2016 Trek Boone 5 Disc

Original specifications: Shimano 105 · 11-speed rear derailleur · 700c wheels.

Share owner experience

Planning to sell? Draft your listing

No archive photo is available for this record.

At a glance

Archive #1438335
Model year
2016
Category
Gravel & Cyclocross
Original MSRP
$3,199.99
Sizes
50, 52, 54, 56, 58, 61cm
Colors
Trek Black/Trek White
In this record
19 specifications · original MSRP
Original buildCarbon Fiber · Shimano 105 mix · 700c

Manufacturer catalog

Published sizes and colors

6 sizes · 1 color

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

505254565861cm

Published colors

Trek Black/Trek White

Frameset

Frame Construction600 Series OCLV Carbon, IsoSpeed, Ride Tuned seatmast, E2 tapered head tube, Weather Sealed, BB90, internal control routing, 3S chain keeper, disc balanced post mount, hidden fender mounts
Frame MaterialCarbon Fiber
Fork MaterialCarbon Fiber

Drivetrain

Component GroupShimano 105 mix
ShiftersShimano RS685 hydraulic, 11 speed
Rear DerailleurShimano 105
CranksetFSA Energy, 46/36
Rear CogsShimano 105, 11-28, 11 speed
ChainShimano 105

Brakes

BrakesShimano RS685 hydraulic disc, 160mm rotors

Cockpit & Contact Points

HeadsetFSA Integrated, sealed cartridge bearings, 1-1/8" top, 1.5" bottom
HandlebarBontrager Race, VR-C, 31.8mm
StemBontrager Elite, 31.8mm, 7 degree, w/Blendr computer & light mounts
SaddleBontrager Paradigm R, hollow chromoly rails
SeatpostBontrager Ride Tuned carbon seatmast cap, 20mm offset

Wheels & Tires

HubsBontrager disc
RimsBontrager TLR disc
Front TireBontrager CX3 Team Issue, aramid bead, 120tpi, 700x32c
Wheel Size700c

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes46/36T · 11–28T · 11-speed
Lowest1.29:1 Highest4.18:1 Total range325%
Estimated speed At 90 RPM Lowest gear9.3 mph Highest gear30.2 mph

Uses front tire 700C×32; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Front tire · Original
Bontrager CX3 Team Issue

aramid bead, 120tpi, 700x32c

Rear derailleur · Original
Shimano 105 Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.
More parts (8)Fewer parts
Cassette / rear cogs · Original
Shimano 105

11-28, 11 speed

Saddle · Original
Bontrager Paradigm R

hollow chromoly rails

Crankset · Original
FSA Energy

46/36

Handlebar · Original
Bontrager Race

VR-C, 31.8mm

Stem · Original
Bontrager Elite

31.8mm, 7 degree, w/Blendr computer & light mounts

Seatpost · Original
Bontrager Ride Tuned carbon seatmast cap

20mm offset

Headset · Original
FSA Integrated

sealed cartridge bearings, 1-1/8" top, 1.5" bottom

Rims · Original
Bontrager TLR disc

Based on the original build. Check fit and installed parts before ordering.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
Bontrager CX3 Team Issue, aramid bead, 120tpi, 700x32c
Drivetrain
11-speed
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 10 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: 600 Series OCLV Carbon, IsoSpeed, Ride Tuned seatmast, E2 tapered head tube, Weather Sealed, BB90, internal control routing, 3S chain keeper, disc balanced post mount, hidden fender mounts · Fork: · Carbon Fiber

Archived: Group: Shimano 105 mix · Shifters: Shimano RS685 hydraulic, 11 speed · Rear derailleur: Shimano 105 · Crankset: FSA Energy, 46/36 · Rear cogs: Shimano 105, 11-28, 11 speed · Chain: Shimano 105

Archived: Brakes: Shimano RS685 hydraulic disc, 160mm rotors

Archived: Wheel size: 700c · Rims: Bontrager TLR disc · Hubs: Bontrager disc · Front tire: Bontrager CX3 Team Issue, aramid bead, 120tpi, 700x32c

Controls and contact points

Archived: Headset: FSA Integrated, sealed cartridge bearings, 1-1/8" top, 1.5" bottom · Handlebar: Bontrager Race, VR-C, 31.8mm · Stem: Bontrager Elite, 31.8mm, 7 degree, w/Blendr computer & light mounts · Seatpost: Bontrager Ride Tuned carbon seatmast cap, 20mm offset · Saddle: Bontrager Paradigm R, hollow chromoly rails
