Uses front tire 29×2.25; rear size isn’t listed.
Velopedia Bicycle Archive
2015 Banshee Phantom Comp
Original specifications: SRAM X7 drivetrain · 29 wheels.
Planning to sell? Draft your listing
At a glance
Archive #1288918- Model year
- 2015
- Category
- Mountain
- Sizes
- M, L, XL
- Colors
- Stealth, Raw, Mint
- In this record
- 21 specifications · 4 archived images
Original buildHydroformed 7005 AL tubes · SRAM X7 · 29
Frameset
| Frame Construction | KS-Link 105mm |
|---|---|
| Frame Material | Hydroformed 7005 AL tubes |
| Fork | Recommended fork travel 120mm |
| Rear Shock | Cane Creek DBair CS |
Drivetrain
| Component Group | SRAM X7 |
|---|---|
| Shifters | SRAM X7 - 10SPD - Trigger |
| Front Derailleur | None |
| Rear Derailleur | SRAM X7 - Type 2 - Medium Cage - 10SPD |
| Crankset | Race Face Ride - 175mm - 32T Narrow Wide |
| Rear Cogs | SRAM PG 1030 - 11-36, e13 42T cog |
| Chain | Yaban S1010CR Hollowpin |
Brakes
| Brakes | SRAM DB3 - 180/160mm |
|---|
Cockpit & Contact Points
| Headset | Banshee Munro Taper 44/56 |
|---|---|
| Handlebar | Race Face Respond - 785mm width - 1/2" rise |
| Stem | Race Face Chester - 50mm |
| Saddle | Kore Fazer |
| Seatpost | Banshee 30.9mm |
Wheels & Tires
| Hubs | Novatech D881SB-15 (includes both 15mm and 20mm adaptors), Novatech D882SB-AA - 142x12 |
|---|---|
| Rims | Kore XCD - 32H 29 |
| Front Tire | Maxxis Ardent - 29x2.25 |
| Wheel Size | 29 |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
e13 42T cog

SRAM PG-1030 Cassette 10 Speed, 11-36T
Model match

Michelin Force XC2 Performance Line 29in - Tubeless Tire Black, 29x2.25
Replacement option

Race Face Chester Stem Black, 8-Deg, 31.8x50mm
Model match
More parts (5)Fewer parts

Race Face Ride XC Seatpost Black, 30.9x375mm
Replacement option
Based on the original build. Check fit and installed parts before ordering.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- Maxxis Ardent - 29x2.25
- Drivetrain
- 10-speed
- Seatpost diameter
- 30.9 mm
Equipment inspection checks 13 checks based on 6 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: KS-Link 105mm · Fork: Recommended fork travel 120mm
Suspension
Evaluate the suspension →Archived: Fork: Recommended fork travel 120mm · Rear shock: Cane Creek DBair CS
Drivetrain
Check drivetrain wear →Archived: Group: SRAM X7 · Shifters: SRAM X7 - 10SPD - Trigger · Rear derailleur: SRAM X7 - Type 2 - Medium Cage - 10SPD · Crankset: Race Face Ride - 175mm - 32T Narrow Wide · Rear cogs: SRAM PG 1030 - 11-36, e13 42T cog · Chain: Yaban S1010CR Hollowpin
Brakes
Inspect the brakes →Archived: Brakes: SRAM DB3 - 180/160mm
Wheels and tires
Check wheels and tires →Archived: Wheel size: 29 · Rims: Kore XCD - 32H 29 · Hubs: Novatech D881SB-15 (includes both 15mm and 20mm adaptors), Novatech D882SB-AA - 142x12 · Front tire: Maxxis Ardent - 29x2.25
Controls and contact points
Archived: Headset: Banshee Munro Taper 44/56 · Handlebar: Race Face Respond - 785mm width - 1/2" rise · Stem: Race Face Chester - 50mm · Seatpost: Banshee 30.9mm · Saddle: Kore Fazer
Have you owned this model?Help document firsthand fit, ride and maintenance details that may no longer be available.
This archive record has limited published detail. Share what would help another rider understand how this model fit, rode and held up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
Gallery4 images
No recent price sample is available for this bike. Check eBay for matching listings.
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
