2001 Trek 6700 WSD
Original specifications: Shimano Deore LX · 9-speed · mechanical rear derailleur · legacy reference geometry.
Planning to sell? Draft your listing
At a glance
Archive #35728- Model year
- 2001
- Category
- Mountain
- Original MSRP
- $879.99
- Sizes
- Womens 14", womens 16", womens 18"
- Colors
- Silver
- Geometry
- Legacy reference
- In this record
- 23 specifications · archived image · original MSRP · geometry
Model history 10 other years
Browse other years
Compare side by side
Identification clues
2001 archived details
- Published colors
- Silver
- Frame
- Alpha ZX aluminum
- Original equipment
- Mountain Mix
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildAlpha ZX aluminum · Mountain Mix
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Alpha ZX aluminum |
| Fork | Rock Shox Judy C, 3.15" travel |
| Fork Material | Aluminum/magnesium, triple-clamp crown |
Drivetrain
| Component Group | Mountain Mix |
|---|---|
| Shifters | Shimano Deore |
| Front Derailleur | Shimano Deore |
| Rear Derailleur | Shimano Deore LX SGS |
| Crankset | Bontrager Comp, 22/32/44 teeth |
| Rear Cogs | 9-speed, 11 - 32 teeth |
| Chain | 1/2 x 3/32" |
| Pedals | Aluminum ATB |
Brakes
| Brakes | Shimano M420 brakes, aluminum linear-pull levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless Dia-Compe STR |
|---|---|
| Handlebar | Bontrager CrowBar Sport |
| Handlebar Extensions | Not included |
| Stem | Bontrager Comp |
| Saddle | Bontrager FS 2000 WSD |
| Seatpost | Bontrager Sport |
Wheels & Tires
| Hubs | Aluminum |
|---|---|
| Rims | Front: Bontrager Super Stock, Rear: Bontrager SuperStock |
| Spokes | DT stainless steel, 2.0mm |
| Front Tire | Bontrager Jones AC |
No specifications match. Try a component name or clear your search.
Geometry
Historical measurements. Frame size unknown.
Reference drawing
Select an available measurement to locate it on the frame.
All geometry measurementsLegacy reference · 6 measurements
| Measurement | Legacy reference |
|---|---|
| Top tube | 533.4 mm |
| Head-tube angle | 70° |
| Seat-tube angle | 74° |
| Chainstay / rear center | 424.2 mm |
| Wheelbase | 1023.6 mm |
| Fork offset / rake | 40.6 mm |
Frame size not recorded.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM = pedal turns per minute.
Speed unavailable: wheel or tire size is missing or unclear.
Add your rear tire size to calculate speedHow it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Affiliate links may earn Velopedia a commission.
22/32/44 teeth
More parts (5)Fewer parts
Based on the original build. Check fit and installed parts before ordering.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- Bontrager Jones AC
- Drivetrain
- 9-speed
Equipment inspection checks 11 checks based on 6 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Rock Shox Judy C, 3.15" travel · Aluminum/magnesium, triple-clamp crown
Suspension
Evaluate the suspension →Archived: Fork: Rock Shox Judy C, 3.15" travel
Drivetrain
Check drivetrain wear →Archived: Group: Mountain Mix · Shifters: Shimano Deore · Front derailleur: Shimano Deore · Rear derailleur: Shimano Deore LX SGS · Crankset: Bontrager Comp, 22/32/44 teeth · Rear cogs: 9-speed, 11 - 32 teeth · Chain: 1/2 x 3/32"
Brakes
Inspect the brakes →Archived: Brakes: Shimano M420 brakes, aluminum linear-pull levers
Wheels and tires
Check wheels and tires →Archived: Rims: Front: Bontrager Super Stock, Rear: Bontrager SuperStock · Hubs: Aluminum · Front tire: Bontrager Jones AC
Controls and contact points
Archived: Headset: 1 1/8" threadless Dia-Compe STR · Handlebar: Bontrager CrowBar Sport · Stem: Bontrager Comp · Seatpost: Bontrager Sport · Saddle: Bontrager FS 2000 WSD · Pedals: Aluminum ATB
