 cm); 350 mm, 20 mm offset (55-57-59 cm) · Saddle: Prologo Nago R4 PAS, nack carbon rail, Nylon Injection, 156 g, Length: 245 mm, Width: 137 mm
Before and during the test ride
Follow the full used-bike inspection order →Have you owned this model?Help preserve its real-world history by sharing your owner experience.
Share the details that would help another rider understand how this model fits, rides and holds up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
Gallery6 images
Checking current listings…
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
