2027 Specialized Turbo Vado SL 2 4.0 Step-Through - Satin Gun Metal

Original specifications: 18.75 kg (41 lb, 5.4 oz) published weight · geometry for 3 published sizes.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #900001028
Model year
2027
Category
City & Commuter
Original MSRP
$3,599.99
Sizes
S, M, L
Colors
Satin Gun Metal, Gloss Pistachio
Weight
18.75 kg (41 lb, 5.4 oz)
Geometry
3 manufacturer sizes
In this record
22 specifications · 8 archived images · original MSRP · geometry
Sponsored affiliate link
Original build22 specifications

Manufacturer catalog

Published sizes and colors

3 sizes · 2 colors

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

SML

Published colors

Satin Gun MetalGloss Pistachio

Frameset

Frame Construction2025 Vado SL Step-Through
ForkVado SL Fork,Tubus front rack mounts up to 14kg

Drivetrain

ShiftersShimano CUES 10-Speed Rapidfire Plus, W/ OPTICAL GEAR DISPLAY, SL-U6000-10R
Rear DerailleurShimano CUES 11-speed w/ Shadow Plus
CranksetSRAM Alloy Crankset, DUB interface
CassetteShimano CUES CS-LG400-10, 10-speed, 11-48t
ChainKMC eGlide for 11-Speed CUES
PedalsSpecialized Commuter w/ grip tape & reflectors

Brakes

Brakes(F) Tektro HD-R285, hydraulic disc / (R) Tektro HD-R285, hydraulic disc

Cockpit & Contact Points

HandlebarSpecialized, alloy, 9-degree backsweep, 15mm rise, 31.8mm
StemSpecialized Stealth Stem, Alloy, 31.8mm, Integrated Display And Light Mount, Size S: 60mm 17 Deg, M/L/Xl: 75mm 15.5 Deg
SaddleBridge Sport, Steel rails, 155mm
SeatpostSpecialized, alloy, single bolt, 21mm offset, 27.2mm

Wheels & Tires

Hubs(F) Alloy, 6-bolt disc, sealed cartridge bearing, high-low flange, 12x100mm thru-axle, 24h / (R) Bear Pawls Rear Hub, 6-Bolt Disc, Sealed Cartridge Bearing, 12x142mm
RimsDouble-wall alloy, 27mm internal width, 28h
SpokesDT Swiss Elemental
Front TireSpecialized Hemisphere flat protection, Reflective side walls, Wirebead, All terrain tire, 700x47c
Rear TireSpecialized Hemisphere flat protection, Reflective side walls, Wirebead, All terrain tire, 700x47c

E-bike System

MotorSpecialized SL 1.2 Custom Rx Trail Tuned Motor
BatterySpecialized SL2-520, Fully Integrated, 520Wh
Display/RemoteHMI TLA,H3,SBC-D10,Eubr Compliant,APLW2,Apluto,Dayton
ChargerCustom charger, 48V System w/ SL system charger plug

Geometry

3 sizes · 18 measurements

Frame measurements by size.

All geometry measurements3 sizes · 18 measurements
MeasurementSML
Seat tube410 mm440 mm480 mm
Effective top tube563 mm595 mm630 mm
Head tube115 mm125 mm160 mm
Head-tube angle69°69°69°
Seat-tube angle73°73°73°
Chainstay / rear center470.5 mm470.5 mm470.5 mm
Wheelbase1103 mm1136 mm1174 mm
Bottom-bracket drop70 mm70 mm70 mm
Bottom-bracket height291 mm291 mm291 mm
Reach375 mm405 mm430 mm
Stack614 mm623 mm656 mm
Fork offset / rake50 mm50 mm50 mm
Front center641 mm674 mm712 mm
Trail85 mm85 mm85 mm
Fork length / axle-to-crown430 mm430 mm430 mm
Crank length165 mm170 mm170 mm
Stem length60 mm60 mm75 mm
Handlebar width680 mm680 mm680 mm

Dimensions as recorded.

Gearing

Original gearing is incomplete. Enter your setup to calculate ratios and cadence speeds.

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Cassette · Original
Shimano CUES CS-LG400-10

10-speed, 11-48t

Front tire · Original
Specialized Hemisphere flat protection

Reflective side walls, Wirebead, All terrain tire, 700x47c

Brake pads · Original
(F) Tektro HD-R285

hydraulic disc / (R) Tektro HD-R285, hydraulic disc

More parts (5)Fewer parts
Pedals · Original
Specialized Commuter w/ grip tape & reflectors
Crankset · Original
SRAM Alloy Crankset, DUB interface
165 mm Frame sizes S
170 mm Frame sizes M / L
Rear derailleur · Original
Shimano CUES 11-speed w/ Shadow Plus Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.
Shifters · Original
Shimano CUES 10-Speed Rapidfire Plus

W/ OPTICAL GEAR DISPLAY, SL-U6000-10R

Seatpost · Original
Specialized

alloy, single bolt, 21mm offset, 27.2mm

Based on the original build. Check fit and installed parts before ordering.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
Specialized Hemisphere flat protection, Reflective side walls, Wirebead, All terrain tire, 700x47c
Rear tire
Specialized Hemisphere flat protection, Reflective side walls, Wirebead, All terrain tire, 700x47c
Seatpost diameter
27.2 mm
Sponsored affiliate link
Equipment inspection checks 14 checks based on 6 archived component groups Open equipment checksClose equipment checks
0 of 14 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: 2025 Vado SL Step-Through · Fork: Vado SL Fork,Tubus front rack mounts up to 14kg

Archived: Shifters: Shimano CUES 10-Speed Rapidfire Plus, W/ OPTICAL GEAR DISPLAY, SL-U6000-10R · Rear derailleur: Shimano CUES 11-speed w/ Shadow Plus · Crankset: SRAM Alloy Crankset, DUB interface · Cassette: Shimano CUES CS-LG400-10, 10-speed, 11-48t · Chain: KMC eGlide for 11-Speed CUES

Archived: Brakes: (F) Tektro HD-R285, hydraulic disc / (R) Tektro HD-R285, hydraulic disc

Archived: Rims: Double-wall alloy, 27mm internal width, 28h · Hubs: (F) Alloy, 6-bolt disc, sealed cartridge bearing, high-low flange, 12x100mm thru-axle, 24h / (R) Bear Pawls Rear Hub, 6-Bolt Disc, Sealed Cartridge Bearing, 12x142mm · Front tire: Specialized Hemisphere flat protection, Reflective side walls, Wirebead, All terrain tire, 700x47c · Rear tire: Specialized Hemisphere flat protection, Reflective side walls, Wirebead, All terrain tire, 700x47c

Controls and contact points

Archived: Handlebar: Specialized, alloy, 9-degree backsweep, 15mm rise, 31.8mm · Stem: Specialized Stealth Stem, Alloy, 31.8mm, Integrated Display And Light Mount, Size S: 60mm 17 Deg, M/L/Xl: 75mm 15.5 Deg · Seatpost: Specialized, alloy, single bolt, 21mm offset, 27.2mm · Saddle: Bridge Sport, Steel rails, 155mm · Pedals: Specialized Commuter w/ grip tape & reflectors

Archived: Motor: Specialized SL 1.2 Custom Rx Trail Tuned Motor · Battery: Specialized SL2-520, Fully Integrated, 520Wh · Display: HMI TLA,H3,SBC-D10,EUBR COMPLIANT,APLW2,APLUTO,DAYTON · Charger: Custom charger, 48V System w/ SL system charger plug
