2015 Trek Superfly FS 7

Archived: 2015 Trek Superfly FS 7 · Mountain Dual Suspension · Published sizes: 15.5, 17.5, 18.5, 19.5, 21.5, 23"

• Confirm the frame markings and seller description match this archived model. Note every component that differs from the published build.
• Record the frame serial number. It should be legible, unaltered and consistent with the seller’s ownership history.
• Find the size marking on the bicycle and confirm the fit before judging the condition or price.

Archived: Frame: Alpha Platinum Aluminum, ABP Convert, E2 tapered head tube, internal derailleur & dropper post routing, press fit BB, Flow Mold carbon swing link, G2 Geometry, 100mm travel · Fork: RockShox Reba RL, Solo Air spring, rebound, Motion Control remote lockout, E2 tapered steerer, 15mm Maxle Lite, custom G2 Geometry w/51mm offset, 100mm travel · Suspension

• Inspect composite areas in bright light for impact marks, cracks, ripples or crushed clamp zones. Check metal sections and welds separately for dents or cracking.
• Stand behind and in front of the bicycle to look for obvious frame, fork or wheel misalignment. Ask directly about crashes, transport damage and repairs.

Archived: Fork: RockShox Reba RL, Solo Air spring, rebound, Motion Control remote lockout, E2 tapered steerer, 15mm Maxle Lite, custom G2 Geometry w/51mm offset, 100mm travel · Rear shock: RockShox Monarch RL, rebound, lockout, 6.5x1.5"

• Inspect the fork stanchions for scratches or coating wear, look for oil or dirt rings at the seals, and cycle the fork through its travel while checking for binding or bushing play.
• Inspect the shock shaft and seals, cycle the rear suspension through its travel and check for oil, air loss, binding or unusual top-out and bottom-out noises.
• Hold the rear brake and load the suspension from several directions. Check pivots, bearings and mounting hardware for knock, looseness or side play.
• Ask for dated fork, shock and pivot-service records. A clean exterior does not establish the condition of internal seals, oil, bushings or bearings.

Archived: Group: Shimano Deore mix · Shifters: Shimano Deore, 10 speed · Front derailleur: SRAM X7, low direct mount · Rear derailleur: Shimano Deore XT, Shadow Plus · Crankset: FSA F2000, 36/22 · Bottom bracket: Press Fit · Rear cogs: Shimano HG50, 11-36, 10 speed · Chain: KMC X10

• Shift through every available gear under light load. Hesitation, skipping or inconsistent indexing can reflect wear, damage, poor adjustment or mismatched replacement parts.
• Measure chain wear with a compatible gauge and inspect chainring, cassette or freewheel teeth. A new chain does not rule out wear in the remaining drivetrain.
• Turn the cranks slowly, feel for rough bearings and check for side-to-side play. Inspect crank arms, chainring bolts and pedal threads for looseness or damage.

Archived: Brakes: Shimano Deore hydraulic disc

• Squeeze each lever firmly. It should feel consistent and return cleanly. Check levers, hoses and calipers for fluid, inspect pad thickness and contamination, and examine rotors for wear or bending.
• Before riding, test every installed brake separately at walking speed. Each should stop firmly and release cleanly without its control reaching the end of its usable travel.

Archived: Wheel size: 29 · Rims: Bontrager Mustang Elite Tubeless Ready, 142x12 rear, 15mm front · Hubs: Bontrager Mustang Elite Tubeless Ready, 142x12 rear, 15mm front · Front tire: Bontrager XR1 Expert, Tubeless Ready, aramid bead, 29x2.20"

• Spin both wheels and watch for side-to-side and vertical movement. Check spoke tension, rim condition and hub play.
• Inspect both tire casings for cuts, cracking, plugs, bulges or exposed threads and confirm the installed sizes are safe for the rims and available frame and fork clearance.
• Remove and reinstall or closely inspect both wheel-retention systems. Axles or quick releases should tighten correctly with undamaged threads, hardware and dropouts.
• Confirm whether the bike is actually set up tubeless, whether both tires hold pressure, and when sealant and rim tape were last serviced.

Archived: Headset: FSA IS-2, E2, alloy cartridge · Handlebar: Bontrager Low Riser, 31.8mm, 5mm rise · Stem: Bontrager Race Lite, 31.8mm, 7 degree · Seatpost: Bontrager SSR, 2-bolt head, 31.6mm, 12mm offset · Saddle: Bontrager Evoke 2, chromoly rails

• Apply the front brake and rock the bike to check for headset play or notchiness. Inspect the stem, handlebar and clamp zones, then confirm every fastener and control is secure.
• Check that the seatpost moves for adjustment and that the saddle, post and clamp hold securely without cracks, severe corrosion or damaged hardware.

• Before riding, confirm both wheels are secure, tires are safe, both brakes function, and the headset, handlebar, stem, cranks and pedals have no looseness.
• Begin at low speed. Test steering, braking and shifting progressively, then load the drivetrain and suspension only after the basic safety checks pass.
• Listen and feel for repeated knocks, grinding, skipping, brake pulsation or movement at joints. Stop the test if the bicycle cannot be controlled safely.
