Lowest0.88:1
Highest4.36:1
Total range499%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 700C×32; rear size isn’t listed.
Velopedia Bicycle Archive
2010 Bianchi Camaleonte 1
Original specifications: Shimano Alivio · 8-speed rear derailleur · 700c wheels.
Planning to sell? Draft your listing
At a glance
Archive #20180- Model year
- 2010
- Category
- City & Commuter
- Original MSRP
- $600.00
- Sizes
- 43cm, 48cm, 53cm, 58cm
- Colors
- UL Arctic Silver
- In this record
- 24 specifications · archived image · original MSRP
Original buildAluminum · Commuter Mix · 700c wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Aluminum |
| Fork | Bianchi FF BKC |
| Fork Material | Aluminum, unicrown crown |
Drivetrain
| Component Group | Commuter Mix |
|---|---|
| Shifters | Shimano ST-EF60 |
| Front Derailleur | Shimano FD-M310 |
| Rear Derailleur | Shimano Alivio |
| Crankset | Shimano FC-M151, 48/38/28 teeth |
| Cassette | Shimano CS-HG30 |
| Rear Cogs | 8-speed, 11 - 32 teeth |
| Chain | KMC HV800 |
| Pedals | VP-516A |
Brakes
| Brakes | MV-87 Mini V-Brake alloy brakes, integrated levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless FSA ZS4-Custom |
|---|---|
| Handlebar | HL AL-110BT Aluminum |
| Handlebar Extensions | Not included |
| Stem | Lee Chi MA-527 Adjustable |
| Saddle | Active FM316 |
| Seatpost | RC SP-222 alloy, 27.2mm diameter |
Wheels & Tires
| Hubs | Front: Joytech JY-731, Rear: Shimano FH-RM30 |
|---|---|
| Rims | Mach 1 240, 32-hole |
| Front Tire | 700 x 32c Spectra Regular Amber |
| Wheel Size | 700c wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
RC SP-222 alloy
27.2mm diameter
Retailer offers
Race Face Ride XC Seatpost Black, 27.2x375mm
Replacement option
700 x 32c Spectra Regular Amber
Replacement search: 700cx32 bicycle tire Before ordering: Check rim type and tire clearance.
More parts (6)Fewer parts
MV-87 Mini V-Brake alloy brakes
integrated levers
Shimano FC-M151
48/38/28 teeth
Shimano Alivio
1 1/8" threadless FSA ZS4-Custom
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 700 x 32c Spectra Regular Amber
- Drivetrain
- 8-speed
- Seatpost diameter
- 27.2 mm
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Bianchi FF BKC · Aluminum, unicrown crown
Drivetrain
Check drivetrain wear →Archived: Group: Commuter Mix · Shifters: Shimano ST-EF60 · Front derailleur: Shimano FD-M310 · Rear derailleur: Shimano Alivio · Crankset: Shimano FC-M151, 48/38/28 teeth · Cassette: Shimano CS-HG30 · Rear cogs: 8-speed, 11 - 32 teeth · Chain: KMC HV800
Brakes
Inspect the brakes →Archived: Brakes: MV-87 Mini V-Brake alloy brakes, integrated levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700c wheels · Rims: Mach 1 240, 32-hole · Hubs: Front: Joytech JY-731, Rear: Shimano FH-RM30 · Front tire: 700 x 32c Spectra Regular Amber
Controls and contact points
Archived: Headset: 1 1/8" threadless FSA ZS4-Custom · Handlebar: HL AL-110BT Aluminum · Stem: Lee Chi MA-527 Adjustable · Seatpost: RC SP-222 alloy, 27.2mm diameter · Saddle: Active FM316 · Pedals: VP-516A
