2027 Trek Fuel LX 9.9 X0 AXS
Mountain bicycle from the Velopedia specification archive.
- Original MSRP
- $8,999.99
- Sizes
- S; M; L; XL; XXL
- Colors
- Purple Phaze / Amethyst Marble; Gloss Dark Carmine / Matte Trek Black; Miami Green / Aloha Marble
- Geometry
- 5 manufacturer sizes
- Archive ID
- 900000686
Current market
Snapshot not yet availableProtected live updateReady after page interactionAutomated crawlers do not trigger marketplace requests.
Move, scroll, tap or type to start the protected update.
Velopedia analysis
What the specifications mean
Suspension at both ends means fork and shock setup should be considered together; mismatched sag or rebound can leave the front and rear reacting very differently. Electronic shifting removes the usual shift cable but adds a separate battery and controls, while the 520% cassette range describes how much gearing is available. Hydraulic disc brakes shift routine service toward pad and rotor condition, fluid leaks and use of the correct bleed fluid.
Suspension setup
Front + rear
Fork and shock pressure, sag and rebound should be balanced and recorded independently.
Drivetrain
Electronic · 520% range
Shift-system battery state joins derailleur setup and sprocket compatibility as a troubleshooting variable.
Brake service
Hydraulic disc
Pad and rotor condition plus the correct bleed fluid are the primary service checks.
Frame material
Mixed materials
Composite impact checks and metal-joint inspection both apply.
Used-bike inspection
If you’re buying this bike used
Before any test ride: both brakes should stop the bike firmly and release cleanly; both wheels should run true and be securely attached; tires should have no casing damage; and the headset, handlebar, stem, cranks and pedals should have no looseness or play.
Follow the full used-bike inspection order →- FrameInspect the composite sections for impact or clamp damage, then check the metal joints and welds for dents or cracking. Ask about any crash history.Inspect the frame and fork →
- BrakesBoth levers should feel firm and return cleanly. Check for fluid around the levers and calipers, inspect pad thickness and contamination, and look for worn or bent rotors.Inspect the brakes →
- SuspensionAsk when the fork and shock were last serviced. Check the stanchions for damage, look for oil at the seals, cycle both units through their travel and test the suspension pivots for play.Evaluate the suspension →
- DrivetrainConfirm every shift-system battery charges, every shift control works and the derailleur moves cleanly across the cassette. Make sure the matching shift-system charger is included, then measure chain wear and inspect the cassette teeth.Check drivetrain wear →
- Wheels & tiresSpin both wheels and watch the rims for side-to-side or vertical movement. Check for dents, cracks, loose or uneven spokes and hub play, then inspect both tire casings for cuts, cracking or exposed threads.Check wheels and tires →
Bike-specific inspection checklist 19 checks based on 5 archived component groups Open checklistClose checklist
This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.
Identity and fit
Follow the full used-bike inspection order →Archived: 2027 Trek Fuel LX 9.9 X0 AXS · Mountain · Published sizes: S; M; L; XL; XXL
Frame and fork
Inspect the frame and fork →Archived: Frame: Carbon fiber · Fork: Rockshox ZEB Ultimate B1, Linear XL w/ ButterCups, Charger 3.2 RC2 damper, tapered steerer, 44mm offset, Boost110, 15mm Maxle Stealth, 170mm travel
Suspension
Evaluate the suspension →Archived: Fork: Rockshox ZEB Ultimate B1, Linear XL w/ ButterCups, Charger 3.2 RC2 damper, tapered steerer, 44mm offset, Boost110, 15mm Maxle Stealth, 170mm travel · Rear shock: RockShox Vivid Ultimate D1, 205x65mm
Drivetrain
Check drivetrain wear →Archived: Group: SRAM X0 Eagle AXS, 12-speed · Shifters: SRAM AXS pod · Rear derailleur: SRAM X0 Eagle AXS, T-Type · Crankset: S, M, L, XL, XXL: SRAM X0 Eagle, DUB, 30T steel, T-Type, 55mm chainline, 170mm length / S, M, L, XL, XXL: SRAM X0 Eagle, DUB, 30T, T-Type, 55mm chainline, 165mm length · Bottom bracket: SRAM DUB MTB Wide, 73mm, BSA threaded · Cassette: SRAM Eagle XS-1295, T-Type, 10-52, 12 speed · Chain: SRAM X0 Eagle, T-Type, 12 speed
Brakes
Inspect the brakes →Archived: Brakes: SRAM Maven Silver 4-piston hydraulic disc
Controls and contact points
Archived: Headset: 1-1/8'' threadless, sealed cartridge bearings · Handlebar: Race Face ERA, carbon, 35mm, 40mm rise, 800mm width · Stem: Race Face Turbine R, 35mm, 0 degree, 40mm length · Seatpost: S: Fox Transfer NEO, 150mm travel, wireless, 34.9mm / M, L: Fox Transfer NEO, 175mm travel, wireless, 34.9mm / XL, XXL: Fox Transfer NEO, 200mm travel, wireless, 34.9mm · Saddle: Trek Aeolus Pro, carbon fiber rails, AirLoom lattice 145mm width
Before and during the test ride
Follow the full used-bike inspection order →Interpretation based on the archived manufacturer specifications. Confirm exact fit and standards before ordering parts or performing service.
Have you owned this bike?Help preserve its real-world history by sharing your owner experience.
Share the details that would help another rider understand how this model fits, rides and holds up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
Frameset
| Frame Construction | OCLV Mountain Carbon, internal storage, ZS headset, adjustable leverage rate, guided internal routing, interchangeable alloy rocker link, interchangeable lower shock mount, downtube guard, shuttle guard, BSA 73, ISCG 05, ABP, UDH, Boost148, adaptable travel 145mm-160mm |
|---|---|
| Frame Material | Carbon fiber |
| Fork | Rockshox ZEB Ultimate B1, Linear XL w/ ButterCups, Charger 3.2 RC2 damper, tapered steerer, 44mm offset, Boost110, 15mm Maxle Stealth, 170mm travel |
| Rear Shock | RockShox Vivid Ultimate D1, 205x65mm |
Drivetrain
| Component Group | SRAM X0 Eagle AXS, 12-speed |
|---|---|
| Shifters | SRAM AXS pod |
| Rear Derailleur | SRAM X0 Eagle AXS, T-Type |
| Crankset | S, M, L, XL, XXL: SRAM X0 Eagle, DUB, 30T steel, T-Type, 55mm chainline, 170mm length / S, M, L, XL, XXL: SRAM X0 Eagle, DUB, 30T, T-Type, 55mm chainline, 165mm length |
| Bottom Bracket | SRAM DUB MTB Wide, 73mm, BSA threaded |
| BB Shell Width | 73 mm |
| Cassette | SRAM Eagle XS-1295, T-Type, 10-52, 12 speed |
| Chain | SRAM X0 Eagle, T-Type, 12 speed |
Brakes
| Brakes | SRAM Maven Silver 4-piston hydraulic disc |
|---|
Cockpit & Contact Points
| Headset | 1-1/8'' threadless, sealed cartridge bearings |
|---|---|
| Handlebar | Race Face ERA, carbon, 35mm, 40mm rise, 800mm width |
| Stem | Race Face Turbine R, 35mm, 0 degree, 40mm length |
| Saddle | Trek Aeolus Pro, carbon fiber rails, AirLoom lattice 145mm width |
| Seatpost | S: Fox Transfer NEO, 150mm travel, wireless, 34.9mm / M, L: Fox Transfer NEO, 175mm travel, wireless, 34.9mm / XL, XXL: Fox Transfer NEO, 200mm travel, wireless, 34.9mm |
Wheels & Tires
| Wheels | (F) Bontrager Line Pro 30, OCLV Mountain Carbon, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle, 29'' / (R) Bontrager Line Pro 30, OCLV Mountain Carbon, Tubeless Ready, Rapid Drive 108, 6-bolt, Boost148, 12mm thru axle, 29'' |
|---|---|
| Front Tire | S, M, L, XL, XXL: Maxxis Assegai, tubeless ready, 3C, EXO+ casing, MAXXGRIP, folding bead, 29x2.5'' / S, M, L, XL, XXL: Maxxis Minion DHR II, tubeless ready, 3C, EXO+ casing, MAXXTERRA, folding bead, 29x2.5'' |
| Rear Tire | S, M, L, XL, XXL: Maxxis Assegai, tubeless ready, 3C, EXO+ casing, MAXXGRIP, folding bead, 29x2.5'' / S, M, L, XL, XXL: Maxxis Minion DHR II, tubeless ready, 3C, EXO+ casing, MAXXTERRA, folding bead, 29x2.5'' |
| Wheel Size | 29" |
Size-specific frame data
Geometry
Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.
| Measurement | 15.5" (S) | 17.5" (M) | 19.5" (L) | 21.5" (XL) | 23" (XXL) |
|---|---|---|---|---|---|
| Seat tube | 370 mm | 400 mm | 420 mm | 455 mm | 475 mm |
| Effective top tube | 552 mm | 586 mm | 621 mm | 655 mm | 684 mm |
| Head tube | 95 mm | 110 mm | 125 mm | 140 mm | 155 mm |
| Head-tube angle | 63.4° | 63.4° | 63.4° | 63.5° | 63.5° |
| Seat-tube angle | 71.5° | 71.5° | 71.5° | 71.6° | 71.6° |
| Chainstay / rear center | 437 mm | 437 mm | 442 mm | 447 mm | 452 mm |
| Wheelbase | 1200 mm | 1237 mm | 1273 mm | 1310 mm | 1341 mm |
| Bottom-bracket drop | 26 mm | 27 mm | 27 mm | 27 mm | 27 mm |
| Bottom-bracket height | 347 mm | 347 mm | 347 mm | 346 mm | 346 mm |
| Reach | 418 mm | 448 mm | 473 mm | 498 mm | 518 mm |
| Stack | 619 mm | 633 mm | 647 mm | 661 mm | 674 mm |
| Standover height | 750 mm | 752 mm | 759 mm | 765 mm | 773 mm |
| Fork offset / rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Front center | 765 mm | 801 mm | 833 mm | 864 mm | 891 mm |
| Trail | 138 mm | 138 mm | 137 mm | 137 mm | 137 mm |
| Wheel size | 29" | 29" | 29" | 29" | 29" |
Geometry source: Trek first-party OCC sizing data ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.
Gallery
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
