Uses front tire 29×2.3; rear size isn’t listed.
Velopedia Bicycle Archive
2015 Trek Fuel EX 7 29
Original specifications: Shimano SLX · 10-speed rear derailleur · 29 wheels.
Planning to sell? Draft your listing
No archive photo is available for this record.
At a glance
Archive #1530591- Model year
- 2015
- Category
- Mountain
- Original MSRP
- $2,629.99
- Sizes
- 15.5, 17.5, 18.5, 19.5, 21.5, 23"
- Colors
- Liquid Orange/Trek Black, Black Titanite/Trek Cyan
- In this record
- 23 specifications · original MSRP
Model history 2 other years
Browse other years
Compare side by side
Identification clues
2015 archived details
- Published colors
- Liquid Orange/Trek Black, Black Titanite/Trek Cyan
- Frame
- Aluminum
- Original equipment
- Mountian mix
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildAluminum · Mountian mix · 29
Frameset
| Frame Construction | Alpha Platinum Aluminum, ABP Convert, Full Floater, E2 tapered head tube, press fit BB, magnesium EVO link, down tube guard, G2 Geometry, 120mm travel |
|---|---|
| Frame Material | Aluminum |
| Fork | Fox Evolution Series 32 Float, CTD (climb-trail-descend) damper, rebound, E2 tapered steerer, 15QR, custom G2 Geometry w/51mm offset, 120mm travel |
| Fork Material | Suspension |
| Rear Shock | Fox Evolution Series Float, DRCV, CTD (climb-trail-descend) damper, rebound, tuned by Trek in California, 7.25x1.875" |
Drivetrain
| Component Group | Mountian mix |
|---|---|
| Shifters | Shimano Deore, 10 speed |
| Front Derailleur | SRAM X5, high direct mount |
| Rear Derailleur | Shimano SLX, Shadow Plus |
| Crankset | SRAM S1010, 36/22 |
| Bottom Bracket | Press Fit |
| Rear Cogs | Shimano HG50, 11-36, 10 speed |
| Chain | KMC X10 |
Brakes
| Brakes | Shimano Deore hydraulic disc |
|---|
Cockpit & Contact Points
| Headset | FSA IS-2, E2, alloy cartridge |
|---|---|
| Handlebar | Bontrager Low Riser, 31.8mm, 5mm rise |
| Stem | Bontrager Race Lite, 31.8mm, 7 degree |
| Saddle | Bontrager Evoke 2, chromoly rails |
| Seatpost | Bontrager SSR, 2-bolt head, 31.6mm, 12mm offset |
Wheels & Tires
| Hubs | Bontrager Duster Elite Tubeless Ready, 142x12 rear, 15mm front |
|---|---|
| Rims | Bontrager Duster Elite Tubeless Ready, 142x12 rear, 15mm front |
| Front Tire | Bontrager XR3 Expert, aramid bead, 29x2.30" |
| Wheel Size | 29 |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
aramid bead, 29x2.30"

Hutchinson Python 2 29in Tire Black, 29x2.3
Replacement option
11-36, 10 speed
More parts (10)Fewer parts
chromoly rails
36/22
high direct mount
Shadow Plus
10 speed
31.8mm, 7 degree
2-bolt head, 31.6mm, 12mm offset
E2, alloy cartridge
142x12 rear, 15mm front
142x12 rear, 15mm front
Based on the original build. Check fit and installed parts before ordering.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- Bontrager XR3 Expert, aramid bead, 29x2.30"
- Drivetrain
- 10-speed
- Seatpost diameter
- 31.6 mm
- Bottom bracket / shell
- Press Fit
Equipment inspection checks 14 checks based on 6 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: Alpha Platinum Aluminum, ABP Convert, Full Floater, E2 tapered head tube, press fit BB, magnesium EVO link, down tube guard, G2 Geometry, 120mm travel · Fork: Fox Evolution Series 32 Float, CTD (climb-trail-descend) damper, rebound, E2 tapered steerer, 15QR, custom G2 Geometry w/51mm offset, 120mm travel · Suspension
Suspension
Evaluate the suspension →Archived: Fork: Fox Evolution Series 32 Float, CTD (climb-trail-descend) damper, rebound, E2 tapered steerer, 15QR, custom G2 Geometry w/51mm offset, 120mm travel · Rear shock: Fox Evolution Series Float, DRCV, CTD (climb-trail-descend) damper, rebound, tuned by Trek in California, 7.25x1.875"
Drivetrain
Check drivetrain wear →Archived: Group: Mountian mix · Shifters: Shimano Deore, 10 speed · Front derailleur: SRAM X5, high direct mount · Rear derailleur: Shimano SLX, Shadow Plus · Crankset: SRAM S1010, 36/22 · Bottom bracket: Press Fit · Rear cogs: Shimano HG50, 11-36, 10 speed · Chain: KMC X10
Brakes
Inspect the brakes →Archived: Brakes: Shimano Deore hydraulic disc
Wheels and tires
Check wheels and tires →Archived: Wheel size: 29 · Rims: Bontrager Duster Elite Tubeless Ready, 142x12 rear, 15mm front · Hubs: Bontrager Duster Elite Tubeless Ready, 142x12 rear, 15mm front · Front tire: Bontrager XR3 Expert, aramid bead, 29x2.30"
Controls and contact points
Archived: Headset: FSA IS-2, E2, alloy cartridge · Handlebar: Bontrager Low Riser, 31.8mm, 5mm rise · Stem: Bontrager Race Lite, 31.8mm, 7 degree · Seatpost: Bontrager SSR, 2-bolt head, 31.6mm, 12mm offset · Saddle: Bontrager Evoke 2, chromoly rails
