Lowest1.29:1
Highest3.14:1
Total range243%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 26×2.125; rear size isn’t listed.
Velopedia Bicycle Archive
2001 Sun Bicycles Key West Aluminum
Original specifications: Cruiser Mix drivetrain · 26" wheels · 29 lb published weight.
Planning to sell? Draft your listing
No archive photo is available for this record.
At a glance
Archive #35912- Model year
- 2001
- Category
- Cruiser
- Sizes
- 19", 21", womens 17", womens 19"
- Colors
- Black, Blue, Polished, Red
- Weight
- 29 lb
- In this record
- 24 specifications
Model history 3 other years
Browse other years
Compare side by side
Identification clues
2001 archived details
- Published colors
- Black, Blue, Polished, Red
- Frame
- 7005 aluminum
- Original equipment
- Cruiser Mix
Clues, not proof of model year. Colors vary and components may have been replaced.
Original build7005 aluminum · Cruiser Mix · 26" wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 7005 aluminum |
| Fork | Sun Bicycles Fat Fork |
| Fork Material | Hi-tensile steel, oversize, unicrown crown |
Drivetrain
| Component Group | Cruiser Mix |
|---|---|
| Shifters | SRAM MRX |
| Rear Derailleur | Shimano MR-40 |
| Crankset | Dotek aluminum, 44 teeth |
| Bottom Bracket | Sealed cartridge |
| Rear Cogs | 7-speed, 14 - 34 teeth |
| Chain | KMC Z-30, 1/2 x 3/32" |
| Pedals | Wellgo LU-990 |
Brakes
| Brakes | Tektro 825A linear-pull brakes, Tektro 380 levers |
|---|
Cockpit & Contact Points
| Headset | 1" steel |
|---|---|
| Handlebar | Steel hi-rise |
| Stem | Aluminum |
| Saddle | Viscount 2350 |
| Seatpost | Aluminum, 27.2mm diameter |
Wheels & Tires
| Hubs | Front: Joy Tech aluminum, nutted, Rear: aluminum |
|---|---|
| Rims | Aluminum, 36-hole |
| Spokes | Stainless steel, 2.0mm straight gauge |
| Spoke Nipples | Brass nipples |
| Front Tire | 26 x 2.125" Kenda K-847 |
| Wheel Size | 26" wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Aluminum
27.2mm diameter
Retailer offers
Race Face Ride XC Seatpost Black, 27.2x375mm
Replacement option
KMC Z-30
1/2 x 3/32"
26 x 2.125" Kenda K-847
Replacement search: 26x2.125 bicycle tire Before ordering: Check rim type and tire clearance.
More parts (2)Fewer parts
Tektro 825A linear-pull brakes
Tektro 380 levers
Wellgo LU-990
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 26 x 2.125" Kenda K-847
- Drivetrain
- 7-speed
- Seatpost diameter
- 27.2 mm
- Bottom bracket / shell
- Sealed cartridge
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Sun Bicycles Fat Fork · Hi-tensile steel, oversize, unicrown crown
Drivetrain
Check drivetrain wear →Archived: Group: Cruiser Mix · Shifters: SRAM MRX · Rear derailleur: Shimano MR-40 · Crankset: Dotek aluminum, 44 teeth · Bottom bracket: Sealed cartridge · Rear cogs: 7-speed, 14 - 34 teeth · Chain: KMC Z-30, 1/2 x 3/32"
Brakes
Inspect the brakes →Archived: Brakes: Tektro 825A linear-pull brakes, Tektro 380 levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 26" wheels · Rims: Aluminum, 36-hole · Hubs: Front: Joy Tech aluminum, nutted, Rear: aluminum · Front tire: 26 x 2.125" Kenda K-847
Controls and contact points
Archived: Headset: 1" steel · Handlebar: Steel hi-rise · Stem: Aluminum · Seatpost: Aluminum, 27.2mm diameter · Saddle: Viscount 2350 · Pedals: Wellgo LU-990
