Velopedia Bicycle Archive

2015 Trek District 8

Original specifications: Commuter mix drivetrain · 700c wheels.

Share owner experience

Planning to sell? Draft your listing

No archive photo is available for this record.

At a glance

Archive #1063503
Model year
2015
Category
City & Commuter
Original MSRP
$609.99
Sizes
50, 54, 56, 58, 61cm
Colors
Copper Metallic
In this record
22 specifications · original MSRP
Original buildSteel · Commuter mix · 700c

Manufacturer catalog

Published sizes and colors

5 sizes · 1 color

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

5054565861cm

Published colors

Copper Metallic

Frameset

Frame ConstructionTrek Custom Steel w/inboard rear disc brake mounts, rack & fender mounts
Frame MaterialSteel
ForkHigh-tensile steel
Fork MaterialHigh tensile Steel

Drivetrain

Component GroupCommuter mix
ShiftersShimano Altus M310, 8 speed
Front DerailleurNone
Rear DerailleurShimano Acera
CranksetForged alloy 3 piece, 45T
Rear CogsSRAM PG-830, 11-32, 8 speed
ChainKMC X9
PedalsNylon body w/alloy cage

Brakes

BrakesTektro Novela mechanical disc brakes, 160mm rotors, Tektro adjustable-reach alloy levers

Cockpit & Contact Points

Headset1-1/8" Threadless
HandlebarBontrager Urban, 31.8mm, 25mm rise
StemBontrager Race Lite, 31.8mm, 7 degree
SaddleBontrager SSR
SeatpostBontrager Alloy, 2-bolt head, 27.2mm, 8mm offset

Wheels & Tires

HubsFormula DC20 alloy, Formula DC22 alloy
Rims32-hole double-walled alloy
Front TireBontrager AW1 Hard-Case Lite, 700x32c
Wheel Size700c

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes45T · 11–32T · 8-speed
Lowest1.41:1 Highest4.09:1 Total range291%
Estimated speed At 90 RPM Lowest gear10.2 mph Highest gear29.6 mph

Uses front tire 700C×32; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Front tire · Original
Bontrager AW1 Hard-Case Lite

700x32c

Cassette / rear cogs · Original
SRAM PG-830

11-32, 8 speed

Saddle · Original
Bontrager SSR
More parts (5)Fewer parts
Shifters · Original
Shimano Altus M310

8 speed

Handlebar · Original
Bontrager Urban

31.8mm, 25mm rise

Stem · Original
Bontrager Race Lite

31.8mm, 7 degree

Seatpost · Original
Bontrager Alloy

2-bolt head, 27.2mm, 8mm offset

Hubs · Original
Formula DC20 alloy

Formula DC22 alloy

Based on the original build. Check fit and installed parts before ordering.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
Bontrager AW1 Hard-Case Lite, 700x32c
Drivetrain
8-speed
Seatpost diameter
27.2 mm
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 10 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: Trek Custom Steel w/inboard rear disc brake mounts, rack & fender mounts · Fork: High-tensile steel · High tensile Steel

Archived: Group: Commuter mix · Shifters: Shimano Altus M310, 8 speed · Rear derailleur: Shimano Acera · Crankset: Forged alloy 3 piece, 45T · Rear cogs: SRAM PG-830, 11-32, 8 speed · Chain: KMC X9

Archived: Brakes: Tektro Novela mechanical disc brakes, 160mm rotors, Tektro adjustable-reach alloy levers

Archived: Wheel size: 700c · Rims: 32-hole double-walled alloy · Hubs: Formula DC20 alloy, Formula DC22 alloy · Front tire: Bontrager AW1 Hard-Case Lite, 700x32c

Controls and contact points

Archived: Headset: 1-1/8" Threadless · Handlebar: Bontrager Urban, 31.8mm, 25mm rise · Stem: Bontrager Race Lite, 31.8mm, 7 degree · Seatpost: Bontrager Alloy, 2-bolt head, 27.2mm, 8mm offset · Saddle: Bontrager SSR · Pedals: Nylon body w/alloy cage
