Uses front tire 700C×25; rear size isn’t listed.
Velopedia Bicycle Archive
2002 Trek 1200
Original specifications: Shimano Tiagra · 9-speed · mechanical rear derailleur · 700c wheels · legacy reference geometry.
Planning to sell? Draft your listing
At a glance
Archive #37523- Model year
- 2002
- Category
- Road
- Original MSRP
- $1,049.99
- Sizes
- 52cm, 54cm, 56cm, 58cm, 60cm
- Colors
- Grey
- Geometry
- Legacy reference
- In this record
- 25 specifications · archived image · original MSRP · geometry
Model history 7 other years
Browse other years
Compare side by side
Identification clues
2002 archived details
- Published colors
- Grey
- Frame
- Aluminum
- Original equipment
- Road Mix Triple
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildAluminum · Road Mix Triple · 700c wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Aluminum |
| Fork | Trek |
| Fork Material | Aluminum, aero crown |
Drivetrain
| Component Group | Road Mix Triple |
|---|---|
| Shifters | Shimano Tiagra STI Dual Control |
| Front Derailleur | Shimano Tiagra |
| Rear Derailleur | Shimano Tiagra GS |
| Crankset | Shimano Tiagra Triple, 30/42/52 teeth |
| BB Shell Width | 68mm English |
| Rear Cogs | 9-speed, 12 - 25 teeth |
| Chain | 1/2 x 3/32" |
| Pedals | Aluminum w/clips & straps |
Brakes
| Brakes | Aluminum Dual Pivot brakes, Shimano Tiagra STI Dual Control levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless Dia-Compe STR |
|---|---|
| Handlebar | Aluminum drop bar |
| Handlebar Extensions | Not included |
| Stem | Aluminum threadless |
| Saddle | Selle San Marco New Millenium |
| Seatpost | Aluminum micro-adjust |
Wheels & Tires
| Hubs | Aluminum, Q/R |
|---|---|
| Rims | Matrix Aurora, 32-hole |
| Spokes | Stainless steel, 14ga. (2.0mm) straight gauge |
| Front Tire | 700 x 25c IRC Red Storm |
| Wheel Size | 700c wheels |
No specifications match. Try a component name or clear your search.
Geometry
Historical measurements. Frame size unknown.
Reference drawing
Select an available measurement to locate it on the frame.
All geometry measurementsLegacy reference · 5 measurements
| Measurement | Legacy reference |
|---|---|
| Top tube | 564 mm |
| Head-tube angle | 73.8° |
| Seat-tube angle | 73.5° |
| Chainstay / rear center | 412 mm |
| Wheelbase | 993 mm |
Frame size not recorded.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
30/42/52 teeth
More parts (2)Fewer parts
Based on the original build. Check fit and installed parts before ordering.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 700 x 25c IRC Red Storm
- Drivetrain
- 9-speed
- Bottom bracket / shell
- 68mm English
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Trek · Aluminum, aero crown
Drivetrain
Check drivetrain wear →Archived: Group: Road Mix Triple · Shifters: Shimano Tiagra STI Dual Control · Front derailleur: Shimano Tiagra · Rear derailleur: Shimano Tiagra GS · Crankset: Shimano Tiagra Triple, 30/42/52 teeth · Rear cogs: 9-speed, 12 - 25 teeth · Chain: 1/2 x 3/32"
Brakes
Inspect the brakes →Archived: Brakes: Aluminum Dual Pivot brakes, Shimano Tiagra STI Dual Control levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700c wheels · Rims: Matrix Aurora, 32-hole · Hubs: Aluminum, Q/R · Front tire: 700 x 25c IRC Red Storm
Controls and contact points
Archived: Headset: 1 1/8" threadless Dia-Compe STR · Handlebar: Aluminum drop bar · Stem: Aluminum threadless · Seatpost: Aluminum micro-adjust · Saddle: Selle San Marco New Millenium · Pedals: Aluminum w/clips & straps
Have you owned this model?Help preserve its real-world history by sharing your owner experience.
Share the details that would help another rider understand how this model fits, rides and holds up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
Used price & market
Checked Nov 15, 2026We may earn a commission from purchases through these eBay links.
Used · Fixed price · offers accepted · USD 764.15
Seller size: 52 cm
Shipping shown: $119.00; confirm for your destination.
Model year not confirmed
Used · Fixed price · offers accepted · USD 195.00
Model year not confirmed
Asking prices, not completed sales. Shipping and tax excluded. Condition, size and service history affect used value; this is not an appraisal.
Stored price evidence is shown above. Check eBay for a newer observation.
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
