2014 Trek CrossRip Comp

Original specifications.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #9258597
Model year
2014
Sizes
49 cm, 52 cm, 54 cm, 56 cm, 58 cm, 61 cm
Colors
Matte Trek Black
In this record
16 specifications · archived image
Model history 2 other years

Browse other years

Compare side by side

Identification clues

2014 archived details

Published colors
Matte Trek Black
Frame
100 Series Alpha Aluminum

Clues, not proof of model year. Colors vary and components may have been replaced.

Sponsored affiliate link
Original build100 Series Alpha Aluminum

Manufacturer catalog

Published sizes and colors

6 sizes · 1 color

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

49 cm52 cm54 cm56 cm58 cm61 cm

Published colors

Matte Trek Black

Frameset

Frame Material100 Series Alpha Aluminum
ForkBontrager Satellite Plus

Drivetrain

ShiftersShimano Claris STI, 8 speed
Front DerailleurShimano Claris
Rear DerailleurShimano Claris
CranksetFSA Vero, 50/39/30 (triple)
CassetteSRAM PG-830 11-28, 8 speed
PedalsNylon body w/alloy cage

Brakes

BrakesAvid BB5

Cockpit & Contact Points

HeadsetCartridge bearings, sealed
HandlebarBontrager Race Lite IsoZone
StemBontrager Race Lite 31.8mm
SaddleBontrager Evoke 1
SeatpostBontrager SSR 27.2mm

Wheels & Tires

RimsBontrager Nebula Disc Rims
Front TireBontrager H5 Hard-Case Ult

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

All published sizes50/39/30T · 11–28T · 8-speed
Lowest1.07:1 Highest4.55:1 Total range424%

Speed unavailable: wheel or tire size is missing or unclear.

Add your rear tire size to calculate speed
How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Seatpost · Original
Bontrager SSR 27.2mm
Retailer offers
Cassette · Original
SRAM PG-830 11-28

8 speed

Saddle · Original
Bontrager Evoke 1
More parts (7)Fewer parts
Crankset · Original
FSA Vero

50/39/30 (triple)

Front derailleur · Original
Shimano Claris
Rear derailleur · Original
Shimano Claris
Shifters · Original
Shimano Claris STI

8 speed

Handlebar · Original
Bontrager Race Lite IsoZone
Stem · Original
Bontrager Race Lite 31.8mm
Rims · Original
Bontrager Nebula Disc Rims

Based on the original build. Check fit and installed parts before ordering.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
Bontrager H5 Hard-Case Ult
Drivetrain
8-speed
Seatpost diameter
27.2 mm
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 10 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: 100 Series Alpha Aluminum · Fork: Bontrager Satellite Plus

Archived: Shifters: Shimano Claris STI, 8 speed · Front derailleur: Shimano Claris · Rear derailleur: Shimano Claris · Crankset: FSA Vero, 50/39/30 (triple) · Cassette: SRAM PG-830 11-28, 8 speed

Archived: Brakes: Avid BB5

Archived: Rims: Bontrager Nebula Disc Rims · Front tire: Bontrager H5 Hard-Case Ult

Controls and contact points

Archived: Headset: Cartridge bearings, sealed · Handlebar: Bontrager Race Lite IsoZone · Stem: Bontrager Race Lite 31.8mm · Seatpost: Bontrager SSR 27.2mm · Saddle: Bontrager Evoke 1 · Pedals: Nylon body w/alloy cage
