2015 Banshee Phantom Show

Original specifications: SRAM X01 drivetrain · 29 wheels.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #1069248
Model year
2015
Category
Mountain
Sizes
M, L, XL
Colors
Stealth, Raw, Mint
In this record
21 specifications · 3 archived images
Sponsored affiliate link
Original buildHydroformed 7005 AL tubes · SRAM X01 · 29

Manufacturer catalog

Published sizes and colors

3 sizes · 3 colors

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

MLXL

Published colors

StealthRawMint

Frameset

Frame ConstructionKS-Link 105mm
Frame MaterialHydroformed 7005 AL tubes
ForkRecommended fork travel 120mm
Rear ShockCane Creek DBair CS

Drivetrain

Component GroupSRAM X01
ShiftersSRAM X01 - 11SPD - Trigger
Front DerailleurNone
Rear DerailleurSRAM X01 11SPD
CranksetRace Face Next SL - 175mm - 30T Narrow Wide
Rear CogsSRAM X01 - 11SPD - 10-42
ChainYaban SLA110 - hollow pin - 11Speed

Brakes

BrakesSRAM Guide RS - 180/160mm

Cockpit & Contact Points

HeadsetBanshee Munro Taper 44/56
HandlebarRace Face SixC 35mm - 800mm width - 20mm rise
StemRace Face Atlas 35 - 50mm
SaddleKore Fazer SL
SeatpostRock Shox Reverb Stealth 420mm - 125mm

Wheels & Tires

HubsSpank Oozy EVO Wheelset 29"
RimsSpank Oozy EVO Wheelset 29"
Front TireMaxxis High roller II - 29x2.3 - 3C
Wheel Size29

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

All published sizes30T · 10–42T · 11-speed
Lowest0.71:1 Highest3.00:1 Total range420%

Speed unavailable: wheel or tire size is missing or unclear.

Add your rear tire size to calculate speed
How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Stem · Original
Race Face Atlas 35 - 50mm
Retailer offers
Cassette / rear cogs · Original
SRAM X01 - 11SPD - 10-42
Front tire · Original
Maxxis High roller II - 29x2.3 - 3C Before ordering: Confirm the exact tire width before ordering.
More parts (6)Fewer parts
Crankset · Original
Race Face Next SL - 175mm - 30T Narrow Wide
Rear derailleur · Original
SRAM X01 11SPD Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.
Shifters · Original
SRAM X01 - 11SPD - Trigger Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.
Handlebar · Original
Race Face SixC 35mm - 800mm width - 20mm rise
Rims · Original
Spank Oozy EVO Wheelset 29"
Hubs · Original
Spank Oozy EVO Wheelset 29"

Based on the original build. Check fit and installed parts before ordering.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
Maxxis High roller II - 29x2.3 - 3C
Drivetrain
11-speed
Equipment inspection checks 13 checks based on 6 archived component groups Open equipment checksClose equipment checks
0 of 13 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: KS-Link 105mm · Fork: Recommended fork travel 120mm

Archived: Fork: Recommended fork travel 120mm · Rear shock: Cane Creek DBair CS

Archived: Group: SRAM X01 · Shifters: SRAM X01 - 11SPD - Trigger · Rear derailleur: SRAM X01 11SPD · Crankset: Race Face Next SL - 175mm - 30T Narrow Wide · Rear cogs: SRAM X01 - 11SPD - 10-42 · Chain: Yaban SLA110 - hollow pin - 11Speed

Archived: Brakes: SRAM Guide RS - 180/160mm

Archived: Wheel size: 29 · Rims: Spank Oozy EVO Wheelset 29" · Hubs: Spank Oozy EVO Wheelset 29" · Front tire: Maxxis High roller II - 29x2.3 - 3C

Controls and contact points

Archived: Headset: Banshee Munro Taper 44/56 · Handlebar: Race Face SixC 35mm - 800mm width - 20mm rise · Stem: Race Face Atlas 35 - 50mm · Seatpost: Rock Shox Reverb Stealth 420mm - 125mm · Saddle: Kore Fazer SL
