2027 Specialized Rockhopper Expert
Mountain bicycle from the Velopedia specification archive.
- Original MSRP
- $1,299.99
- Sizes
- XS - 27.5, S - 27.5, M - 27.5, S - 29, M - 29, L - 29, XL - 29, XXL - 29
- Colors
- Gloss Charcoal Tint Aluminum / Amethyst Frost, Gloss Red Tint Aluminum / White
- Weight
- 13.11 kg (28 lb, 14.4 oz)
- Geometry
- 8 manufacturer sizes · Ride analysis
- Archive ID
- 900000961
Recently checked market
0 close matches
Observed used market
No listingsNo close used matches in the latest snapshot.
New asking
No listingsNo close matches in this condition.
View market details Move, scroll, tap or type to start the protected update.
Velopedia analysis
What the specifications mean
Suspension is concentrated at the fork, so fork setup and rear-tire pressure are the main tools for balancing front and rear behavior. Both 27.5- and 29-inch wheels appear in the record, but it does not establish a mixed front/rear build; confirm the correct diameter for the selected frame size. The 455% cassette range describes the available gearing more clearly than the component-group name alone.
Suspension setup
Front only
Fork settings affect the front while rear-wheel behavior remains dependent on tire and wheel setup.
Wheel system
27.5 / 29 options
Both diameters are documented, but the archive does not prove a mixed front/rear setup.
Gearing
455% cassette range
Calculated from the published 11–50-tooth sprocket span.
Brake service
Hydraulic disc
Pad and rotor condition plus the correct bleed fluid are the primary service checks.
Used-bike inspection
If you’re buying this bike used
Before any test ride: both brakes should stop the bike firmly and release cleanly; both wheels should run true and be securely attached; tires should have no casing damage; and the headset, handlebar, stem, cranks and pedals should have no looseness or play.
Follow the full used-bike inspection order →- FrameLook closely for dents and hairline cracks around welds, the head tube and bottom-bracket area. Cosmetic scratches matter less than a change in shape or a crack line.Inspect the frame and fork →
- BrakesBoth levers should feel firm and return cleanly. Check for fluid around the levers and calipers, inspect pad thickness and contamination, and look for worn or bent rotors.Inspect the brakes →
- SuspensionAsk when the fork was last serviced. Check the stanchions for damage, look for oil at the seals and make sure the fork moves smoothly without bushing play.Evaluate the suspension →
- DrivetrainShift through the full range under light load, measure chain wear and inspect the cassette or freewheel teeth. Skipping or hesitation can indicate wear, poor adjustment or mismatched parts.Check drivetrain wear →
- Wheels & tiresSpin both wheels and watch the rims for side-to-side or vertical movement. Check for dents, cracks, loose or uneven spokes and hub play, then inspect both tire casings for cuts, cracking or exposed threads. If it is set up tubeless, confirm both tires hold pressure and ask when the sealant was last refreshed.Check wheels and tires →
Bike-specific inspection checklist 21 checks based on 6 archived component groups Open checklistClose checklist
This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.
Identity and fit
Follow the full used-bike inspection order →Archived: 2027 Specialized Rockhopper Expert · Mountain · Published sizes: XS - 27.5, S - 27.5, M - 27.5, S - 29, M - 29, L - 29, XL - 29, XXL - 29
Frame and fork
Inspect the frame and fork →Archived: Frame: Specialized A1 premium butted alloy, zero-stack head tube, internal cable routing, 135x9mm forged dropouts, chainstay-mounted disc brake, replaceable alloy derailleur hanger, stealth rack mounts, dropper post compatible · Fork: RockShox Judy, Solo Air, Turnkey damper, 46mm offset, QR, 80/90/100mm travel (size-specific), alloy steerer · Aluminum
Suspension
Evaluate the suspension →Archived: Fork: RockShox Judy, Solo Air, Turnkey damper, 46mm offset, QR, 80/90/100mm travel (size-specific), alloy steerer
Drivetrain
Check drivetrain wear →Archived: Shifters: SRAM S200 Eagle Trigger Shifter · Rear derailleur: SRAM S200 Eagle · Crankset: SRAM Eagle S100, 30T · Bottom bracket: SRAM Powerspline · Cassette: SRAM PG-1210 Eagle, 11-50T · Chain: SRAM CN S200 EAGLE DRVTRN XXX LINK
Brakes
Inspect the brakes →Archived: Brakes: (F) SRAM DB6, 4-piston caliper, hydraulic disc, 180mm rotor / (R) SRAM DB6, 4-piston caliper, hydraulic disc, 160mm rotor
Wheels and tires
Check wheels and tires →Archived: Wheel size: 27.5; 29 · Rims: Specialized Alloy, hookless, Tubeless ready, 25mm inner width · Hubs: (F) Alloy, Sealed bearing, 6-Bolt, disc, 100x9mm spacing, quick-release / (R) Alloy Sealed bearing, 6-Bolt, disc, 135x9mm spacing, quick-release · Front tire: Ground Control, 27.5/29x2.35, T5 · Rear tire: Ground Control, 27.5/29x2.35, T5
Controls and contact points
Archived: Handlebar: Alloy Mini Rise, 9-degree backsweep, 15mm rise, 31.8mm · Stem: 3D-forged alloy, 31.8mm, 7-degree rise · Seatpost: Alloy, 2-bolt clamp, 30.9mm · Saddle: Body Geometry Power Sport, steel rails · Pedals: Specialized, platform
Before and during the test ride
Follow the full used-bike inspection order →Interpretation based on the archived manufacturer specifications. Confirm exact fit and standards before ordering parts or performing service.
Have you owned this bike?Help preserve its real-world history by sharing your owner experience.
Share the details that would help another rider understand how this model fits, rides and holds up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
Frameset
| Frame Construction | Specialized A1 premium butted alloy, zero-stack head tube, internal cable routing, 135x9mm forged dropouts, chainstay-mounted disc brake, replaceable alloy derailleur hanger, stealth rack mounts, dropper post compatible |
|---|---|
| Frame Material | Aluminum |
| Fork | RockShox Judy, Solo Air, Turnkey damper, 46mm offset, QR, 80/90/100mm travel (size-specific), alloy steerer |
| Fork Material | Aluminum |
Drivetrain
| Shifters | SRAM S200 Eagle Trigger Shifter |
|---|---|
| Rear Derailleur | SRAM S200 Eagle |
| Crankset | SRAM Eagle S100, 30T |
| Bottom Bracket | SRAM Powerspline |
| Cassette | SRAM PG-1210 Eagle, 11-50T |
| Chain | SRAM CN S200 EAGLE DRVTRN XXX LINK |
| Pedals | Specialized, platform |
Brakes
| Brakes | (F) SRAM DB6, 4-piston caliper, hydraulic disc, 180mm rotor / (R) SRAM DB6, 4-piston caliper, hydraulic disc, 160mm rotor |
|---|
Cockpit & Contact Points
| Handlebar | Alloy Mini Rise, 9-degree backsweep, 15mm rise, 31.8mm |
|---|---|
| Stem | 3D-forged alloy, 31.8mm, 7-degree rise |
| Saddle | Body Geometry Power Sport, steel rails |
| Seatpost | Alloy, 2-bolt clamp, 30.9mm |
Wheels & Tires
| Hubs | (F) Alloy, Sealed bearing, 6-Bolt, disc, 100x9mm spacing, quick-release / (R) Alloy Sealed bearing, 6-Bolt, disc, 135x9mm spacing, quick-release |
|---|---|
| Rims | Specialized Alloy, hookless, Tubeless ready, 25mm inner width |
| Spokes | Stainless, 14g |
| Front Tire | Ground Control, 27.5/29x2.35, T5 |
| Rear Tire | Ground Control, 27.5/29x2.35, T5 |
| Wheel Size | 27.5; 29 |
Size-specific frame data
Geometry
Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.
| Measurement | XS - 27.5 | S - 27.5 | M - 27.5 | S - 29 | M - 29 | L - 29 | XL - 29 | XXL - 29 |
|---|---|---|---|---|---|---|---|---|
| Seat tube | 310 mm | 350 mm | 400 mm | 360 mm | 400 mm | 450 mm | 500 mm | 560 mm |
| Effective top tube | 541 mm | 565 mm | 589 mm | 586 mm | 608 mm | 630 mm | 654 mm | 679 mm |
| Head tube | 95 mm | 100 mm | 105 mm | 95 mm | 95 mm | 105 mm | 120 mm | 135 mm |
| Head-tube angle | 68° | 68° | 68° | 68.5° | 68.5° | 68.5° | 68.5° | 68.5° |
| Seat-tube angle | 73.5° | 73.5° | 73.5° | 73.5° | 73.5° | 73.5° | 73.5° | 73.5° |
| Chainstay / rear center | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1067 mm | 1092 mm | 1118 mm | 1105 mm | 1128 mm | 1152 mm | 1178 mm | 1203 mm |
| Bottom-bracket drop | 43 mm | 43 mm | 43 mm | 62 mm | 62 mm | 62 mm | 62 mm | 62 mm |
| Bottom-bracket height | 310 mm | 310 mm | 310 mm | 310 mm | 310 mm | 310 mm | 310 mm | 310 mm |
| Reach | 375 mm | 395 mm | 415 mm | 405 mm | 425 mm | 445 mm | 465 mm | 485 mm |
| Stack | 559 mm | 573 mm | 589 mm | 607 mm | 616 mm | 626 mm | 640 mm | 654 mm |
| Fork offset / rake | 42 mm | 42 mm | 42 mm | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Front center | 630 mm | 656 mm | 682 mm | 672 mm | 696 mm | 719 mm | 745 mm | 770 mm |
| Trail | 97 mm | 97 mm | 97 mm | 97 mm | 97 mm | 97 mm | 97 mm | 97 mm |
| Fork length / axle-to-crown | 475 mm | 485 mm | 495 mm | 505 mm | 515 mm | 515 mm | 515 mm | 515 mm |
| Crank length | 165 mm | 170 mm | 170 mm | 170 mm | 170 mm | 170 mm | 175 mm | 175 mm |
| Stem length | 40 mm | 40 mm | 60 mm | 40 mm | 60 mm | 60 mm | 70 mm | 70 mm |
| Handlebar width | 700 mm | 720 mm | 740 mm | 720 mm | 740 mm | 740 mm | 740 mm | 740 mm |
| Wheel size | 27.5in | 27.5in | 27.5in | 29in | 29in | 29in | 29in | 29in |
Geometry source: Manufacturer HTML geometry table ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.
Geometry interpretation
What this geometry means
The manufacturer publishes more than one geometry configuration. Velopedia analyzes each labeled state separately while treating them as one chassis in archive comparisons.
XS geometry
27.5
Riding position
The 559 mm stack is tall relative to the 375 mm reach, pointing to a more upright front-end position rather than an especially long, low cockpit. The 73.5° effective seat angle is comparatively relaxed for a modern mountain bike, placing the seated position farther behind the bottom bracket than a steep climbing-oriented layout.
Handling tendencies
A 68° head angle combined with a 1067 mm wheelbase points to quicker-steering and more responsive steering and chassis behavior. The longer the chassis and slacker the front end, the more the bike tends to favor composure over very quick direction changes.
Archive context
Its reach of 375 mm sits toward the shorter end. Its stack of 559 mm sits toward the lower end. Its wheelbase of 1067 mm sits toward the shorter end.
S geometry
Configuration
Riding position
The 573 mm stack is tall relative to the 395 mm reach, pointing to a more upright front-end position rather than an especially long, low cockpit. The 73.5° effective seat angle is comparatively relaxed for a modern mountain bike, placing the seated position farther behind the bottom bracket than a steep climbing-oriented layout.
Handling tendencies
A 68° head angle combined with a 1092 mm wheelbase points to quicker-steering and more responsive steering and chassis behavior. The longer the chassis and slacker the front end, the more the bike tends to favor composure over very quick direction changes.
Configuration changes
Compared with 29, this configuration reduces bottom-bracket drop by 19 mm, slackens the head angle by 0.5°, shortens reach by 10 mm, and reduces stack by 34 mm.
Archive context
Its reach of 395 mm sits toward the shorter end. Its stack of 573 mm sits toward the lower end. Its wheelbase of 1092 mm sits toward the shorter end.
Riding position
The 607 mm stack is tall relative to the 405 mm reach, pointing to a more upright front-end position rather than an especially long, low cockpit. The 73.5° effective seat angle is comparatively relaxed for a modern mountain bike, placing the seated position farther behind the bottom bracket than a steep climbing-oriented layout.
Handling tendencies
A 68.5° head angle combined with a 1105 mm wheelbase points to quicker-steering and more responsive steering and chassis behavior. The longer the chassis and slacker the front end, the more the bike tends to favor composure over very quick direction changes.
Configuration changes
Compared with 27.5, this configuration increases bottom-bracket drop by 19 mm, steepens the head angle by 0.5°, extends reach by 10 mm, and adds stack by 34 mm.
Archive context
Its bottom-bracket drop of 62 mm sits toward the deeper-drop end. Its reach of 405 mm sits toward the shorter end. The head angle of 68.5° sits toward the steeper end.
M geometry
Configuration
Riding position
The 589 mm stack is tall relative to the 415 mm reach, pointing to a more upright front-end position rather than an especially long, low cockpit. The 73.5° effective seat angle is comparatively relaxed for a modern mountain bike, placing the seated position farther behind the bottom bracket than a steep climbing-oriented layout.
Handling tendencies
A 68° head angle combined with a 1118 mm wheelbase points to quicker-steering and more responsive steering and chassis behavior. The longer the chassis and slacker the front end, the more the bike tends to favor composure over very quick direction changes.
Configuration changes
Compared with 29, this configuration reduces bottom-bracket drop by 19 mm, slackens the head angle by 0.5°, shortens reach by 10 mm, and reduces stack by 27 mm.
Archive context
Its reach of 415 mm sits toward the shorter end. Its wheelbase of 1118 mm sits toward the shorter end. Its stack of 589 mm sits toward the lower end.
Riding position
The 616 mm stack is tall relative to the 425 mm reach, pointing to a more upright front-end position rather than an especially long, low cockpit. The 73.5° effective seat angle is comparatively relaxed for a modern mountain bike, placing the seated position farther behind the bottom bracket than a steep climbing-oriented layout.
Handling tendencies
A 68.5° head angle combined with a 1128 mm wheelbase points to quicker-steering and more responsive steering and chassis behavior. The longer the chassis and slacker the front end, the more the bike tends to favor composure over very quick direction changes.
Configuration changes
Compared with 27.5, this configuration increases bottom-bracket drop by 19 mm, steepens the head angle by 0.5°, extends reach by 10 mm, and adds stack by 27 mm.
Archive context
Its reach of 425 mm sits toward the shorter end. Its bottom-bracket drop of 62 mm sits toward the deeper-drop end. Its wheelbase of 1128 mm sits toward the shorter end.
L geometry
29
Riding position
The 626 mm stack is tall relative to the 445 mm reach, pointing to a more upright front-end position rather than an especially long, low cockpit. The 73.5° effective seat angle is comparatively relaxed for a modern mountain bike, placing the seated position farther behind the bottom bracket than a steep climbing-oriented layout.
Handling tendencies
A 68.5° head angle combined with a 1152 mm wheelbase points to quicker-steering and more responsive steering and chassis behavior. The longer the chassis and slacker the front end, the more the bike tends to favor composure over very quick direction changes.
Archive context
Its reach of 445 mm sits toward the shorter end. Its bottom-bracket drop of 62 mm sits toward the deeper-drop end. The seat angle of 73.5° sits toward the more relaxed end.
XL geometry
29
Riding position
A 465 mm reach paired with 640 mm of stack gives this size a moderate frame proportion: roomy enough when standing without pushing strongly toward either a very low or very upright front end. The 73.5° effective seat angle is comparatively relaxed for a modern mountain bike, placing the seated position farther behind the bottom bracket than a steep climbing-oriented layout.
Handling tendencies
A 68.5° head angle combined with a 1178 mm wheelbase points to quicker-steering and more responsive steering and chassis behavior. The longer the chassis and slacker the front end, the more the bike tends to favor composure over very quick direction changes.
Archive context
Its reach of 465 mm sits toward the shorter end. Its wheelbase of 1178 mm sits toward the shorter end. Its bottom-bracket drop of 62 mm sits toward the deeper-drop end.
XXL geometry
29
Riding position
A 485 mm reach paired with 654 mm of stack gives this size a moderate frame proportion: roomy enough when standing without pushing strongly toward either a very low or very upright front end. The 73.5° effective seat angle is comparatively relaxed for a modern mountain bike, placing the seated position farther behind the bottom bracket than a steep climbing-oriented layout.
Handling tendencies
A 68.5° head angle combined with a 1203 mm wheelbase points to quicker-steering and more responsive steering and chassis behavior. The longer the chassis and slacker the front end, the more the bike tends to favor composure over very quick direction changes.
Archive context
Its reach of 485 mm sits toward the shorter end. Its wheelbase of 1203 mm sits toward the shorter end. The chainstay of 440 mm sits toward the shorter rear-center end.
Geometry describes frame proportions and likely tendencies, not a ride test. Rider proportions, cockpit setup, tires, suspension settings, wheel configuration, and component choices can materially change how a bicycle fits and feels.
Gallery
Recently checked marketplace data
Market Snapshot
Velopedia did not find a close used eBay listing in the latest snapshot. New and used listings remain separate.
No close current matches found. Velopedia did not find an eBay listing confident enough to include in the latest snapshot.
Listings shown have not passed their eBay-supplied end time. Velopedia rechecks matched bicycles on a protected weekly cycle; availability can still change between checks. Asking prices are not completed-sale prices or an appraisal. Only Velopedia's high-confidence matches are included; lower-confidence Review candidates are excluded. Browse recently checked matched listings.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
