2026 Spot Acme

Original specifications: 700c wheels · geometry for 5 published sizes.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #900001750
Model year
2026
Category
City & Commuter
Original MSRP
$2,399.00
Sizes
50, 52, 55, 57, 60, Open
Colors
Shelby Blue, Helicopter Black
Geometry
5 manufacturer sizes
In this record
9 specifications · 6 archived images · original MSRP · geometry
Sponsored affiliate link
Original buildAluminum · 700c

Manufacturer catalog

Published sizes and colors

6 sizes · 2 colors

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

5052555760Open

Published colors

Shelby BlueHelicopter Black

Frameset

Frame ConstructionSpot Custom 7005 Aluminum Frame
Frame MaterialAluminum

Drivetrain

PedalsBlack body/Black cage

Cockpit & Contact Points

Headset10-Series, zS56 Bottom, 10, ZS44 Short
HandlebarAlloy, 31.8mm, 620mm width, 9 deg sweep
StemAlloy, 31.8 clamp, +/-6 degree, 50/52cm = 100mm, 55/57cm = 110mm, 60cm = 120mm
SaddleSpot performance fit, black with grey accent
SeatpostSpot black alloy, 27.2mm

Wheels & Tires

Wheel Size700c

Geometry

5 sizes · 11 measurements

Frame measurements by size.

All geometry measurements6 size / setup combinations · 11 measurements
MeasurementOpen50cm52cm55cm57cm60cm
Seat tube420 mm496 mm520 mm550 mm570 mm600 mm
Top tube560 mm530 mm550 mm570 mm590 mm620 mm
Head tube115 mm115 mm125 mm140 mm160 mm180 mm
Head-tube angle71°70°71°72°72.5°72.5°
Seat-tube angle74°74°74°73°73°73°
Chainstay / rear center427 mm427 mm427 mm427 mm427 mm427 mm
Wheelbase1025 mm1004 mm1015 mm1016 mm1031 mm1061 mm
Bottom-bracket drop68 mm68 mm68 mm68 mm68 mm68 mm
Reach405 mm376 mm392 mm396 mm410 mm434 mm
Stack541 mm537 mm551 mm569 mm590 mm609 mm
Standover height574 mm727 mm751 mm790 mm811 mm838 mm

Dimensions as recorded.

Gearing

Original gearing is incomplete. Enter your setup to calculate ratios and cadence speeds.

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Seatpost · Original
Spot black alloy

27.2mm

Retailer offers

Based on the original build. Check fit and installed parts before ordering.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Seatpost diameter
27.2 mm
