Lowest1.07:1
Highest2.91:1
Total range273%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Rear tire: 54-507 ETRTO.
Velopedia Bicycle Archive
At a glance
Archive #900001880- Model year
- 2024
- Category
- Kids
- Original MSRP
- $664.00
- Sizes
- OSFM
- Colors
- 7U - CK16 / Silver Graphite, 7X - Acid Yellow Full Glossy, 8A - Carina / Silver Full Glossy
- In this record
- 18 specifications · 3 archived images · original MSRP
Original buildAluminum
Frameset
| Frame Construction | Bianchi XR24, Alluminio, Disc Brake, per 24″ misura ruote 33 |
|---|---|
| Frame Material | Aluminum |
| Fork | Zoom Suspended fork for 24″, escursione 50mm |
Drivetrain
| Shifters | Shimano SL-M315, Tourney 8sp |
|---|---|
| Rear Derailleur | Shimano RD-TY800, Tourney 8sp |
| Crankset | 32T, lunghezza 152mm |
| Cassette | Shimano CS-HG31, 8sp, 11-13-15-17-20-23-26-30T |
| Chain | KMC 8sp |
Brakes
| Brakes | Shimano BR-TX80 freno a disco meccanico, Tourney; Rotors: Shimano SM-RT10, 160 mm; Levers: Shimano BL-T4000 per freno a disco meccanico |
|---|
Cockpit & Contact Points
| Headset | NECO Headset for 1-1/8″ |
|---|---|
| Handlebar | Bianchi, larghezza 580mm, barebore 25.4mm, rise 16mm, backsweep 9° |
| Handlebar Extensions | Bianchi manopole in gomma |
| Stem | Bianchi Stem alloy, lunghezza 50mm |
| Saddle | DDK sella in memory foam |
| Seatpost | SP-7019, 27.2mm, 0mm seatback |
Wheels & Tires
| Wheels | Mach1 ER20 24″, 32 fori |
|---|---|
| Front Tire | Rubena Ocelot, 24×2.1″, 54-507 |
| Rear Tire | Rubena Ocelot, 24×2.1″, 54-507 |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
SP-7019
27.2mm, 0mm seatback
Retailer offers
Race Face Ride XC Seatpost Black, 27.2x375mm
Replacement option
KMC 8sp
Replacement search: 8-speed bicycle chain Before ordering: Check chain width and length.
Shimano CS-HG31
8sp, 11-13-15-17-20-23-26-30T
Shimano CS-HG31 on eBaySponsored links
More parts (3)Fewer parts
Shimano BR-TX80 freno a disco meccanico
Tourney; Rotors: Shimano SM-RT10, 160 mm; Levers: Shimano BL-T4000 per freno a disco meccanico
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- Rubena Ocelot, 24×2.1″, 54-507
- Rear tire
- Rubena Ocelot, 24×2.1″, 54-507
- Drivetrain
- 8-speed
- Seatpost diameter
- 27.2 mm
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: Bianchi XR24, Alluminio, Disc Brake, per 24″ misura ruote 33 · Fork: Zoom Suspended fork for 24″, escursione 50mm
Drivetrain
Check drivetrain wear →Archived: Shifters: Shimano SL-M315, Tourney 8sp · Rear derailleur: Shimano RD-TY800, Tourney 8sp · Crankset: 32T, lunghezza 152mm · Cassette: Shimano CS-HG31, 8sp, 11-13-15-17-20-23-26-30T · Chain: KMC 8sp
Brakes
Inspect the brakes →Archived: Brakes: Shimano BR-TX80 freno a disco meccanico, Tourney; Rotors: Shimano SM-RT10, 160 mm; Levers: Shimano BL-T4000 per freno a disco meccanico
Wheels and tires
Check wheels and tires →Archived: Wheels: Mach1 ER20 24″, 32 fori · Front tire: Rubena Ocelot, 24×2.1″, 54-507 · Rear tire: Rubena Ocelot, 24×2.1″, 54-507
Controls and contact points
Archived: Headset: NECO Headset for 1-1/8″ · Handlebar: Bianchi, larghezza 580mm, barebore 25.4mm, rise 16mm, backsweep 9° · Stem: Bianchi Stem alloy, lunghezza 50mm · Seatpost: SP-7019, 27.2mm, 0mm seatback · Saddle: DDK sella in memory foam
Have you owned this model?Help document firsthand fit, ride and maintenance details that may no longer be available.
This archive record has limited published detail. Share what would help another rider understand how this model fit, rode and held up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
Gallery3 images
Checking current listings…
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
