2024 Trek Domane+ SLR 6
Electric-assist bicycle from the Velopedia specification archive.
- Original MSRP
- $7,699.99
- Sizes
- 50; 52; 54; 56; 58; 60; 62
- Colors
- Matte Deep Smoke
- Weight
- 56 - 12.85 kg / 28.33 lbs
- Geometry
- 7 manufacturer sizes
- Archive ID
- 900000648
Recently checked market
0 close matches
Observed used market
No listingsNo close used matches in the latest snapshot.
New asking
No listingsNo close matches in this condition.
View market details Move, scroll, tap or type to start the protected update.
Velopedia analysis
What the specifications mean
The electric-assist system adds another maintenance layer, especially battery condition, charger compatibility, motor operation and any available diagnostic history. Electronic shifting removes the usual shift cable but adds a separate battery and controls, while the 309% cassette range describes how much gearing is available. Hydraulic disc brakes shift routine service toward pad and rotor condition, fluid leaks and use of the correct bleed fluid.
E-bike system
Electric-assist
The drive system needs its own battery, charger, motor-control and diagnostic checks in addition to the bicycle components.
Drivetrain
Electronic · 309% range
Shift-system battery state joins derailleur setup and sprocket compatibility as a troubleshooting variable.
Brake service
Hydraulic disc
Pad and rotor condition plus the correct bleed fluid are the primary service checks.
Tire setup
Tubeless-ready
The rims and tires may support tubeless use, but the bike may still be running tubes.
Used-bike inspection
If you’re buying this bike used
Before any test ride: both brakes should stop the bike firmly and release cleanly; both wheels should run true and be securely attached; tires should have no casing damage; and the headset, handlebar, stem, cranks and pedals should have no looseness or play.
Follow the full used-bike inspection order →- FrameInspect the frame in bright light, especially around the head tube, bottom bracket, chainstays and clamped areas. Look for cracks, ripples, crushed sections or signs of a previous impact.Inspect the frame and fork →
- BrakesBoth levers should feel firm and return cleanly. Check for fluid around the levers and calipers, inspect pad thickness and contamination, and look for worn or bent rotors.Inspect the brakes →
- E-bike systemConfirm the main battery charges with the correct charger, locks securely into its mount and has no case damage, swelling, corrosion or overheating marks. Power the bike on from cold, test every assist mode and ask for available battery-health and diagnostic records.Check the battery and electronics →
- Wheels & tiresSpin both wheels and watch the rims for side-to-side or vertical movement. Check for dents, cracks, loose or uneven spokes and hub play, then inspect both tire casings for cuts, cracking or exposed threads. If it is set up tubeless, confirm both tires hold pressure and ask when the sealant was last refreshed.Check wheels and tires →
Bike-specific inspection checklist 22 checks based on 5 archived component groups Open checklistClose checklist
This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.
Identity and fit
Follow the full used-bike inspection order →Archived: 2024 Trek Domane+ SLR 6 · Electric-assist · Published sizes: 50; 52; 54; 56; 58; 60; 62
Frame and fork
Inspect the frame and fork →Archived: Frame: 800 Series OCLV Carbon, TQ drive system, tapered head tube, rear IsoSpeed, internal routing, flat mount disc, fender mounts, 142x12mm thru axle · Fork: Domane+ carbon, tapered carbon steerer, internal brake routing, fender mounts, flat mount disc, 12x100mm thru axle · Carbon fiber
Drivetrain
Check drivetrain wear →Archived: Group: Shimano 105, 2x12 · Shifters: Shimano 105 R7170 Di2, 12 speed · Front derailleur: Shimano 105 R7150 Di2, braze-on, down swing · Rear derailleur: Shimano R7150 Di2, 36T max cog · Crankset: 50, 52: Praxis Carbon, 170mm length / 54, 56: Praxis Carbon, 172.5mm length / 58, 60, 62: Praxis Carbon, 175mm length · Cassette: Shimano 105 7101, 11-34, 12 speed · Chain: Shimano SLX M7100, 12 speed
Brakes
Inspect the brakes →Archived: Brakes: Shimano Hydraulic Disc / Shimano RT70, centerlock, 160mm
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700c · Wheels: (F) Bontrager Paradigm Comp 25, Tubeless Ready, 25mm rim width, 100x12mm thru axle / (R) Bontrager Paradigm Comp 25, Tubeless Ready, 25mm rim width, Shimano 11/12-speed freehub, 142x12 thru axle · Front tire: Bontrager R3 Hard-Case Lite, Tubeless Ready, aramid bead, 120 tpi, 700x32mm · Rear tire: Bontrager R3 Hard-Case Lite, Tubeless Ready, aramid bead, 120 tpi, 700x32mm
E-bike system
Check the battery and electronics →Archived: Trek Domane+ SLR 6 · electric-assist identification
Before and during the test ride
Follow the full used-bike inspection order →Interpretation based on the archived manufacturer specifications. Confirm exact fit and standards before ordering parts or performing service.
Have you owned this bike?Help preserve its real-world history by sharing your owner experience.
Share the details that would help another rider understand how this model fits, rides and holds up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
Frameset
| Frame Construction | 800 Series OCLV Carbon, TQ drive system, tapered head tube, rear IsoSpeed, internal routing, flat mount disc, fender mounts, 142x12mm thru axle |
|---|---|
| Frame Material | Carbon fiber |
| Fork | Domane+ carbon, tapered carbon steerer, internal brake routing, fender mounts, flat mount disc, 12x100mm thru axle |
| Fork Material | Carbon fiber |
Drivetrain
| Component Group | Shimano 105, 2x12 |
|---|---|
| Shifters | Shimano 105 R7170 Di2, 12 speed |
| Front Derailleur | Shimano 105 R7150 Di2, braze-on, down swing |
| Rear Derailleur | Shimano R7150 Di2, 36T max cog |
| Crankset | 50, 52: Praxis Carbon, 170mm length / 54, 56: Praxis Carbon, 172.5mm length / 58, 60, 62: Praxis Carbon, 175mm length |
| Cassette | Shimano 105 7101, 11-34, 12 speed |
| Chain | Shimano SLX M7100, 12 speed |
Brakes
| Brakes | Shimano Hydraulic Disc / Shimano RT70, centerlock, 160mm |
|---|
Cockpit & Contact Points
| Handlebar | 50, 52: Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 40cm width / 54, 56: Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 42cm width / 58, 60, 62: Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 44cm width |
|---|---|
| Stem | 50: Trek RCS Pro, -7 degree, 80mm length / 52, 54: Trek RCS Pro, -7 degree, 90mm length / 56, 58: Trek RCS Pro, -7 degree, 100mm length / 60, 62: Trek RCS Pro, -7 degree, 110mm length |
| Saddle | 50, 52: Verse Short Elite, hollow magnesium rails, 155mm width / 54, 56, 58, 60, 62: Verse Short Elite, hollow magnesium rails, 145mm width |
| Seatpost | 50, 52, 54, 56: KVF aero carbon seatpost, 20mm offset, 280mm length / 58, 60, 62: KVF aero carbon seatpost, 20mm offset, 320mm length |
Wheels & Tires
| Wheels | (F) Bontrager Paradigm Comp 25, Tubeless Ready, 25mm rim width, 100x12mm thru axle / (R) Bontrager Paradigm Comp 25, Tubeless Ready, 25mm rim width, Shimano 11/12-speed freehub, 142x12 thru axle |
|---|---|
| Front Tire | Bontrager R3 Hard-Case Lite, Tubeless Ready, aramid bead, 120 tpi, 700x32mm |
| Rear Tire | Bontrager R3 Hard-Case Lite, Tubeless Ready, aramid bead, 120 tpi, 700x32mm |
| Wheel Size | 700c |
Size-specific frame data
Geometry
Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.
| Measurement | 50 cm | 52 cm | 54 cm | 56 cm | 58 cm | 60 cm | 62 cm |
|---|---|---|---|---|---|---|---|
| Seat tube | 450 mm | 475 mm | 500 mm | 525 mm | 548 mm | 567 mm | 586 mm |
| Effective top tube | 519 mm | 530 mm | 542 mm | 554 mm | 567 mm | 579 mm | 593 mm |
| Head tube | 130 mm | 145 mm | 160 mm | 175 mm | 195 mm | 220 mm | 245 mm |
| Head-tube angle | 71.1° | 71.3° | 71.3° | 71.9° | 72° | 72.1° | 72.1° |
| Seat-tube angle | 74.6° | 74.2° | 73.7° | 73.3° | 73° | 72.8° | 72.5° |
| Chainstay / rear center | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1007 mm | 1013 mm | 1021 mm | 1018 mm | 1027 mm | 1037 mm | 1047 mm |
| Bottom-bracket drop | 80 mm | 80 mm | 80 mm | 78 mm | 78 mm | 75 mm | 75 mm |
| Reach | 368 mm | 371 mm | 374 mm | 377 mm | 380 mm | 383 mm | 386 mm |
| Stack | 546 mm | 561 mm | 575 mm | 591 mm | 611 mm | 632 mm | 656 mm |
| Standover height | 728 mm | 747 mm | 766 mm | 788 mm | 808 mm | 829 mm | 847 mm |
| Fork offset / rake | 53 mm | 53 mm | 53 mm | 48 mm | 48 mm | 48 mm | 48 mm |
| Trail | 63 mm | 62 mm | 62 mm | 63 mm | 63 mm | 62 mm | 62 mm |
| Wheel size | 700c | 700c | 700c | 700c | 700c | 700c | 700c |
Geometry source: Trek first-party OCC sizing data ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.
