Uses front tire 700C×32; rear size isn’t listed.
Velopedia Bicycle Archive
2015 Trek Boone 9 Disc Di2
Original specifications: Shimano Ultegra Di2 drivetrain · 700c wheels.
Planning to sell? Draft your listing
No archive photo is available for this record.
At a glance
Archive #1095340- Model year
- 2015
- Category
- Gravel & Cyclocross
- Original MSRP
- $6,299.99
- Sizes
- 50, 52, 54, 56, 58, 61cm
- Colors
- Matte Trek Black
- In this record
- 22 specifications · original MSRP
Original buildCarbon Fiber · Shimano Ultegra Di2 · 700c
Frameset
| Frame Construction | 600 Series OCLV Carbon, IsoSpeed, Ride Tuned seatmast, disc balanced post mount, E2 tapered head tube, BB90, internal control routing, 3S chain keeper, vanishing fender mounts |
|---|---|
| Frame Material | Carbon Fiber |
| Fork | Trek IsoSpeed Cross carbon disc, E2 |
| Fork Material | Carbon Fiber |
Drivetrain
| Component Group | Shimano Ultegra Di2 |
|---|---|
| Shifters | Shimano RS785 hydraulic Di2, 11 speed |
| Front Derailleur | Shimano Ultegra Di2, braze-on |
| Rear Derailleur | Shimano Ultegra Di2 |
| Crankset | Shimano Ultegra, 46/36 |
| Bottom Bracket | Bb90 |
| Rear Cogs | Shimano Ultegra 11-28, 11 speed |
| Chain | Shimano Ultegra |
Brakes
| Brakes | Shimano RS785 hydraulic disc, 160mm rotors |
|---|
Cockpit & Contact Points
| Headset | Integrated, cartridge bearings, sealed, 1-1/8" top, 1.5" bottom |
|---|---|
| Handlebar | Bontrager Race Lite IsoZone, VR-CF, 31.8mm |
| Stem | Bontrager Race X Lite, 31.8mm, 7 degree |
| Saddle | Bontrager Evoke 3, hollow titanium rails |
| Seatpost | Bontrager Ride Tuned Carbon seatmast cap, 20mm offset |
Wheels & Tires
| Hubs | HED Ardennes + centerlock disc |
|---|---|
| Rims | HED Ardennes + centerlock disc |
| Front Tire | Bontrager CX3 Team Issue, 700x32c |
| Wheel Size | 700c |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Shimano SLX/105 CN-HG601 11-Speed Chain
Replacement option
700x32c

Specialized Nimbus 2 Tire Black, 700x32
700x32c
Replacement option
braze-on

Shimano Ultegra Di2 FD-R8050 Front Derailleur Gray, Braze-On
Specification match
More parts (7)Fewer parts
11 speed
hollow titanium rails
46/36
VR-CF, 31.8mm
31.8mm, 7 degree
20mm offset
Based on the original build. Check fit and installed parts before ordering.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- Bontrager CX3 Team Issue, 700x32c
- Drivetrain
- 11-speed
- Bottom bracket / shell
- BB90
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: 600 Series OCLV Carbon, IsoSpeed, Ride Tuned seatmast, disc balanced post mount, E2 tapered head tube, BB90, internal control routing, 3S chain keeper, vanishing fender mounts · Fork: Trek IsoSpeed Cross carbon disc, E2 · Carbon Fiber
Drivetrain
Check drivetrain wear →Archived: Group: Shimano Ultegra Di2 · Shifters: Shimano RS785 hydraulic Di2, 11 speed · Front derailleur: Shimano Ultegra Di2, braze-on · Rear derailleur: Shimano Ultegra Di2 · Crankset: Shimano Ultegra, 46/36 · Bottom bracket: BB90 · Rear cogs: Shimano Ultegra 11-28, 11 speed · Chain: Shimano Ultegra
Brakes
Inspect the brakes →Archived: Brakes: Shimano RS785 hydraulic disc, 160mm rotors
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700c · Rims: HED Ardennes + centerlock disc · Hubs: HED Ardennes + centerlock disc · Front tire: Bontrager CX3 Team Issue, 700x32c
Controls and contact points
Archived: Headset: Integrated, cartridge bearings, sealed, 1-1/8" top, 1.5" bottom · Handlebar: Bontrager Race Lite IsoZone, VR-CF, 31.8mm · Stem: Bontrager Race X Lite, 31.8mm, 7 degree · Seatpost: Bontrager Ride Tuned Carbon seatmast cap, 20mm offset · Saddle: Bontrager Evoke 3, hollow titanium rails
